KEYSECURE® 6 USER INSTRUCTIONS
The Knox eKey can be charged and programmed via the KeySecure 6. When the Knox eKey is retained, the
KeySecure will not display any LED lights. The Knox eKey, however, will slowly flash green while charging.
Refer to the Knox eKey User Guide for information on the color status of the LEDs.

Remove and Return the Electronic Knox eKey

1. Enter a valid PIN, SecurePIN or two valid PINs if Dual PIN is enabled on the keypad. PIN entry should be
followed by pressing the arrow (Return) key to complete the PIN entry:
• The Keypad numbers will dim upon each key press and illuminate upon each keypad release
Single PIN: If a correct PIN is entered and only a single PIN is required, both amber LED lights will
•
illuminate and the device will begin the key release process
• Dual PIN: If a correct PIN is entered both amber LED lights will fast flash. The second user will have 15
seconds to enter their PIN:
• Flashing will discontinue upon the first keypress or the 15 second time out
• When the correct second PIN is entered, both amber LED lights will illuminate and the device will begin
the key release process
• If an incorrect PIN is entered, both amber LED lights will double flash. Repeat step 1 using a correct PIN
Key release process:
•
• The master key and eKey retainer will become physically unlocked (this may take several seconds -
DO NOT attempt to remove the eKey or key during this time). The LED lights will then stay lit for an
additional 5 seconds allowing the key or eKey to be removed.
2. To remove the key from the KeySecure device:
eKey: Flip down the retention latch and remove it from the KeySecure
•
NOTE: The amber LED light above the electronic key will flash, indicating the key is unsecured.
Mechanical key: Turn the master key clockwise (right) and remove it from the KeySecure.
•
NOTE: The amber LED light above the key will flash, indicating the key is unsecured
NOTE: The key and eKey remain in a released position for five (5) seconds. If they are not removed within
the specified release time they will be relocked. To release, repeat step 1.
3. Return the key to the KeySecure device:
• eKey: Insert the eKey and push the retention latch up to activate the retention motor. The LED on the
KeySecure will display light solid red while the retention latch locks the eKey securely and verifies it, the
LED light will then turn off.
Mechanical key: Insert the master key and turn counterclockwise (left) to lock it into the retention port.
•
The LED light on the KeySecure will stop flashing.
