ASRock Industrial IMB-1714 Settings Manual

IMB-1714
IMB-X1714
The terms HDMI ® and HDMI High-Definition
Multimedia Interface, and the HDMI logo are
trademarks or registered trademarks of HDMI
Licensing LLC in the United States and other
countries.

Revision History

Date Description
December 8, 2022 First Release
May 26, 2023 Second Release
August 21, 2023 Third Release

COM Port Pin9 PWR Setting Jumpers

1 : PWR_COM1 (For COM Port1)
PWR_COM2 (For COM Port2)
25 : PWR_COM3 (For COM Port3)
PWR_COM4 (For COM Port4)
PWR_COM5 (For COM Port5)
PWR_COM6 (For COM Port6)
1-2 : +5V (Default)
2-3 : +12V

2 : PS/2 Keyboard/Mouse Header

(PS2_KB_MS1)
Pin Signal Name Signal Name Pin
1 KBCLK +5V 2
3 KBDATA +5V 4
5 MSDATA GND 6
7 MSCLK GND 8

LAN LED Headers

3 : I225_LED3 (For LAN3 Port)
37 : I225_LED2 (For LAN2 Port)
I225_LED1 (For LAN1 Port)
Pin Signal Name
1 LILEDP
2 LED_LNK#_ACT
3 LED_1000#
4 LED_2500#

4 : ATX 12V Power Connector (ATX12V1)

Pin Signal Name Signal Name Pin
1 GND ATX12V 5
2 GND ATX12V 6
3 GND ATX12V 7
4 GND ATX12V 8

Chassis FAN Connectors (+12V)

5 : CHA_FAN1
22 : CHA_FAN2
14 : CHA_FAN3
Pin Signal Name
1 GND
2 +12V
3 CHA_FAN_SPEED
4 FAN_SPEED_CONTROL

6 : CPU FAN Connector (+12V)

