PORTABLE AIR CONDITIONER(Local Air Conditioner)
Owner's Manual &
Installation Manual
MODEL: MPPD33H
IMPORTANT NOTE:
Read this manual carefully before installing
or operating your new air conditioning
unit. Make sure to save this manual for
future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MPPD33H and is the answer not in the manual?

Questions and answers

Related Manuals for Midea MPPD33H

Summary of Contents for Midea MPPD33H

  • Page 1 PORTABLE AIR CONDITIONER(Local Air Conditioner) Owner’s Manual & Installation Manual MODEL: MPPD33H IMPORTANT NOTE: Read this manual carefully before installing or operating your new air conditioning unit. Make sure to save this manual for future reference.

  • Page 2: Table Of Contents

    Table of Contents Safety Precautions Safety Precautions ........................Installation Instructions Preparation..........................Design Notice..........................Ambient Temperature Range For Unit Operating............... Exhaust Hose Installation......................Choosing The Right Location..................... Recommend Installation......................12 Energy Rating Information ......................How to Stay Cool with a New Portable Air Conditioner..............

  • Page 3: Safety Precautions

    Safety Precautions Read Safety Precautions Before Operation and Installation To prevent death or injury to the user or other people and property damage, the following instructions must be followed. Incorrect operation due to ignoring of instructions may cause death, harm or damage. CAUTION WARNING This symbol indicates the possibility of...
  • Page 4 In a thunderstorm, the power must be cut off to avoid damage to the machine due to lightning. • Your air conditioner should be used in such a way that it is protected from moisture. • e.g. condensation, splashed water, etc. Do not place or store your air conditioner where it can fall or be pulled into water or any other liquid.
  • Page 5 • Do not use hazardous chemicals to clean or come into contact with the unit. Do not use the unit in the presence of inflammable substances or vapour such as alcohol, insecticides, petrol,etc. • Always transport your air conditioner in a vertical position and stand on a stable, level surface during use.
  • Page 6 For R290(Not applicable for North America) amount of refrigerant (kg) Min. room area(m²) amount of refrigerant (kg) Min. room area(m²) 0.0836 0.1881 and 0.2090 ≥ < ≥ 0.0836 and 0.1045 < 0.2090 and 0.2299 ≥ < ≥ 0.1045 and 0.1254 <...
  • Page 7 Caution: Risk of fire/ flammable materials (Required for R32/R290 units only) Explanation of symbols displayed on the unit(For the unit adopts R32/R290 Refrigerant only): This symbol shows that this appliance used a flammable refrigerant. If the refrigerant WARNING is leaked and exposed to an external ignition source, there is a risk of fire. CAUTION This symbol shows that the operation manual should be read carefully.
  • Page 8 The area shall be checked with an appropriate refrigerant detector prior to and during work, to ensure the technician is aware of potentially flammable atmospheres. Ensure that the leak detection equipment being used is suitable for use with flammable refrigerants, i.e. non-sparking, adequately sealed or intrinsically safe.
  • Page 9 being worked upon prior to any removal of sealed covers, etc. If it is absolutely necessary to have an electrical supply to equipment during servicing, then a permanently operating form of leak detection shall be located at the most critical point to warn of a potentially hazardous situation. 2)Particular attention shall be paid to the following to ensure that by working on electrical components, the casing is not altered in such a way that the level of protection is affected.
  • Page 10 oxygen shall not be used for this task. Flushing shall be achieved by breaking the vacuum in the system with OFN and continuing to fill until the working pressure is achieved, then venting to atmosphere, and finally pulling down to a vacuum. This process shall be repeated until no refrigerant is within the system. When the final OFN charge is used, the system shall be vented down to atmospheric pressure to enable work to take place.

  • Page 11: Installation Instructions

    recovery occurs. The recovery equipment shall be in good working order with a set of instructions concerning the equipment that is at hand and shall be suitable for the recovery of flammable refrigerants. In addition, a set of calibrated weighing scales shall be available and in good working order. Hoses shall be complete with leak-free disconnect couplings and in good condition.

