Summary of Contents for Supermicro SuperWorkstation SYS-531AD-I

  • Page 1 SuperWorkstation SYS-531AD-I USER’S MANUAL Revision 1.0...
  • Page 2 State of California, USA. The State of California, County of Santa Clara shall be the exclusive venue for the resolution of any such disputes. Supermicro's total liability for all claims will not exceed the price paid for the hardware product.
  • Page 3 If you have any questions, please contact our support team at: support@supermicro.com This manual may be periodically updated without notice. Please check the Supermicro website for possible updates to the manual revision level. Secure Data Deletion A secure data deletion tool designed to fully erase all data from storage devices can be found on our website: https://www.supermicro.com/about/policies/disclaimer.cfm?url=/wdl/utility/...

  • Page 4: Table Of Contents

    SuperWorkstation SYS-531AD-I User's Manual Contents Chapter 1 Introduction 1.1 Overview ..........................7 1.2 System Features ........................8 Front View ...........................8 Control Panel ........................9 Rear View ..........................10 Side View ..........................12 1.3 Motherboard Layout ......................13 Quick Reference Table ......................14 System Block Diagram ......................16 Chapter 2 Workstation Installation 2.1 Overview ..........................17...
  • Page 5 Preface 3.7 PCIe Expansion Cards .......................34 3.8 Motherboard Battery ......................34 3.9 Drives ..........................35 Hard Drives ........................35 3.10 System Cooling .........................39 Water Cooled Heatsink .....................41 Mounting the Pump ......................42 Air Flow ..........................45 Dust Filters ........................45 Power Supply ........................46 Chapter 4 Motherboard Connections 4.1 Power Connections ......................47 Power Connections ......................47 4.2 Headers and Connectors ....................49...
  • Page 6 SuperWorkstation SYS-531AD-I User's Manual System Boot Failure ......................67 Memory Errors ........................68 Losing the System Setup Configuration ................68 When the System Becomes Unstable ................68 7.3 CMOS Clear ........................70 7.4 Where to Get Replacement Components ................70 7.5 Reporting an Issue ......................70 Technical Support Procedures ..................70 Returning Merchandise for Service ...................71...

  • Page 7: Chapter 1 Introduction

    Chapter 1: Introduction Chapter 1 Introduction 1.1 Overview This chapter provides a brief outline of the functions and features of the SYS-531AD-I. It is based on the C9Z790-CG motherboard and the CSE-GS5A-754K chassis. The following provides an overview of the specifications and capabilities. System Overview Chassis CSE-GS5A-754K...

  • Page 8: System Features

    Chapter 1: Introduction 1.2 System Features The following views of the system display the main features. Refer to Appendix B for additional specifications. Front View Front Control Panel Front 5.25" Drive Bay Front 5.25" Drive Bay Front Bezel Screen Figure 1-1. Front View System Features: Front Feature Description...

  • Page 9: Control Panel

    Chapter 1: Introduction Control Panel Figure 1-2. Control Panel Control Panel Features Item Feature Description Microphone Port The microphone port allows you to connect a cable for audio input. Audio Port The audio port allows you to connect a cable for audio output. USB Ports Two universal serial bus 3.2 Gen 1 ports.

  • Page 10: Rear View

    Chapter 1: Introduction Rear View Rear I/O Ports Figure 1-3. System: Rear View System Features: Rear Feature Description Rear I/O Ports For details, see 4.3 Input/Output Ports. Add-on card slots A 750W power module...
  • Page 11 Chapter 1: Introduction Expansion Slot Locations Item Description Slot 7: PCIe 5.0 x16 Slot 5: PCIe 3.0 x1 Slot 4: PCIe 5.0 x8 (in x16) Slot 1: PCIe 3.0 x1 *Slots 4 and 7 share a x16 link. When both slots are populated, they will both run at x8. If only slot 7 is populated, it will run at x16.

  • Page 12: Side View

    Chapter 1: Introduction Side View Rear Exhaust Fan DIMM Slots CPU Cooler PCIe M.2 Slots Fans Figure 1-4. System: Side View System Features: Side Feature Description Rear Exhaust Fan One 120-mm PWM rear exhaust fan Supports 12th/13th Generation Intel® Core™ i9/i7/i5/i3 processors CPU Cooler Closed-loop water cooling (optional) One PCIe 4.0 x4 M.2 slot...

