- Page 1 CONSPIT CPP EVO Quick Guide Elite Sim-racing Development...
-
Page 2: Table Of Contents
Product Disclaimer ....................1 Packing List ......................4 01 Install the CPP EVO to the Base Mounting Plate ......... 5 Recommended position of pedals................5 Cable routing path....................6 Mount the pedal set to the base mounting plate ............. 6 Connect all cables .................... - Page 3 Table of Contents Please read the manual carefully before you use the pedal set modifications, tampering, changes or unauthorized uses of the product will void the warranty The pedal set has no waterproof feature, please keep it away from water, rain, morsture and other items containing liquid This pedal set is exclusively designed for sim-racing Disconnect the USB cable if you will not use the product for a long time...
-
Page 4: Product Disclaimer
If you have any questions about this Disclaimer or the following product safety tips and operating specifications, you can consult through support@conspit.com. In the process of reading this Disclaimer and the following product safety tips and operating specifications, you should immediately stop using this product if you do not agree with any of the contents. - Page 5 - If the product is damaged or cannot be used properly, please stop using it immediately and consult CONSPIT's after-sales customer service. Continuing to use it may cause further damage to the product. - Do not attempt to repair the product or its accessories by yourself.
- Page 6 CONSPIT CPP EVO Pedal Set: All-metal build, rock-solid durability. Innovative hydraulics, precision throttle tuning for smooth, nuanced control. High-accuracy sensors, lightning-fast response. 200bar braking force, professional handling, unwavering confidence. Please confirm all the components listed in the packing list before starting the installation.
-
Page 7: Packing List
Packing List （B） （B） （A） CPP EVO 3 CPP EVO 2 base mounting plate throttle, brake and throttle and brake pedals clutch pedals M8x18mm M8x16mm stickers round head hex bolts hex bolts (6 pieces) (4 pieces) 6.0mm hex wrench 5.0mm hex wrench spare parts 4.0mm hex wrench... -
Page 8: Install The Cpp Evo To The Base Mounting Plate
Install the CPP EVO to the Base Mounting Plate * Precautions during installation The product contains small parts. Please avoid accidental swallowing. It is forbidden to disassemble modular units such as hydraulic brake system, clutch modules. Avoid using excessive force to prevent screw damage and other potential risks. -
Page 9: Cable Routing Path
（2） Thread all data and rumble motor cables through the lumbar hole on the base mounting plate. （3） Mount the pedal set to the base mounting plate. The figure below takes the throttle pedal as an example The brake and clutch pedals are installed in the same way M8*18mm rounded head hex bolts (6 pieces) -
Page 10: Connect All Cables
* In order to ensure the stability of data transmission, the data cable must be ensured no entanglement or crushing during assemble. DC 24V in rumble motor connector cable to CONSPIT Wheelbase to PC sensor cable connector Connection Demonstration - 7 -... - Page 11 Data Cable Connection Rumble Motor Connection - 8 -...
-
Page 12: Install The Pedal Set To The Rig
Install the Pedal Set to the Rig 4×Φ9 4×M8 275.2 CPP EVO Drilling Template - 9 -... -
Page 13: Mount Cpp Evo To The Rig
（1） Mount CPP EVO to the rig M8*16mm hex bolts (4 pieces) - 1 0 -... -
Page 14: Mount Cpp Evo To Aluminum Profile-Based Rig
（2） Mount CPP EVO to Aluminum Profile-based Rig 40 Series T-Slot Aluminum Profile is recommended M8*16mm hex bolts (4 pieces) - 1 1 -... -
Page 15: Fine Tune Your Cpp Evo
Fine Tune Your CPP EVO CPP series provides versatile adjustable space, with throttle, brake, and clutch supporting stepwise force adjustment as well as further fine-tuning without limitations. Pedal Pads Angle Adjustment The angle adjustment range of the pad is 0° to 15°, with 0° being when the plate is perpendicular to the pedal base. -
Page 16: Pedal Pads Height Adjustment
Pedal Pads Height Adjustment Throttle Pedal Feel Adjustment Different pedal force can be adjusted by changing the locking pin position. The pedal force varies with the corresponding position. Pedal force increases sequentially from bottom to top. - 1 3 -... -
Page 17: Brake Pedal Feel Adjustment
Pedal force and travel can be further fine-tuned by turning the knob. shorten the travel force adjustment extend the travel Brake Pedal Feel Adjustment By changing the locking pin position, the pedal force can be stepped change. 1. Turn the knob counter- clockwise to completely 2. - Page 18 The four positions of the locking pin simulate different brake pedal feel of various vehicles. When the hydraulic sensor reaches its maximum capacity (100 bar), the corresponding pedal force on the pedal pad is shown in the table below: Type Pedal Force Formula Racing Car 1440N...
- Page 19 Hydraulic Preload of the brake can be adjusted by turning the knob with the adjustment tool. * Do not increase the Hydraulic Preload (turning the knob clockwise) excessively - 1 6 -...
-
Page 20: Clutch Pedal Feel Adjustment
Clutch Pedal Feel Adjustment The clutch travel and engagement point can be adjusted by turning the knob. - 1 7 -... -
Page 21: Software Installation And Set-Up
Software Installation and Set-Up * Visit www.conspit.com and download Conspit Link 2.0. Please scan the QR code for reference. - 1 8 -... - Page 22 - 1 9 -...
- Page 24 WWW.CONSPIT.COM...