  • Page 12: Ambient Temperature Range For Unit Operating

    Ambient Temperature Range For Unit Operating MODE Temperature Range MODE Temperature Range 应品质要求 Cool 17-35°C (62-95°F) Heat(pump heat mode) 5-30°C (41-86°F) ，增加上出 ≥ 13-35°C (55-95°F) Heat(electrical heat mode) 30°C (86°F) 风口与障碍 物距离 50cm(工程 Exhaust Hose Installation 师提供的数 据)。 The exhaust hose and adaptor must be installed or removed in accordance with the usage mode. For COOL,HEAT(heat pump type) or AUTO mode must be installed exhaust hose.

  • Page 13: Tools Needed

    What should I look for first when purchasing a portable air conditioner? The right air conditioner helps you cool a room efficiently. An undersized unit won't cool adequately while one that's too large will not remove enough humidity, leaving the air feeling damp. To find the proper air conditioner, determine the square footage of the room you want to cool by multiplying the room length by its width.

  • Page 14: Window Installation Kit

    Other Regions Qty. Qty. Shape Shape Name of Accessories Name of Accessories Unit Adaptor 1 pc Security Bracket and 2 Screws 1 set(*) Exhaust Hose 1 pc Drain Hose 1 pc Window Slider Adaptor 1 pc(*) Power Cord Buckle 1 pc Window Slider A 1 pc(*) Bolt...
  • Page 15 Step Two: Install the Exhaust hose assembly to Hook Hole Seat the unit Insert unit adaptor of the Exhaust hose assembly into the lower groove of the air outlet of the unit while the hook of the adaptor is aligned with the hole seat of the air outlet and slide down the Make sure the adaptor Lower groove...

  • Page 16: Installation

    Installation NOTE: Once the Exhaust Hose assembly and Adjustable Window Slider are prepared, choose from one of the following two installation methods. Type 1: Hung Window or Sliding Window Installation(For some models) Foam seal B Foam seal B (Adhesive type-shorter) (Adhesive type-shorter) Foam seal A (Adhesive type)
  • Page 17 MODEL A MODEL B 基准说明同时展示PD所有全功能显示标贴，如客户有要 5. Insert the window slider adaptor into the hole of the window slider. 求，可根据订单BOM中的实际显示标贴图纸进行替换 Type 2: Wall Installation(For some models) 1. Cut a 125mm (4.9inch) hole into the wall for the Wall Exhaust Adaptor B. 2.

  • Page 18: Operating Instructions

    Operating Instructions Control Panel Features NOTE: The following control panels are for explanation purpose only. The control panel of the unit you purchased may be slightly different according to the models. Your machine may not contain some indicators or buttons. The actual shape shall prevail. Press 3s CONSTANT FAN(Press 3s) CONSTANT FAN(Press 3s)

  • Page 19: Operation Instructions

    and the LED DISPLAY shows 'OF' for 3 seconds, ION/Fresh feature(on some models) press SWING and UP(+) buttons at the same Press FAN button for 3 seconds to initiate ION/FRESH time to turn on Wireless function and the LED feature and the ION/FRESH light illumiantes(if applicable), DISPLAY shows 'On' for 3 seconds.

  • Page 20: Other Features

    Note: For some models, the fan speed can not be initiate the Auto-off stop program, the TIMER OFF adjusted under HEAT mode. indicator light illuminates. Press the UP or down button to select the desired time. Press the TIMER button again within 5 seconds, the Auto-on start DRY operation program is initiated.
  • Page 21 AIR FLOW DIRECTION ADJUSTMENT that there are no kinks that will stop the warter flowing. The louver can be adjusted automatically. Adjust the Place the end of the hose into the drain and make sure air flow direction automatically: the end of the hose is down to let the water flow ·...

  • Page 22: Maintenance

    Maintenance Safety Precautions · Always unplug the unit before cleaning or servicing. · DO NOT use flammable liquids or chemicals to clean the unit. · DO NOT wash the unit under running water. Doing so causes electrical danger. · DO NOT operate the machine if the power supply was damaged during cleaning. A damaged power cord must be replaced with a new cord from the manufacturer.

  • Page 23: Store The Unit When Not In Use

    Store the unit when not in use · Drain the unit’s water collection tray according to the instructions in the following section. · Run the appliance on FAN mode for 12 hours in a warm room to dry it and prevent mold. ·...

