Application Guidelines

SM/SZ 185 P, X, Y version

Brazed version
SANS COMPRESSION: 29.5
/ Without compression
AVEC COMPRESSION: 28.0
/ With compression
90°
30°
Dimensions
528.5±1.2
4 holes
Ø 19.43
90°
35°
Rotolock version
650
615
153
78
SANS COMPRESSION: 29.5
/ Without compression
AVEC COMPRESSION: 28.0
/ With compression
184
156
90°
428
30°
Grommet
Lock washer
Flat washer
Steel mounting sleeve
Rubber grommet
Ø 256
215
83
81
Ø 317
345.4
279.4
4 holes
Ø 19.43
187
192
178
90°
35°
All dimensions in mm
HM 8 bolt
Compressor
base plate
28 mm
Nut
AB237986441643en-010801
187
528.5±1.2
304.8
371
13
