- Page 1 MIDEA 60Hz PORTABLE PD SERIES SINGLE-HOLE...
-
Page 2: Table Of Contents
CONTENTS 1. Precaution ............................. 1 1.1 Safety Precaution..........................1 1.2 Warning ............................... 1 2. Model Lists ............................6 3.Function and control panel ........................7 3.1 Function .............................. 7 3.2 Control panel ............................8 ... -
Page 3: Precaution
1. Precaution 1.1 Safety Precaution. To prevent injury to the user or other people and property damage, the following instructions must be followed. Incorrect operation due to ignoring instruction will cause harm or damage. Before service unit, be sure to read this service manual at first. 1.2 Warning ... - Page 4 It may cause injury, accident, or damage to the product. Be sure the installation area does not deteriorate with age. If the base collapses, the air conditioner could fall with it, causing property damage, product failure, and personal injury. ...
- Page 5 unit is so equipped.) There is risk of physical injury, electric shock, or product failure. When the product is soaked (flooded or submerged), contact an Authorized service center. There is risk of fire or electric shock. Be caution that water could not enter the product. There is risk of fire, electric shock, or product damage.
- Page 6 Operational Do not expose the skin directly to cool air for long periods of time. (Do not sit in the draft). This could harm to your health. Do not use the product for special purposes, such as preserving foods, works of art, etc. It is a consumer air conditioner, not a precision refrigerant system There is risk of damage or loss of property.
- Page 7 Warning -Do not use means to accelerate the defrosting process or to clean, other than those recommended by the manufacturer. -The appliance shall be stored in a room without continuously operating ignition sources (for example: open flames, an operating gas appliance or an operating electric heater). -Do not pierce or burn.
-
Page 8: Model Lists
2. Model Lists Capacity units ON/OFF MPPDB-10CRN8-BCG8 MPPDB-10HRN8-BCG8... -
Page 9: Function And Control Panel
3.Function and control panel 3.1 Function ※ Operation mode: Cooling, Heating, Dry, Fan and Auto. ※ ION (optional) ※ Auto swing function. ※ Timer function. ※ Flexible installation kit. ※ No bucket design. ※ LED display. ※ Sleep mode. ※... -
Page 10: Control Panel
3.2 Control panel MPPDB-10CRN8-BCG8, MPPDB-10HRN8-BCG8 (1) POWER button Power switch on/off (2) SLEEP button Used to initiate the SLEEP operation. (3) FAN/ION button (ION is optional) Control the fan speed. Press to select the fan speed in four steps-LOW, MED, HI and AUTO. The fan speed indicator light illuminates under different fan settings except AUTO speed. - Page 11 louver at the desired angle. (8) LED Display Show the set temperature in "℃" or "℉" and the Auto-timer settings. While on DRY and FAN modes, it shows the room temperature. Error codes: E1- Room temperature sensor error-Unplug the unit and plug it back in. If error repeats, call for service. E2- Evaporator temperature sensor error- Unplug the unit and plug it back in.
-
Page 12: Dimension
4. Dimension Unit Dimension W(mm) H(mm) D(mm) small body big body... -
Page 13: Refrigerant Cycle Diagram
5. Refrigerant Cycle Diagram The figure below is a brief description of the important components and their function in what is called the refrigeration system. (1) This will help to understand the refrigeration cycle and the flow of the refrigerant in the cooling cycle. C A P IL I A R Y T U B E L I Q U I D S ID E C O N D E N S E R... - Page 14 (2).This figure below is fit for Heat Pump Unit. C H E C K V A L V E L IQ U ID S ID E ( H e a tin g M o d e l o n ly ) C A P IL IA R Y T U B E H E A T H E A T...
-
Page 15: Wiring Diagram
6. Wiring Diagram MPPDB-10CRN8-BCG8, MPPDB-10HRN8-BCG8... -
Page 16: Electronic Function
7 Electronic function 7.1 Terms and definitions TC: Temperature of evaporator (T2). TA: Temperature of indoor ambient (T1). TS: The set temperature. TE: Temperature of condenser (T3) 7.2 Electric Control working environment Input voltage: 187~264V for 50Hz models 7.3 Protection function ... -
Page 17: Drying Mode
O p e r a tio n c o n d ito n ( T A - T s ) ℃ C o m p r e s s o r o n C o m p r e s s o r o ff 7.5.2.1 If TA﹥TS+1℃, the outdoor fan operates. -
Page 18: Heating Mode (Heater)
7.6.3. The TIMER function is valid in drying mode. 7.7 Heating mode (heater) 7.7.1. The speed of indoor fan can be optionally chosen as High/Mid/Low. The compressor and outdoor fan keep on stop (except P1 protection) 7.7.2. In heating mode, the heater will operate according to the difference between TA and TS. Electric heater operates as below. -
Page 19: Sensor Malfunction
2) When TE(TC)﹥40℃ or time is more than 7 minutes, up outdoor motor is on at high speed until defrosting is over. 7.8.4 When meeting one of conditions as below, unit finishes defrosting motion. 1) The time of defrosting is up to 10 minutes. 2) TE(TC)≥50℃... - Page 20 7.10.2. Sleep function Press this button, the selected temperature will increase (cooling) or decrease (heating) by 1℃/2 ℉30 minutes. The temperature will then increase (cooling) or decrease (heating) by another 1℃/2℉ after an additional 30 minutes. This new temperature will be maintained for 7 hours before it returns to the originally seting temperature.