  • Page 13: Motherboard Layout

    Chapter 1: Introduction 1.3 Motherboard Layout Below is a layout of the C9Z790-CG motherboard with jumper, connector and LED locations shown. See the table on the following page for descriptions. For detailed descriptions, pinout information and jumper settings, refer to Chapter 4 or the Motherboard...

  • Page 14: Quick Reference Table

    Chapter 1: Introduction Quick Reference Table Jumper Description Default Setting CLEAR CMOS Clear CMOS Button Push Button Switch Pins 1-4: External Speaker Speaker / Buzzer Pins 3-4: Buzzer (Default) JPME2 Intel Manufacturing Mode Pins 1-2: Normal JWD1 Watch Dog Function Enable Pins 1-2: Reset POWER BUTTON Internal Power Button...
  • Page 15 Chapter 1: Introduction Connector Description 12V_PUMP_PWR1 12V 4-pin Power Connector (for CPU Liquid Cooling Pump) AUDIO FP Front Panel Audio Header Onboard Battery COM1 COM Header CPU_FAN1, CPU_FAN2 CPU_FAN1, CPU_FAN2: CPU Fan Headers SYS_FAN1 - SYS_FAN3 SYS_FAN1 - SYS_FAN3: System Fan Headers DP/HDMI Back Panel DisplayPort 1.4b / High-Definition Multimedia Interface 2.1 HD AUDIO...

  • Page 16: System Block Diagram

    Chapter 1: Introduction System Block Diagram The block diagram below shows the connections and relationships between the subsystems and major components of the overall system. PCIe5.0_x8 PCIe x16 SLOT #7 16.0GT/s PCIe4.0_x8 16.0GT/s PCIe_5.0x8 PCIe5.0_x8 32.0GT/s SVID PCIe x 8 (in x16) SLOT #4 IMVP9.1 IMVP9.1 16.0GT/s...

  • Page 17: Chapter 2 Workstation Installation

    Chapter 2: Workstation Installation Chapter 2 Workstation Installation 2.1 Overview This chapter provides advice and instructions for installing a workstation. If your system is not already fully integrated with processors, system memory etc., refer to Chapter 3 for details on installing those specific components. Caution: Electrostatic Discharge (ESD) can damage electronic components.

  • Page 18: Installing The Gpu

    Chapter 2: Workstation Installation 2.4 Installing the GPU A compatible graphics processing unit (GPU) must be installed into one of the PCIe expansion slots. If the 2.5" HDD cage is installed, the maximum supported GPU size is 320mm. If the 2.5"...

  • Page 19: Chapter 3 Maintenance And Component Installation

    Chapter 3: Maintenance and Component Installation Chapter 3 Maintenance and Component Installation This chapter provides instructions on installing and replacing main system components. To prevent compatibility issues, only use components that match the specifications and/or part numbers given. Installation or replacement of most components require that power first be removed from the system.

  • Page 20: Front Bezel

    Chapter 3: Maintenance and Component Installation Figure 3-1. Removing the Side Chassis Covers Front Bezel Remove the front bezel by pulling off the bottom first. Generally, this is only necessary when replacing the front fans. Figure 3-2. Removing the Front Bezel...

  • Page 21: Static-Sensitive Devices

    Chapter 3: Maintenance and Component Installation 3.3 Static-Sensitive Devices Electrostatic Discharge (ESD) can damage electronic com ponents. To avoid damaging your motherboard, it is important to handle it very carefully. The following measures are generally sufficient to protect the system PCBs from ESD. Precautions •...

  • Page 22: Processor And Heatsink Installation

    • Thermal grease is pre-applied on a new heatsink. No additional thermal grease is needed. • Refer to the Supermicro website for updates on processor support. • All graphics in this manual are for illustration only. Your components may look different.
  • Page 23 Chapter 3: Maintenance and Component Installation 2. Gently push down the load lever to release and lift it, then lift the load plate to open it completely. Lever lock 3. Use your thumb and your index finger to hold the CPU. Align the small triangle marker and notches on the CPU to the corresponding triangle marker and notches on the CPU load bracket.
  • Page 24 Chapter 3: Maintenance and Component Installation 6. Close the load plate with the CPU inside the socket. Gently push the load lever down until it locks under the Lever Lock latch. Lever lock Attention! You can only install the CPU inside the socket in one direction. Make sure that it is properly inserted into the CPU socket before closing the load plate.