  • Page 24: Troubleshooting Tips

    Troubleshooting Tips Problem Possible Causes Solution The Water Collection Tray is full. Turn off the P1 Protection Code unit, drain the water from the Water Collection Tray and restart the unit. Unit does not turn on when pressing In COOL mode: room ON/OFF button temperature is lower than Reset the temperature...
  • Page 26 The design and specifications are subject to change without prior notice for product improvement. Consult with the sales agency or manufacturer for details. Any updates to the manual will be uploaded to the service website, please check for the latest version. CP001UI-PDTY...
  • Page 27 REMOTE CONTROLLER OWNER’S MANUAL IMPORTANT NOTE: Thank you for purchasing our air conditioner. Please read this manual carefully before operating your new air conditioning unit. Make sure to save this manual for future reference.
  • Page 28 Table of Contents Remote Controller Specifications ..........02 Handling the Remote Controller ..........03 Buttons and Functions ..............04 Remote Screen Indicators .............06 How to Use Basic Functions ............07 How to Use Advanced Functions ..........10...

  • Page 29: Remote Controller Specifications

    Remote Controller Specifications RG10F(B)/BGEF、RG10F1(B)/BGEF、 Model RG10F2(B1)/BGEFU1、RG10F3(B1)/BGEFU1 3.0V( Dry batteries R03/LR03×2) Rated Voltage Signal Receiving Range -5°C~60°C(23°F~140°F) Environment Quick Start Guide AUTO COOL HEAT FIT BATTERIES SELECT MODE SELECT TEMPERATURE SELECT FAN SPEED PRESS POWER BUTTON POINT REMOTE TOWARD UNIT NOT SURE WHAT A FUNCTION DOES? Refer to the How to Use Basic Functions and sections of this How to Use Advanced Functions...

  • Page 30: Handling The Remote Controller

    Handling the Remote Controller NOTES FOR USING REMOTE CONTROL Inserting and Replacing Batteries Your air conditioning unit may come with two The device could comply with the local batteries(some units). Put the batteries in the national regulations. remote control before use. In Canada, it should comply with •...

  • Page 31: Buttons And Functions

    Buttons and Funcitons Before you begin using your new air conditioner, make sure to familiarize yourself with its remote control. The following is a brief introduction to the remote control itself. For instructions on how to operate your air conditioner, refer to the section of this manual.
  • Page 32 ON/OFF MODE Turns the unit on or off. Scrolls through operation modes as follows: AUTO  COOL  TEMP Increases temperate in DRY  HEAT  FAN 1°C (1°F) increments. NOTE: Please do not select Max. temperature is HEAT mode if the machine you 30°C (86°F ).

  • Page 33: Remote Screen Indicators

    Remote Screen Indicators Information are displayed when the remote controller is power up. Fresh feature display(some units) (No displays when Fresh feature is activated) Sleep mode display Follow me feature display Wireless control feature display Indicator Transmission Low battery detection display(If flashes) Lights up when remote sends signal to indoor display...

  • Page 34: How To Use Basic Functions

    How to Use Basic Functions Basic operation COOL Mode ATTENTION! Before operation, please ensure the unit is plugged in and power is available. SETTING TEMPERATURE The operating temperature range for units is 17°C-30°C (62°F-86°F). You can increase or decrease the set temperature in 1°C (1°F) increments.
  • Page 35 DRY Mode (dehumidifying) Press FAN button to select the fan speed: AUTO, LOW, MED or HIGH. Press the button to start the unit. ON/OFF You can’t set temperature in mode. NOTE: As a result, your remote control’s screen will not display temperature. HEAT Mode 1.
  • Page 36 Setting the TIMER TIMER ON/OFF - Set the amount of time after which the unit will automatically turn on/off. TIMER ON setting Press TIMER ON button to Press up or down button for Point remote to unit and wait initiate the ON time sequence. multiple times to set the desired 1sec, the TIMER ON will be time to turn on the unit.

