OUTDOOR DISCOVERY CRAFT
TWO MAN PONTOON BOAT
ASSEMBLY INSTRUCTIONS
Your ODC 1220 Two Man Pontoon Boat comes in two separate cartons consisting of the following parts:
FRONT FISHING FRAME
(1) Left Frame Member
(1) Right Frame Member
(1) Seat Support Frame Member
(1) Tall Seat Support Frame Member
(1) Plastic Padded Seat Back
(1) Plastic Padded Seat Bottom
(2) Seat Assembly Pins
(4) Seat Screws
(1) Leaning Bar
(1) Standing Platform
(1) Long U-Bar
(1) Under the Seat, Zippered Mesh Bag
(1) Behind the Seat, Zippered Mesh Bag
(1) Stripping Apron and Stripping Apron Waist Belt
(12) Short Snap Pins
(4) Long Snap Pins
OARS & OARLOCKS
(1) Pair 8 foot, 3 piece oars
(1) Pair bronze oarlocks, with split rings
(1) Pair Oar Stops
(2) Oarlock Bushings
WARRANTY CARD & PATCH KIT
Please take a moment to lay out all frame parts as shown in figures 1 & 2 to familiarize
ODC 1220
yourself with the frame parts of your new pontoon boat.
REAR ROWING FRAME
(1) Left Frame Member
(1) Right Frame Member
(1) Seat Support Frame Member with Underseat Lift
and Lock Anchor System Attached
1) Plastic Padded Seat Back
(1) Plastic Padded Seat Bottom
(2) Seat Assembly Pins
(4) Seat Screws
(1) Foot Brace
(1) Short U-Bar
(1) Anchor Line Storage Bag
(1) Cargo Deck (with protective bar
for shipping attached)
(10) Short Snap Pins
(2) Side Storage Pockets
(1) Rod Holder
PONTOONS
(1) Pair pontoons: Each pontoon consists of
30 oz. thermal welded cover, 420 denier nylon liner and
30 gauge PVC bladder with valve insert
and valve plate all pre-assembled.
(16) Cam-lock straps
Complete with a set of adapters
T T M M
PUMP
(1)
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Creek Company ODC 1220
Summary of Contents for Creek Company ODC 1220
- Page 1 T T M M OUTDOOR DISCOVERY CRAFT TWO MAN PONTOON BOAT ASSEMBLY INSTRUCTIONS Your ODC 1220 Two Man Pontoon Boat comes in two separate cartons consisting of the following parts: FRONT FISHING FRAME REAR ROWING FRAME (1) Left Frame Member...
-
Page 2: Frame Assembly
ODC 1220 O O U U T T D D O O O O R R D D I I S S C C O O V V E E R R Y Y C C R R A A F F T T... - Page 3 NOTE: Always inflate the Pontoons first, before attaching to frame. 1. Position inflated Pontoons under the Left and Right Frame Members with ODC 1220 logo oriented to the outside. The valve covers at top of Pontoon should fit between the Front Fishing Frame and the Rear Rowing Frame (see figure 3).
- Page 4 Figure 1a. Rowing Frame Seat Assembly Front Seat View A. Seat Support Frame Member with Underseat Lift and Back Lock Anchor Attached Bottom B. Anchor Line Storage Bag View Seat Assembly Seat Bottom Pins Seat Screw FORWARD Holes Seat Screws Lift and Lock Anchor System Rod Holder Attached Here...
- Page 5 Transom for trolling motor ODC 1220 Figure 3 Assembled ODC 1220 A . Stripping Apron Frame B. Under the Seat, Zippered Mesh Bag C. Behind the Seat, Zippered Mesh Bag Nylon Strap D. Side Storage Pocket Figure 3a Valve Insert detail E.
-
Page 6: Care And Maintenance
2. Do not store your ODC1220 in direct sunlight. 3. If you are leaving your ODC 1220 out in the sun for any amount of time, be aware that the heat can increase the pressure inside the pontoons to a dangerous level. Let some of the air out of the pontoons if the craft will be out of the water in the sun for any length of time, or if it is stored in a vehicle, etc.