  • Page 25: Installing A Cpu Heatsink

    Chapter 3: Maintenance and Component Installation Installing a CPU Heatsink Note 1: The installation described in this section is for reference only. The actual in- stallation steps may vary depending on the CPU heatsink model. Please refer to the heatsink instruction for more details. Note 2: Graphic draw ings included in this manual are for reference only.
  • Page 26 Chapter 3: Maintenance and Component Installation 3. Attach the backplate into the mounting holes around the CPU socket on the bottom side of the motherboard. Backplate bottom side Motherboard bottom side Mounting hole Motherboard Top side...
  • Page 27 Chapter 3: Maintenance and Component Installation 4. Apply the proper amount of thermal grease on the CPU. 5. Place the heatsink on top of the CPU so that the four mounting holes on the heatsink are aligned with those on the retention mechanism. 6.

  • Page 28: Removing A Cpu Heatsink

    Chapter 3: Maintenance and Component Installation Removing a CPU Heatsink Warning: We do not recommend that the CPU or heatsink be removed. However, if you do need to remove the heatsink, please follow the instruction below to uninstall the heatsink to avoid damaging the CPU or other components.

  • Page 29: Installation (Optional)

    Chapter 3: Maintenance and Component Installation 3.5 M.2 Installation (optional) The motherboard has three PCIe M.2 M-key sockets that support the M.2 2260/2280/22110 modules (M.2-P1 and M.2-P2), and 2260/2280 modules (M.2-C1). Refer to the illustration on the right for the locations of M.2 sockets and mounting holes.
  • Page 30 Chapter 3: Maintenance and Component Installation 3. Installation WITH pre-installed standoffs: Insert the M.2 device into the M.2 socket at a 30-degree angle and press it down. Installation WITHOUT pre-installed standoffs: Install the standoff to the intended mounting hole first. Then insert the M.2 device into the M.2 socket at a 30-degree angle and press it down.
  • Page 31 Chapter 3: Maintenance and Component Installation 5. To install the heatsink correctly, make sure Pogo Pin the pogo pin contacts are properly touching Contacts the pogo pins on the motherboard. Refer to the illustration on the right for the locations Heatsink with Pogo Pin Header LED for M.2-C1...

  • Page 32: Memory

    Chapter 3: Maintenance and Component Installation 3.6 Memory Memory Support The C9Z790-CG supports up to 128GB Unbuffered non-ECC UDIMM, DDR5-4400MT/s, in four DIMM slots. Refer to the tables below for the recommended DIMM population order and additional memory information. General Guidelines for Optimizing Memory Performance •...

  • Page 33: Dimm Installation

    Chapter 3: Maintenance and Component Installation DIMM Installation 1. Insert DIMM modules in the following order: DIMMA2, DIMMB2, then DIMMA1, DIMMB1. For the system to work properly, use memory modules of the same type and speed. Receptive Point 2. Align the DIMM module key with the receptive point on the single-latch DIMM Notch slot.

  • Page 34: Pcie Expansion Cards

    Chapter 3: Maintenance and Component Installation 3.7 PCIe Expansion Cards The SYS-531AD-I can accommodate up to two PCIe 5.0 x16 slots (supporting x16 or x8/x8) and two PCIe 3.0 x1 expansion cards. Install your graphics card into a PCIe expansion slot. Note: Slots 4 and 7 share a x16 link.

  • Page 35: Drives

    Chapter 3: Maintenance and Component Installation 3.9 Drives Hard Drives Your system might ship with hard drives installed. The chassis has two 5.25" drive bays, four 2.5" drive bays, and six bays that can hold 3.5" or 2.5" drives. • Each 5.25" bay can be fitted with a removable media drive (e.g. DVD) or a storage device (3.5"...
  • Page 36 Chapter 3: Maintenance and Component Installation Removing a Hot-Swap Drive Carrier 1. Push the release button on the carrier. 2. Swing the handle fully out. 3. Grasp the handle and use it to pull the drive carrier out of its bay. Installing a Storage Device in the 5.25"...
  • Page 37 Chapter 3: Maintenance and Component Installation Figure 3-6. Storage Device Configurations for 5.25" Bays Installing Drives into a Removable Cage You can install up to four 2.5" drives in the dedicated center cage. Also, you can install up to three 2.5" or 3.5" drives into each combination cage (upper and lower). Begin by removing power from the system as described in Section 3.1 and...
  • Page 38 Chapter 3: Maintenance and Component Installation Figure 3-8. Mounting Tray for 3.5" Drive Figure 3-9. Mounting Tray for 2.5" Drive...