  • Page 37: How To Use Advanced Functions

    How to Use Advanced Functions SHORTCUT function Swing function Press Swing button Press SHORTCUT button The horizontal louver will swing up and Push this button when remote controller is on, downautomatically when pressing Swing the system will automatically revert back to button.
  • Page 38 SLEEP Function LOCK function Press SLEEP button The SLEEP function is used to decrease energy while you sleep(and don’t need the same temperature settings to stay comfortable). This function can only by activated via remote control. For the details, please see “sleep operation ” in “...
  • Page 39 SET function Press the SET button to enter the function setting, then press SET button or TEMP or TEMP • button to select the desired function. The selected symbol will flash on the display area, press the OK button to confirm. To cancel the selected function, just perform the same procedures as above.
  • Page 40 The design and specifications are subject to change without prior notice for product improvement. Consult with the sales agency or manufacturer for details. CR271-RG10F(B)
  • Page 41 USER MANUAL OF SMART KIT IMPORTANT NOTE: Read the manual carefully before connecting your Smart kit(Wireless module). Make sure to save this manual for future reference.Illustrations in this manual are for explanatory purposes.The actual shape shall prevail.
  • Page 43 CONTENTS SPECIFICATION....................DOWNLOAD AND INSTALL APP................. PREPARATION ....................NETWORK CONFIGURATION................HOW TO USE APP....................SPECIAL FUNCTIONS..................APP DECLARATION....................

  • Page 44: Specification

    1 SPECIFICATION Unit model:MPPD33H Wireless Module Model: EU-SK105, US-SK105 Antenna Type: Printed PCB Antenna Frequency Band: 2400-2483.5MHz Operation Temperature:0 C~45 C/32 F~113 F Operation Humidity: 10%~85% Power Input: DC 5V/300mA Maximum TX Power: <20dBm 2 DOWNLOAD AND MSmartHome APP On an app market (Google Play Store, Apple App Store), search for "MSmartHome"...

  • Page 45: Network Configuration

    4 NETWORK CONFIGURATION Cautions It is necessary to forget any other around network and make sure the Android or iOS device just connect to the Wireless network you want to configure. Make sure the Android or iOS device Wireless function works well and can be connected back to your original Wireless network automatically.
  • Page 46 Register and log in Open the MSmartHome app, and create a new account to start ( you can also register through a third-party account). If you already had an existing account, use the account to log in. Login Enter email XXXXXXXXX Login Enter password...
  • Page 47 5. If no message appears, select "+" on the page and select your device in the list of nearby devices available. If your device is not listed, please add your device manually by the device category [Air Conditioner] and device model [Window AC/ Portable AC].
  • Page 48 NOTE: Make sure your devices are powered on. ・ Keep your mobile phone close enough to your device when you are connecting ・ network to your device. Connect your mobile phone to the wireless network at home, and make sure you ・...

  • Page 49: How To Use App

    5 HOW TO USE APP Please ensure both your mobile device and air conditioner are connected to the Internet before using app to control the air conditioner via internet, please follow the next steps: Login Enter email XXXXXXXXX MSmartHome Login Enter password Login 1.

  • Page 50: Special Functions

    NOTE: Not all the function of the APP is available on air conditioner. For example: ECO, Turbo, Swing function, please check the user manual to find more information. 6 SPECIAL FUNCTIONS Including: Schedule, Sleep curve, Energy Monitor, Check. NOTE: No all the unit can use these special function on the APP. Thus, if the air conditioner do not support theabove function,the function will be hided from the function list.
  • Page 51 Schedule Weekly,user can make an appointment to turn on or off AC on specific time.User also can choose circulation to keep the AC under schedule control every week. Every day Sleep Curve User can customize their own comfortable sleep by setting target temperature.
  • Page 52 Energy Monitor User can simply monitor the electricity consumptionof AC unit by checking the chart and history record. Check User can simply check the AC running status with this function.When finishing this procedure,it can display the normal items,abnormal items, and detail information. Done...

  • Page 53: App Declaration

    7 APP DECLARATION Applicable system:IOS,Android. APP can not support the latest software version of Android and IOS system. Due to special situation may be occurred,we explicitly claims below:Not all of the Android and IOS system are compatible with APP.We will not be responsible for any issue as a result of the incompatibility.
  • Page 54 Declaration of conformity FCC ID: 2ADQOMDNA21 IC: 12575A-MDNA21 This device complies with Part 15 of the FCC Rules and Industry Canada’s licence- exempt RSSs. Operation is subject to the following two conditions: (1) This device may not cause interference;and (2) This device must acceptany interference,including interference that may cause undesired operation of the device.
  • Page 55 NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 56 Manufacturer: Midea Appliances Australia 7 Ordish Road Dandenong South VIC 3175 Australia E-mail: info@midea.net.au CP005IU-MSMARTAPWIFI(OBM)
