XR 9-2009:new odc 1018 revised 2/17/10 9:11 AM Page 1
ODC XR 9
TM
OUTDOOR DISCOVERY CRAFT
TM
ASSEMBLY INSTRUCTIONS
Your ODC XR 9 Pontoon Boat comes in two separate cartons consisting of the following parts:
alUMinUM FRaMe
(1) Left Frame Member
(1) Right Frame Member
(1) Seat Support Frame Member with Underseat Lift and Lock Anchor System Attached
(2) Foot Bars
(8) Short Snap Pins
(1) Side Storage Pocket
(1) Cargo Deck with Motor Mount (with protective bar for shipping attached)
(1) Anchor Line Storage Bag
(1) Rod Holder
(1) Plastic Padded Seat Back
(1) Plastic Padded Seat Bottom
(4) Seat Screws
(2) Seat Assembly Pins
OaRs & OaRlOCks
POntOOns
(1) Pair 7 foot, 3 piece oars
(1) Pair pontoons: Each pontoon consists of
(1) Pair bronze oarlocks, with split rings
30 oz. PVC thermal welded cover with integral side
(1) Pair Oar Stops
storage pockets, 420 denier nylon liner and 30 gauge
(2) Oarlock Bushings
PVC bladder with valve insert
and valve plate all pre-assembled.
WaRRantY CaRD & PatCh kit
(8) Cam-lock straps
stRiPPing aPROn
PUMP
(1)
Complete with a set of adapters
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Creek Company ODC XR 9
Summary of Contents for Creek Company ODC XR 9
- Page 1 XR 9-2009:new odc 1018 revised 2/17/10 9:11 AM Page 1 ODC XR 9 OUTDOOR DISCOVERY CRAFT ASSEMBLY INSTRUCTIONS Your ODC XR 9 Pontoon Boat comes in two separate cartons consisting of the following parts: alUMinUM FRaMe (1) Left Frame Member (1) Right Frame Member...
- Page 2 IV. ATTACH PONTOONS TO FRAME nOte: always inflate the Pontoons first, before attaching to frame. 1. Position inflated Pontoons under the Left and Right Frame Members with ODC XR 9 logo oriented to the outside. 2. Attach each Pontoon to frame using (4) Cam Lock Straps. Slip each strap through D-Ring on Pontoon, around frame and pull tight through Cam Lock Buckle.
- Page 3 XR 9-2009:new odc 1018 revised 2/17/10 9:11 AM Page 3 VI. ATTACH SIDE STORAGE POCKET TO FRAME 1. Position Side Storage Pocket along Left Frame Member or Right Frame Member. (see figure 5) 2. Wrap straps around upper rail of frame and strap down. . VII.
- Page 4 XR 9-2009:new odc 1018 revised 2/17/10 9:11 AM Page 4 Figure 4 Rod Holder Frame assembly attaches here G. Foot Bars H. Left Frame Member I. Right Frame Member J. Seat Support Frame Member K. Cargo Deck L. Lift and Lock Anchor Drop Assembly Rod Holder attaches here Valves located on...
- Page 5 XR 9-2009:new odc 1018 revised 2/17/10 9:11 AM Page 5 Figure 8 Figure 7 Valve insert detail Oarlock Oar lock Detail Top valve cap Valve assembly Oarlock Bushing Oarlock Stations Valve plate Split Ring Bladder Figure 9 Underneath View of Underseat lift and lock anchor system Designed to be used...
-
Page 6: Care And Maintenance
4. A gain in altitude will increase the pressure in the pontoons also. If you are taking your inflated ODC XR 9 from a low elevation to a high elevation, be sure to let some of the air out of it.