  • Page 39: System Cooling

    Chapter 3: Maintenance and Component Installation 3.10 System Cooling Three 120-mm fans provide the cooling for the system (two in the front, one in the rear). Additionally, the following fan mount configurations are supported: • Front fans can be replaced with 140-mm fans. •...
  • Page 40 Chapter 3: Maintenance and Component Installation Figure 3-11. All Possible Fan Placements...

  • Page 41: Water Cooled Heatsink

    Chapter 3: Maintenance and Component Installation Water Cooled Heatsink The chassis supports a water cooled CPU heatsink. A 120-mm radiator can be placed over the rear fan. A 240-mm radiator can be place under the top of the chassis. Consult your water cooling kit instructions for installation.

  • Page 42: Mounting The Pump

    Chapter 3: Maintenance and Component Installation Mounting the Pump 1. To mount the backplate to motherboard, place the backplate (if required) on the rear of the CPU socket and secure it in place using the provided four standoffs. Standoff Figure 3-13. Mounting the Backplate to Motherboard 2.
  • Page 43 Chapter 3: Maintenance and Component Installation 3. Position pump/retention ring assembly on the CPU. Ensure the holes on the retention ring align with the standoffs, and then tighten thumb screws onto standoffs tight. Figure 3-15. Mounting the Pump to Motherboard 4.
  • Page 44 Chapter 3: Maintenance and Component Installation 5. Connect the pump power cable to a fan header on the motherboard. Figure 3-17. Connecting the Pump Power Cable...

  • Page 45: Air Flow

    Chapter 3: Maintenance and Component Installation Air Flow Verify that cables do not obstruct the cooling airflow. Dust Filters The chassis has two magnetic dust filters (one on the top and one on the bottom) and a dust filter that covers the front fans. Dust filters can be removed and cleaned to improve system air flow circulation.

  • Page 46: Power Supply

    Chapter 3: Maintenance and Component Installation Cleaning the Front Dust Filter 1. Release the filter by pushing the center of the top edge. The top pops loose. 2. Rotate the filter top downward to release it from the hinge points on the bottom. 3.

  • Page 47: Chapter 4 Motherboard Connections

    Chapter 4: Motherboard Connections Chapter 4 Motherboard Connections This section describes the connections on the motherboard and provides pinout definitions. Note that depending on how the system is configured, not all connections are required. The LEDs on the motherboard are also described here. A motherboard layout indicating component locations may be found in Chapter 1.
  • Page 48 Chapter 4: Motherboard Connections 8-Pin Power Connector JPW2 is an 8-pin 12V DC power input for the CPU that must be connected to the power supply. Refer to the table below for pin definitions. 8-pin Power Pin Definitions Pin# Definition 1 - 4 Ground 5 - 8...

  • Page 49: Headers And Connectors

    Chapter 4: Motherboard Connections 4.2 Headers and Connectors Headers Fan Headers There are five 4-pin fan headers (CPU_FAN1 - CPU_FAN2, SYS_FAN1 - SYS_FAN3) on the motherboard. Although pins 1-3 of the system fan headers are backwards compatible with the traditional 3-pin fans, the 4-pin fans are recommended to take advantage of the fan speed control.
  • Page 50 Chapter 4: Motherboard Connections Speaker Header On the JD1 Header, pins 3 and 4 are used for the internal speaker. Close pins 3 and 4 with a cap to use the onboard speaker. If you wish to use an external speaker, close pins 1-4 with a cable.
  • Page 51 Chapter 4: Motherboard Connections Addressable RGB (ARGB) LED Connection Header The motherboard has two +5V ARGB connection headers (JRLED1/2) for connection to optional ARGB LED device such as an LED strip or LED fan. If connecting to an ARGB LED fan, also connect the fan's power connector to one of the motherboard's fan headers (SYS_FAN1 - SYS_FAN3).
  • Page 52 Parallel ATA. Note: For more information on the SATA HostRAID configuration, please refer to the Intel SATA HostRAID user's guide posted on our website at https://www.supermicro.com/ support/manuals/. Front Panel Audio Header A 10-pin Audio header at AUDIO FP is supported on the motherboard. This header allows you to connect the motherboard to a front panel audio control panel, if needed.
  • Page 53 Port 80 connection. Use this header to enhance system performance and data security. Refer to the table below for pin definitions. Please go to the following link for more information on the TPM: https://www.supermicro.com/manuals/other/AOM-TPM-9670V_9670H.pdf. TPM/Port 80 Header Pin Definitions...