-
Page 21: Installation Details
8 Installation details 8.1 Installation instructions Location The air conditioner should be placed on a firm foundation to minimize noise and vibration. For safe and secure positioning, place the unit on a smooth, level floor strong enough to support the unit. The unit has casters to aid placement, but it should only be rolled on smooth, flat surfaces. - Page 22 Window Installation Kit(Optional) Step 1: Preparing the Exhaust Hose assembly Press the exhaust hose into the window slider adaptor (into wall window slider adaptor for wall installation) and unit adaptor, clamp automatically by elastic buckles of the adaptors. Step 2: Install the Exhaust hose assembly to the unit Insert unit adaptor of the Exhaust hose assembly into the lower groove of the air outlet of the unit while the hook of the adaptor is aligned with the hole seat of the air outlet and slide down the Exhaust hose assembly along the arrow direction for installation.
- Page 23 Note: Once the Exhaust Hose assembly and Adjustable Window Slider are prepared, choose from one of the following three installation methods. Type 1: Hung Window Installation(optional)
- Page 24 Type 2: Sliding Window Installation(optional)
- Page 25 Type 3: Wall Installation(optional) -Cut a 125mm (4.9inch) hole into the wall for the Wall Exhaust Adaptor B. -Secure the Wall Exhaust Adaptor B to the wall using the four Anchors and Screws provided in the kit. -Connect the Exhaust Hose Assembly(with Wall Exhaust Adaptor A) to the Wall Exhaust Adaptor B. Note: To ensure proper function, DO NOT overextend or bend the hose.
- Page 26 Water drainage -During dehumidifying modes, remove the drain plug from the back of the unit, install the drain connector(5/8〞universal female mender) with 3 /4〞hose(locally purchased). For the models without drain connector, just attach the drain hose to the hole. Place the open end of the hose directly over the drain area in your basement floor.
-
Page 27: Care And Maintenance
-When the water level of the bottom tray reaches a predetermined level, the unit beeps 8 times, the digital display area shows "P1". At this time the air conditioning/dehumidification process will immediately stop. However, the fan motor will continue to operate (this is normal). Carefully move the unit to a drain location. - Page 28 Cleaning Wash the air filter by immersing it gently in warm water (about 40℃/104℉) with a neutral detergent. Rinse the filter and dry it in a shady place. Mounting Install the upper air filter after cleaning and install the lower filter by using the screw. NOTE: The grill and the air filer are connected and can’t be separated.
-
Page 29: Basic Test Procedure
9 Basic test procedure 9.1 Defective compressor Compressors are single phase, depending on the model unit. All compressor motors are permanent split capacitor type using only a running capacitor across the start and run terminal. All compressors are internally spring mounted and externally mounted on rubber isolators. 9.1.1 Compressor wiring test Remove compressor terminal box cover and disconnect wires from terminals. - Page 30 Terminal "R" and "S" - no continuity - Open winding - replace compressor. 9.1.2 Ground test Use an ohmmeter to set on its highest scale. Touch one lead to the compressor body (clean point of contact as a good connection is a must) and the other probe in turn to each compressor terminal (see Figure 2.) If a reading is obtained, the compressor is grounded and must be replaced.
-
Page 31: 9.2 Sealed Refrigeration System Repairs
1. High amperage. 2. Low refrigerant charge. 3. Frequent recycling. 4. Dirty condenser. 9.1.5 Terminal overload – Test (compressor external type) 1. Remove overload. 2. Allow time for overload to reset before attempting to test. 3. Apply ohmmeter probes to terminals on overload wires. There should be continuity through the overload. - Page 32 8. Accurate refrigerant charge measuring device such as: a. Balance Scales - 1/2 oz. accuracy b. Charging Board - 1/2 oz. accuracy 9. High Pressure Gauge - (0 - 400 lbs.) 10. Low Pressure Gauge - (30 - 150 lbs.) 11.
- Page 33 copper tubing. (Do not use regular hoses.) 10. Evacuate system to maximum absolute holding pressure of 200 microns or less. NOTE: This process can be speeded up by use of heat lamps, or by breaking the vacuum with refrigerant or dry nitrogen at 5,000 microns. Pressure system to 5 PSIG and leave in system a minimum of 10 minutes.
-
Page 34: Fan Motor
as possible to the nameplate charge. 2. The correct method for charging the rotary is to introduce liquid refrigerant into the high side of the system with the unit off. Then start compressor and enter the balance of the charge, gas only, into the low side. - Page 35 Capacitor test: 1. Remove capacitor from unit. 2. Check for visual damage such as bulges, cracks, or leaks 3. For dual rated, apply an ohmmeter lead to common (C) terminal and the other probe to the compressor (HERM) terminal. A satisfactory capacitor will cause a deflection on the pointer, and then gradually move back to infinity.
-
Page 36: Characteristic Of Temperature Sensor
10 Characteristic of temperature sensor Resistance Resistance Resistance Temp.℃ Temp.℃ Temp.℃ KΩ KΩ KΩ 62.2756 14.6181 4.3874 58.7079 13.918 4.2126 56.3694 13.2631 4.0459 52.2438 12.6431 3.8867 49.3161 12.0561 3.7348 46.5725 11.5 3.5896 10.9731 3.451 41.5878 10.4736 3.3185 39.8239 3.1918 37.1988 9.5507 3.0707... -
Page 37: Troubleshooting
11 Troubleshooting In general, possible trouble is classified in three kinds. One is called Starting Failure which is caused from an electrical defect, another is ineffective Air Conditioning caused by a defect in the refrigeration circuit and improper application, and the other is called the Structure Damage. TROUBLES POSSIBLE CAUSES SUGGEST REMEDIES...
