ODC XR 12
OUTDOOR DISCOVERY CRAFT
TWO MAN PONTOON BOAT
ASSEMBLY INSTRUCTIONS
Your ODC XR 12 Two Man Pontoon Boat comes in two separate cartons consisting of the following parts:
FRONT FISHING FRAME
(1) Left Frame Member
(1) Right Frame Member
(1) Seat Support Frame Member
(1) Tall Seat Support Frame Member
(1) Plastic Padded Seat Back
(1) Plastic Padded Seat Bottom
(2) Seat Assembly Pins
(4) Seat Screws
(1) Leaning Bar
(1) Standing Platform
(1) Long U-Bar
(1) Under the Seat, Zippered Mesh Bag
(1) Behind the Seat, Zippered Mesh Bag
(1) Stripping Apron and Stripping Apron Waist Belt
(12) Short Snap Pins
(4) Long Snap Pins
OARS & OARLOCKS
(1) Pair 8 foot, 3 piece oars
(1) Pair bronze oarlocks, with split rings
(1) Pair Oar Stops
(2) Oarlock Bushings
WARRANTY CARD & PATCH KIT
Please take a moment to lay out all frame parts as shown in figures 1 & 2 to familiarize
yourself with the frame parts of your new pontoon boat.
REAR ROWING FRAME
(1) Left Frame Member
(1) Right Frame Member
(1) Seat Support Frame Member with Underseat Lift
and Lock Anchor System Attached
1) Plastic Padded Seat Back
(1) Plastic Padded Seat Bottom
(2) Seat Assembly Pins
(4) Seat Screws
(1) Foot Brace
(1) Short U-Bar
(1) Anchor Line Storage Bag
(1) Ridgid Cargo Deck with Motor Mount
(with protective bar for shipping attached)
(10) Short Snap Pins
(2) Side Storage Pockets
(1) Rod Holder
PONTOONS
(1) Pair pontoons: Each pontoon consists of
30 oz. thermal welded cover, 420 denier nylon liner and
30 gauge PVC bladder with valve insert
and valve plate all pre-assembled.
(16) Cam-lock straps
Complete with a set of adapters
T T M M
T T M
M
PUMP
(1)