  • Page 54: Input/Output Ports

    Chapter 4: Motherboard Connections 4.3 Input/Output Ports Rear I/O Ports See the figure below for the locations and descriptions of the I/O ports on the rear of the motherboard. Figure 4-1. Rear I/O Ports Rear I/O Ports # Description # Description DisplayPort 1.4b USB9: USB 3.2 Gen 2x2 (20Gb, Type C) HDMI 2.1...

  • Page 55: Front Control Panel Leds

    JF1 contains header pins for various buttons and indicators that are normally located on a control panel at the front of the chassis. These connectors are designed specifically for use with Supermicro chassis. Refer to the figure below for the descriptions of the front control panel buttons and LED indicators.
  • Page 56 Chapter 4: Motherboard Connections NIC1/NIC2 (LAN1/LAN2) LED The Network Interface Controller (NIC) LED connection for LAN1/LAN2 is located on pins 9/11 and 10/12 of JF1. Attach an LED indicator to this header to display network activity. Refer to the table below for pin definitions. NIC1/NIC2 LED Pin Definitions (JF1) Pin#...

  • Page 57: Jumpers

    Chapter 4: Motherboard Connections 4.4 Jumpers Explanation of Jumpers To modify the operation of the motherboard, jumpers can be used to choose between optional settings. Jumpers create shorts between two pins to change the function of the connector. Pin 1 is identified with a square solder pad on the printed circuit board. Refer to the diagram below for an example of jumping pins 1 and 2.
  • Page 58 Chapter 4: Motherboard Connections Manufacturing Mode Close pins 2 and 3 of JPME2 to bypass SPI flash security and force the system to operate in Manufacturing Mode, allowing you to flash the system firmware from a host server for system setting modifications.

  • Page 59: Led Indicators

    Device detected Green: Blinking Device Working BIOS POST Code LED LED4 is made up of two alpha-numeric displays that will display a status or BIOS POST code, when the motherboard is powered on. For more information, refer to https://www.supermicro. com/manuals/other/AMI_AptioV_BIOS_POST_Codes_for_SM_Motherboards.pdf.
  • Page 60 Chapter 4: Motherboard Connections Power LED An onboard power LED is located at LED1 on the motherboard. When LED1 is on, the AC power cable is connected. Make sure to disconnect the power cable before removing or installing any component. Refer to the tables below for more information. Power LED Indicator LED Status Status...

  • Page 61: Chapter 5 Software

    USB/SATA DVD drive, or a USB flash drive, or the BMC KVM console. 2. Retrieve the proper RST/RSTe driver. Go to the Supermicro web page for your motherboard and click on "Download the Latest Drivers and Utilities", select the proper driver, and copy it to a USB flash drive.
  • Page 62 Chapter 5: Software 4. During Windows Setup, continue to the dialog where you select the drives on which to install Windows. If the disk you want to use is not listed, click on “Load driver” link at the bottom left corner. Figure 5-2.

  • Page 63: Driver Installation

    The Supermicro website contains drivers and utilities for your system at https://www. supermicro.com/wdl/. Some of these must be installed, such as the chipset driver. After accessing the website, go into the CDR_Images (in the parent directory of the above link) and locate the ISO file for your motherboard. Download this file to a USB flash drive or a DVD.

  • Page 64: Superdoctor ® 5

    5.3 SuperDoctor ® The Supermicro SuperDoctor 5 is a program that functions in a command-line or web-based interface for Windows and Linux operating systems. The program monitors such system health information as CPU temperature, system voltages, system power consumption, fan speed, and provides alerts via email or Simple Network Management Protocol (SNMP).

  • Page 65: Chapter 6 Optional Components

    Chapter 6: Optional Components Chapter 6 Optional Components This chapter describes optional system components and installation procedures. 6.1 Optional Parts List Optional Parts List Description Part Number High Performance Active CPU Heat Sink SNK-P0086AP4 High Performance Close-looped Liquid Cooling Kit for the CPU SNK-P3017A Black LITE-ON 5.25"...

