ODC SUPERSPORT XR 1

OUTDOOR DISCOVERY CRAFT

ASSEMBLY INSTRUCTIONS

(1) Seat Support Frame Member with Underseat Lift and Lock Anchor System Attached

(1) Cargo Deck with Motor Mount and Battery plate

Each Pontoon consists of Nylon Cover with PVC bottom featuring integral Side Storage Pockets,

and Main Bladder with Valve Insert and Valve Plate all preassembled.

THIS BOX CONTAINS:

STEEL FRAME

(1) Left Frame Member

(1) Right Frame Member

(1) Plastic Seat Back

(1) Plastic Seat Bottom

(4) Seat Screws

(2) Seat Assmbly Pins

(2) Foot Bars

(1) Stripping Apron

(8) Snap Pins

(1) Rod Holder

OARS & OARLOCKS

(1) Pair 6-foot 2 piece Oars

(1) Pair Clamp-on Oarlocks

PONTOONS

(1) Left Pontoon

(1) Right Pontoon

(8) Cam Lock Straps

PUMP

Complete with a set of Adaptors

Page 1 ODC SUPERSPORT XR 1 OUTDOOR DISCOVERY CRAFT ASSEMBLY INSTRUCTIONS THIS BOX CONTAINS: STEEL FRAME (1) Left Frame Member (1) Right Frame Member (1) Seat Support Frame Member with Underseat Lift and Lock Anchor System Attached (1) Plastic Seat Back (1) Plastic Seat Bottom...
Page 2 ODC SUPERSPORT XR 1 OUTDOOR DISCOVERY CRAFT ASSEMBLY INSTRUCTIONS I. PLASTIC SEAT ASSEMBLY 1. Assemble Seat Back to Seat Bottom using Seat Assembly Pins (see figure 1a). II. ASSEMBLE FRAME NOTE: Your Frame Assembles using (8) Snap Pins and (4) Seat Screws. Please follow instructions accordingly.
Page 3 Fig. 1 Frame assembly a. Cargo Deck with Motor Mount b. Left Frame Member c. Right Frame Member d. Seat Support Frame Member e. Foot Bars Fig. 1a Seat Frame assembly a. Plastic Seat Back Seat b. Plastic Seat Bottom Assembly c.
Page 4: Care And Maintenance
4. A gain in altitude will increase the pressure in the Pontoons also. If you are taking your inflated ODC SUPERSPORT XR 1 from a low elevation to a high elevation, be sure to let some of the air out of it.