(CPU_FAN1)
Pin Signal Name
1 GND
2 +12V
3 CPU_FAN_SPEED
4 FAN_SPEED_CONTROL
Jumpers and Headers Setting Guide
1 2 3
I225_LED3 I225_LED3
1 1
USB 3.2 Gen2 1
47
Top:
T: USB3_2
LAN3
B: USB3_1 PS2_KB_MS1
1
46
PWR_COM1
1
45
PWR_COM2
44 T: USB 3.2 Gen2
Top:
(USB3_9)
B: USB 3.2 Gen2x2 LAN2
(TC_U3_7)
43 USB 3.2 Gen2
Top:
T: USB3_4
LAN1
B: USB3_3
PCIE_PWR1
42
1
41
PCIE2
TB1
40
39 1
PCIE3
DACC1 I225_LED2
38
1
1
37
1
I225_LED1
CMOS
Battery
PCIE5
36
35 CLRMOS2
1
1 PWR_BAT1
34
1 CLRMOS1
1
BUZZ2
PCIE6
SPDIF1
1
PCIE7
HD_AUDIO1 USB2_10_11
1 1
1
33 32 31
USB 2.0 Ports
7 : USB2_13
1 1
11 : USB2_12
2
3 3
Pin
1
PWR_COM1
2
3
4
1 3
8 : PSU_SMB1
PWR_COM2~6
Pin
1
2
3
4
5
• The SMBus connector is for power supply unit.
1 7
9 : 24-pin ATX Power Input Connector
2 8
Pin Signal Name
1 +3V
2 +3V
3 GND
4 +5V
5 GND
6 +5V
7 GND
8 PWROK_PS
9 ATX+5VSB
10 +12V
11 +12V
12 +3V
1 4
Chassis Intrusion Headers
10 : CI2 :
Open : Active Case Open
Short : Normal (Default)
8 5
13 : CI1 :
Open : Normal (Default)
4 1
Short : Active Case Open
12 : PWR LOSS Jumper (PWR_LOSS1)
1 4
Open : No Power Loss
CHA_FAN1
Short : Power Loss (Default)
CHA_FAN3
4
15 : USB 3.2 Gen1 Header (USB3_5_6)
1
CHA_FAN2
Pin Signal Name
1 ID
3 IntA_P1_D+
5 IntA_P1_D-
7 GND
9 IntA_P1_SSTX+
11 IntA_P1_SSTX-
13 GND
15 IntA_P1_SSRX+
1 4
17 IntA_P1_SSRX-
19 Vbus
4 5 6
1
1 CHA_FAN1
ATX12V1 1
CPU_FAN1
1
1
CHA_FAN3
PCIE1
Industrial
1
PCIE4
COM6
SIO_AT1
1
1
PWR_COM6
1 1
1
JGPIO_SET1 PWR_COM4 PWR_COM5
PWR_COM3
1
LPT_GPIO1
1
ESPI1
JGPIO_PWR1
1
1
1 1 1
COM3 COM4 COM5
30 29 28 27 26 25 24
Signal Name
4
USB_PWR
USB_D-
USB_D+
GND
1
Signal Name
1
SMB_CLK
SMB_DATA
SMBALERT#
GND
5
+3V
Signal Name Pin
12 24
+3V 13
-12V 14
GND 15
PSON# 16
GND 17
GND 18
GND 19
NA 20
+5V 21
1 13
+5V 22
+5V 23
GND 24
2
1
2
1
Signal Name Pin 20 19
IntA_P0_D+ 2
IntA_P0_D- 4
GND 6
IntA_P0_SSTX+ 8
IntA_P0_SSTX- 10
GND 12
IntA_P0_SSRX+ 14
IntA_P0_SSRX- 16
2 1
Vbus 18
20
7
USB2_13
1
1
8
PSU_SMB1
9
1
10
USB2_12
CI1 CI2
11
1 1 1
12
PWR_LOSS1
1
13
14
15
USB3_5_6
1
16
17
18
BIOS
ROM
1
19
PANEL1
1
20
M2_B1
SIM1
1
21
CHA_FAN2
22
1
SATA3_0 1 SATA3_2 1
1 SATA3_1 1 SATA3_3
23
SATA3 Connectors
17 : SATA3_4, SATA3_5
18 : SATA3_6, SATA3_7
23 : SATA3_0~3
Pin Signal Name
1 GND
2 SATA-A+
3 SATA-A-
4 GND
5 SATA-B-
6 SATA-B+
7 GND
19 : System Panel Header (PANEL1)
Pin Signal Name Signal Name
1 HDLED+ PLED+
3 HDLED- PLED-
5 GND PWRBTN#
7 RESET# GND
9 GND
24 : COM Port Headers (COM3~6) (RS232)
Pin Signal Name Signal Name
1 DDCD#1 RRXD1
3 TTXD1 RRTR#1
5 GND DDSR#1
7 RRTS#1 CCTS#1
9 PWR
26 : ATX/AT Mode Jumper (SIO_AT1)
Open : ATX Mode (Default)
Short : AT Mode
27 : ESPI Header (ESPI1)
Pin Signal Name Signal Name
1 ESPI_CLK GND
3 ESPI_CS# SMB_CLK_MAIN
5 ESPI_RST# SMB_DATA_MAIN
7 ESPI_IO3 ESPI_IO2
9 +3V ESPI_IO1
11 ESPI_IO0 GND
13 N/A
15 +3VSB ESPI_ALERT#
17 GND GND
28 : Printer Port/GPIO Header (LPT_GPIO1)
Printer Port:
Pin Signal Name Signal Name Pin
1 STB# AFD# 2
3 SPD0 ERROR# 4
5 SPD1 PINIT# 6
7 SPD2 SLIN# 8
9 SPD3 GND 10
11 SPD4 GND 12
13 SPD5 GND 14
15 SPD6 GND 16
17 SPD7 GND 18
19 ACK# GND 20
21 BUSY GND 22
23 PE GND 24
25 SLCT 26
2 26
1 25
• If you want to use the printer port function, please short pin4 and pin5 on
Digital Inpu/Output Power Select (JGPIO_PWR1).
1
7
SATA3_4~7
SATA3_0 SATA3_2
7 1 7 1
1 7 1 7
SATA3_1 SATA3_3
Pin
1 2
2
4
6
8
10
9 10
2 10
Pin
2
4
6
1 9
8
10
1 2
2 18
Pin
2
4
6
8
1 17
10
12
14
16
18
GPIO:
Pin Signal Name Signal Name Pin
1 SIO_GP77 SIO_GP76 2
3 SIO_GP80 SIO_GP75 4
5 SIO_GP81 SIO_GP74 6
7 SIO_GP82 SIO_GP73 8
9 SIO_GP83 JGPIOPWR 10
11 SIO_GP84 JGPIOPWR 12
13 SIO_GP85 GND 14
15 SIO_GP86 GND 16
SIO_GP87/GPP_
17 GND 18
H23
19 SIO_G72/GPP_I10 GND 20
21 SIO_G71/GPP_E5 GND 22
23 SIO_G70/GPP_E6 GND 24
25 NA NC 26