  • Page 66: Chapter 7 Troubleshooting And Support

    Chapter 7 Troubleshooting and Support 7.1 Information Resources Website A great deal of information is available on the Supermicro website, supermicro.com. Figure 7-1. Supermicro Website • Specifications for servers and other hardware are available by clicking the menu icon, then selecting the Products option.

  • Page 67: Troubleshooting Procedures

    Chapter 7: Troubleshooting and Support 7.2 Troubleshooting Procedures Use the following procedures to troubleshoot your system. If you have followed all of the procedures below and still need assistance, refer to the Technical Support Procedures Returning Merchandise for Service section(s) in this chapter. Power down the system before changing any non hot-swap hardware components.

  • Page 68: Memory Errors

    Chapter 7: Troubleshooting and Support • Remove all components from the motherboard, especially the DIMM modules. Make sure that system power is on and that memory error beeps are activated. • Turn on the system with only one DIMM module installed. If the system boots, check for bad DIMM modules or slots by following the Memory Errors Troubleshooting procedure in this chapter.
  • Page 69 Chapter 7: Troubleshooting and Support Note: Refer to the product page on our website at http://www.supermicro.com for memory and CPU support and updates. • HDD support: Make sure that all hard disk drives (HDDs) work properly. Replace the bad HDDs with good ones.

  • Page 70: Cmos Clear

    7.4 Where to Get Replacement Components If you need replacement parts for your system, to ensure the highest level of professional service and technical support, purchase exclusively from our Supermicro Authorized Distributors/System Integrators/Resellers. A list can be found at: http://www.supermicro.com.

  • Page 71: Returning Merchandise For Service

    For issues related to Red Hat Enterprise Linux, since it is a subscription based OS, contact your account representative. 7.6 Feedback Supermicro values your feedback as we strive to improve our customer experience in all facets of our business. To provide feedback on our manuals, please email us at techwriterteam@...

  • Page 72: Contacting Supermicro

    San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) Sales-USA@supermicro.com (Sales Inquiries) Government_Sales-USA@supermicro.com (Gov. Sales Inquiries) support@supermicro.com (Technical Support) RMA@supermicro.com (RMA Support) Webmaster@supermicro.com (Webmaster) Website: www.supermicro.com Europe Address: Super Micro Computer B.V.

