Application Guidelines

SM/SZ 084-090-100-110-120

Dimensions

A: 464.5
B: 514.5
A: 508
B: 558
A: 251.9
B: 288.4
A: 141.9
B: 178.4
99.4
4 holes Ø 19.4
A: 163
B: 179
284
220
A: SM/SZ 084-090-100
B: SM/SZ 110-120
Ø 240
Ø 230
115.3
Ø 254
284
220
162.8
45°
30°
Grommet
Steel mounting sleeve
Rubber grommet
A: 381.6
B: 431.6
A: 294.5
B: 330.8
100.4
185
A: 156.7
B: 162
99
All dimensions in mm
HM 8 bolt
Lock washer
Flat washer
Nut
AB237986441643en-010801
Compressor
base plate
15.25 mm
9
