ODC 1018
T T M
M
T T M
M
OUTDOOR DISCOVERY CRAFT
ASSEMBLY INSTRUCTIONS
Your ODC 1018 Pontoon Boat comes in two separate cartons consisting of the following parts:
ALUMINUM FRAME
(1) Left Frame Member
(1) Right Frame Member
(1) Seat Support Frame Member with Underseat Lift and Lock Anchor System Attached
(2) Foot Bars
(10) Short Snap Pins
(2) Side Storage Pockets
(1) Cargo Deck (with protective bar for shipping attached)
(1) Anchor Line Storage Bag
(1) U-Bar
(1) Rod Holder
(1) Plastic Padded Seat Back
(1) Plastic Padded Seat Bottom
(4) Seat Screws
(2) Seat Assembly Pins
OARS & OARLOCKS
PONTOONS
(1) Pair 8 foot, 3 piece oars
(1) Pair pontoons: Each pontoon consists of
(1) Pair bronze oarlocks, with split rings
30 oz. PVC thermal welded cover, 420 denier nylon
(1) Pair Oar Stops
liner and 30 gauge PVC bladder with valve insert
(2) Oarlock Bushings
and valve plate all pre-assembled.
(8) Cam-lock straps
WARRANTY CARD & PATCH KIT
PUMP
(1)
STRIPPING APRON
Complete with a set of adapters
Advertisement
Table of Contents
Related Manuals for Creek Company ODC 1018
Summary of Contents for Creek Company ODC 1018
- Page 1 T T M T T M OUTDOOR DISCOVERY CRAFT ASSEMBLY INSTRUCTIONS Your ODC 1018 Pontoon Boat comes in two separate cartons consisting of the following parts: ALUMINUM FRAME (1) Left Frame Member (1) Right Frame Member (1) Seat Support Frame Member with Underseat Lift and Lock Anchor System Attached...
- Page 2 NOTE: Always inflate the Pontoons first, before attaching to frame. IV. ATTACH PONTOONS TO FRAME 1. Position inflated Pontoons under the Left and Right Frame Members with ODC 1018 logo oriented to the outside. 2. Attach each Pontoon to frame using (8) Cam Lock Straps. Slip each strap through D-Ring on Pontoon, around frame and pull tight through Cam Lock Buckle.
- Page 3 VI. ATTACH SIDE STORAGE POCKETS TO FRAME 1. Position Side Storage Pockets along Left Frame Member and Right Frame Member. (see figure 5) 2. Wrap hook & loop straps around upper rail frame and strap down. 3. Wrap lower hook & loop straps around bottom rail of frame and strap down. VII.
- Page 4 Storage Pockets. Transom for electric trolling motor attachment Frame Figure 5 Assembled ODC 1018 Nylon Strap Figure 6 A. Pontoons Detail of Nylon B. Right Frame Member F & G Side Storage Pockets Lock Strap & Cam C.
- Page 5 Figure 8 Figure 7 Valve Insert detail Oar Lock Detail Oarlock Top valve cap Valve assembly Oarlock Bushing Oarlock Stations Valve plate Split Ring Bladder Figure 9 Underneath View of Underseat Lift and Lock Anchor System Designed to be used while sitting in seat.
- Page 6 2. Do not store your ODC 1018 in direct sunlight. 3. If you are leaving your ODC 1018 out in the sun for any amount of time, be aware that the heat can increase the pressure inside the pontoons to a dangerous level. Let some of the air out of the pontoons if the craft will be out of the water in the sun for any length of time, or if it is stored in a vehicle, etc.