  • Page 73: Appendix A Standardized Warning Statements For Ac Systems

    Supermicro's Technical Support department for assistance. Only certified technicians should attempt to install or configure components. Read this appendix in its entirety before installing or configuring components in the Supermicro chassis. These warnings may also be found on our website at http://www.supermicro.com/about/...
  • Page 74 Appendix A: Standardized Warning Statements for AC Systems Warnung WICHTIGE SICHERHEITSHINWEISE Dieses Warnsymbol bedeutet Gefahr. Sie befinden sich in einer Situation, die zu Verletzungen führen kann. Machen Sie sich vor der Arbeit mit Geräten mit den Gefahren elektrischer Schaltungen und den üblichen Verfahren zur Vorbeugung vor Unfällen vertraut. Suchen Sie mit der am Ende jeder Warnung angegebenen Anweisungsnummer nach der jeweiligen Übersetzung in den übersetzten Sicherheitshinweisen, die zusammen mit diesem Gerät ausgeliefert wurden.
  • Page 75 Appendix A: Standardized Warning Statements for AC Systems . ٌ ‫ا ك ً ف حالة و ٌ يك أى تتسبب ف اصابة جسذ ة ٌ هذا الزهز ع ٌ خطز !تحذ ز‬ ‫قبل أى تعول عىل أي هعذات،يك عىل علن بالوخاطز ال ا ٌجوة عي الذوائز‬ ٍ...
  • Page 76 Appendix A: Standardized Warning Statements for AC Systems Warnung Vor dem Anschließen des Systems an die Stromquelle die Installationsanweisungen lesen. ¡Advertencia! Lea las instrucciones de instalación antes de conectar el sistema a la red de alimentación. Attention Avant de brancher le système sur la source d'alimentation, consulter les directives d'installation. .‫יש...
  • Page 77 Appendix A: Standardized Warning Statements for AC Systems Warnung Dieses Produkt ist darauf angewiesen, dass im Gebäude ein Kurzschluss- bzw. Überstromschutz installiert ist. Stellen Sie sicher, dass der Nennwert der Schutzvorrichtung nicht mehr als: 250 V, 20 A beträgt. ¡Advertencia! Este equipo utiliza el sistema de protección contra cortocircuitos (o sobrecorrientes) del edificio.
  • Page 78 Appendix A: Standardized Warning Statements for AC Systems Power Disconnection Warning Warning! The system must be disconnected from all sources of power and the power cord removed from the power supply module(s) before accessing the chassis interior to install or remove system components. 電源切断の警告...
  • Page 79 Appendix A: Standardized Warning Statements for AC Systems ‫אזהרה מפני ניתוק חשמלי‬ ‫!אזהרה‬ ‫יש לנתק את המערכת מכל מקורות החשמל ויש להסיר את כבל החשמלי מהספק‬ ‫.לפני גישה לחלק הפנימי של המארז לצורך התקנת או הסרת רכיבים‬ ‫يجب فصم اننظاو من جميع مصادر انطاقت وإ ز انت سهك انكهرباء من وحدة امداد‬ ‫انطاقت...
  • Page 80 Appendix A: Standardized Warning Statements for AC Systems Attention Il est vivement recommandé de confier l'installation, le remplacement et la maintenance de ces équipements à des personnels qualifiés et expérimentés. !‫אזהרה‬ .‫צוות מוסמך בלבד רשאי להתקין, להחליף את הציוד או לתת שירות עבור הציוד‬ ‫واملدربيه...
  • Page 81 Appendix A: Standardized Warning Statements for AC Systems Warnung Diese Einheit ist zur Installation in Bereichen mit beschränktem Zutritt vorgesehen. Der Zutritt zu derartigen Bereichen ist nur mit einem Spezialwerkzeug, Schloss und Schlüssel oder einer sonstigen Sicherheitsvorkehrung möglich. ¡Advertencia! Esta unidad ha sido diseñada para instalación en áreas de acceso restringido. Sólo puede obtenerse acceso a una de estas áreas mediante la utilización de una herramienta especial, cerradura con llave u otro medio de seguridad.
  • Page 82 Appendix A: Standardized Warning Statements for AC Systems Battery Handling Warning! There is the danger of explosion if the battery is replaced incorrectly. Replace the battery only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer's instructions 電池の取り扱い...
  • Page 83 Appendix A: Standardized Warning Statements for AC Systems ‫هناك خطر من انفجار يف حالة اسحبذال البطارية بطريقة غري صحيحة فعليل‬ ‫اسحبذال البطارية‬ ‫فقط بنفس النىع أو ما يعادلها مام أوصث به الرشمة املصنعة‬ ‫جخلص من البطاريات املسحعملة وفقا لحعليامت الرشمة الصانعة‬ 경고! 배터리가...
  • Page 84 Appendix A: Standardized Warning Statements for AC Systems ¡Advertencia! Puede que esta unidad tenga más de una conexión para fuentes de alimentación. Para cortar por completo el suministro de energía, deben desconectarse todas las conexiones. Attention Cette unité peut avoir plus d'une connexion d'alimentation. Pour supprimer toute tension et tout courant électrique de l'unité, toutes les connexions d'alimentation doivent être débranchées.
  • Page 85 Appendix A: Standardized Warning Statements for AC Systems Backplane Voltage Warning! Hazardous voltage or energy is present on the backplane when the system is operating. Use caution when servicing. バックプレーンの電圧 システムの稼働中は危険な電圧または電力が、 バックプレーン上にかかっています。 修理する際には注意く ださい。 警告 当系统正在进行时，背板上有很危险的电压或能量，进行维修时务必小心。 警告 當系統正在進行時，背板上有危險的電壓或能量，進行維修時務必小心。 Warnung Wenn das System in Betrieb ist, treten auf der Rückwandplatine gefährliche Spannungen oder Energien auf.
  • Page 86 Appendix A: Standardized Warning Statements for AC Systems ‫هناك خطز مه التيار الكهزبايئ أوالطاقة املىجىدة عىل اللىحة‬ ‫عندما يكىن النظام يعمل كه حذ ر ا عند خدمة هذا الجهاس‬ 경고! 시스템이 동작 중일 때 후면판 (Backplane)에는 위험한 전압이나 에너지가 발생 합니다. 서비스...
  • Page 87 Appendix A: Standardized Warning Statements for AC Systems ‫תיאום חוקי החשמל הארצי‬ !‫אזהרה‬ .‫התקנת הציוד חייבת להיות תואמת לחוקי החשמל המקומיים והארציים‬ ‫تركيب املعدات الكهربائية يجب أن ميتثل للقىاويه املحلية والىطىية املتعلقة‬ ‫بالكهرباء‬ 경고! 현 지역 및 국가의 전기 규정에 따라 장비를 설치해야 합니다. Waarschuwing Bij installatie van de apparatuur moet worden voldaan aan de lokale en nationale elektriciteitsvoorschriften.
  • Page 88 Appendix A: Standardized Warning Statements for AC Systems Attention La mise au rebut ou le recyclage de ce produit sont généralement soumis à des lois et/ou directives de respect de l'environnement. Renseignez-vous auprès de l'organisme compétent. ‫סילוק המוצר‬ !‫אזהרה‬ .‫סילוק סופי של מוצר זה חייב להיות בהתאם להנחיות וחוקי המדינה‬ ‫التخلص...
  • Page 89 Appendix A: Standardized Warning Statements for AC Systems Warnung Gefährlich Bewegende Teile. Von den bewegenden Lüfterblätter fern halten. Die Lüfter drehen sich u. U. noch, wenn die Lüfterbaugruppe aus dem Chassis genommen wird. Halten Sie Finger, Schraubendreher und andere Gegenstände von den Öffnungen des Lüftergehäuses entfernt.
  • Page 90 Verbindungskabeln, Stromkabeln und/oder Adapater, die Ihre örtlichen Sicherheitsstandards einhalten. Der Gebrauch von anderen Kabeln und Adapter können Fehlfunktionen oder Feuer verursachen. Die Richtlinien untersagen das Nutzen von UL oder CAS zertifizierten Kabeln (mit UL/CSA gekennzeichnet), an Geräten oder Produkten die nicht mit Supermicro gekennzeichnet sind.
  • Page 91 ‫.قيرح وأ لطع يف ببستي دق ىرخأ تالوحمو تالباك يأ مادختسا .ميلسلا سباقلاو لصوملا مجح‬ ‫ لبق نم ةدمتعملا تالباكلا مادختسا تادعملاو ةيئابرهكلا ةزهجألل ةمالسلا نوناق رظحي‬UL ‫ وأ‬CSA ‫( ةمالع لمحت يتلاو‬UL/CSA) ‫ لبق نم ةددحملاو ةينعملا تاجتنملا ريغ ىرخأ تادعم يأ عم‬Supermicro.
  • Page 92 사항을 준수하여 제공되거나 지정된 연결 혹은 구매 케이블, 전원 케이블 및 AC 어댑터를 사용하십시오. 다른 케이블이나 어댑터를 사용하면 오작동이나 화재가 발생할 수 있습니다. 전기 용품 안전법은 UL 또는 CSA 인증 케이블 (코드에 UL / CSA가 표시된 케이블)을 Supermicro 가 지정한 제품 이외의 전기 장치에 사용하는 것을 금지합니다. Stroomkabel en AC-Adapter...

