Application Guidelines
Dew temperature
Example for SZ 084 to 185
Mean temperature
Example for SZ 084 to 185
30
AB237986441643en-010801
Operating conditions
The following operating diagrams show the difference between mean and dew temperature
application envelopes.
70
65
60
55
50
45
40
35
30
-25 -20 -15
70
65
60
55
50
45
40
35
30
-25 -20 -15
Dew temperature conditions
S.H. = 11.1 K
-10 0
-5
Evaporating temperature (°C)
Mean temperature conditions
S.H. = 11.1 K
-10 0
-5
Evaporating temperature (°C)
S.H. = 30 K
SUPERHEAT
5 10
S.H. = 30 K
SUPERHEAT
5 10
15 20
15 20
