- Page 1 CPP EVO Function Guide Supports: CPP EVO V1.0 Conspit R&D All rights reserved@2024...
-
Page 2: Table Of Contents
2.4 Vibration Settings ..................................11 2.5 Firmware Update ..................................13 2.6 One-Click Game Configuration ............................14 3. Game Compatibility List ..................................15 4. Troubleshooting Guide ..................................16 5. Revision History .....................................17 6. Disclaimer and Copyright Notice ..............................17 Conspit CPP EVO Function Guide V1.0... -
Page 3: Mechanical Adjustment
1. Mechanical Adjustment Decoupling adjustment of throttle travel and spring preload force: Conspit CPP EVO Function Guide V1.0... - Page 4 (This method can be used if it is difficult to re-insert the brake pedal locking pin after it is pulled out.) Unscrew the front adjustment knob of the brake pedal. Loosen the rear adjustment knob of the brake pedal. Conspit CPP EVO Function Guide V1.0...
- Page 5 Push out the pin and adjust it in four levels. After adjustment, put back the previously removed knobs. Note: This part of the clutch pedal is not adjustable. Conspit CPP EVO Function Guide V1.0...
-
Page 6: Driver Software & Functions
2. Driver Software & Functions 2.1 Driver Software Downloads Visit www.conspit.com, or scan the QR code below to download Conspit Link 2.0. 2.2 Homepage Click to select CPP EVO on the homepage. Conspit CPP EVO Function Guide V1.0... - Page 7 On the right side of the homepage, You can quickly check the real-time input and the current pressure of the device. At the bottom of the home page, you can activate the plugin to monitor the inputs of the pedal and steering wheel in real-time through a floating window. Conspit CPP EVO Function Guide V1.0...
- Page 8 Double-click the device name in the “Connected Devices” list, or click the corresponding icon of the device to enter the detailed settings pages. Conspit CPP EVO Function Guide V1.0...
-
Page 9: Pedals Settings
Click on "Pedals" in the menu bar to enter the pedals settings interface. Inputs： In the middle of the page, you can monitor and check the real-time input of the device, and calibrate the input of the throttle, brake, and clutch pedals. Conspit CPP EVO Function Guide V1.0... - Page 10 Click "MIN" to calibrate the minimum value when the pedal is completely released. Click "MAX" to calibrate the maximum value when the pedal is fully pressed. When "Brake" is selected, adjust the upper limit of brake travel input: adjust the upper limit of brake force: Conspit CPP EVO Function Guide V1.0...
- Page 11 After selecting "Throttle", "Brake", or "Clutch" in the middle of the page, you can choose from the four default preset mapping curves for each of the three pedals on the right side of the page, or drag the control points to customize the mapping curve. Conspit CPP EVO Function Guide V1.0...
-
Page 12: Vibration Settings
Click on "Vibration" in the menu bar to enter the vibration settings interface. In the middle of the page, you can select the desired vibration mode from the drop-down box. Set custom vibration in the driver software Controlled by iRacing Controlled by SimHub Conspit CPP EVO Function Guide V1.0... - Page 13 If the vibration mode is selected as "Custom", you can set the vibration mode and intensity for the throttle, brake, and clutch separately. Select "Throttle", "Brake", or "Clutch" to enter the vibration settings interface for the corresponding pedal. Click the "Test" button to test the vibration of each pedal individually. Conspit CPP EVO Function Guide V1.0...
-
Page 14: Firmware Update
Click the ">" button on the right side of the pop-up window to select the firmware you have downloaded for the corresponding product; then click “Confirm” to update the firmware. Note: 1) If the progress bar gets stuck, please unplug and replug the USB cable and try again. Conspit CPP EVO Function Guide V1.0... -
Page 15: One-Click Game Configuration
2.6 One-Click Game Configuration Click on the "Settings" icon in the bottom left corner to enter the driver settings interface, and click on "One-click Game Configuration" to configure. Conspit CPP EVO Function Guide V1.0... -
Page 16: Game Compatibility List
Enter the game, modify the settings, enable UDP, and set the port to 20777. rFactor 2 Special Configuration: One-click configuration is required within Conspit Link 2.0, Enable telemetry plugin in the game settings. Le Mans Ultimate & Dirt Rally 2.0 Special Configuration: One-click configuration is required within Conspit Link 2.0... -
Page 17: Troubleshooting Guide
Tighten the preload knob (if there are both front and rear, tighten them both). To facilitate changing the pin position, the brake pedal will have a natural play (2-3mm) when the preload knob is in a relaxed state. IV. If you encounter any other problems, please consult CONSPIT official customer service. Conspit CPP EVO Function Guide V1.0... -
Page 18: Revision History
Conspit's proposals, specifications, or samples elsewhere. Conspit does not guarantee that this document does not infringe upon third-party rights and shall not be held liable for any infringement of intellectual property rights arising from the use of the information contained in this document.