  • Page 93: Appendix B System Specifications

    Appendix B: System Specifications Appendix B System Specifications Processors Supports 12th/13th Generation Intel® Core™ i9/i7/i5/i3 Note: Refer to the motherboard specifications pages on our website for updates to supported processors. Chipset Intel® Z790 BIOS 256Mb SPI Flash with AMI BIOS Memory Supports up to 128GB unbuffered non-ECC UDIMM, DDR5 4400MT/s, in four DIMM slots SATA Controller...
  • Page 94 Appendix B: System Specifications Operating Environment Operating Temperature: 10º to 30º C (50º to 86º F) Non-operating Temperature: -40º to 60º C (-40º to 140º F) Operating Relative Humidity: 8% to 80% (non-condensing) Non-operating Relative Humidity: 5% to 95% (non-condensing) Regulatory Compliance FCC, CE, VCCI, CSA/ UL, CB Applied Directives, Standards...

  • Page 95: Appendix C Bsmi Rohs Certification

    Appendix C: BSMI RoHS Certification Appendix C BSMI RoHS Certification 限 限 用 用 物 物 質 質 含 含 有 有 情 情 況 況 標 標 示 示 聲 聲 明 明 書 書 Declaration of the Presence Condition of the Restricted Substances Marking 設備名稱: 工作站...
  • Page 96 Appendix C: BSMI RoHS Certification 輸入額定: 100-240V ~, 60-50Hz, 10-5A *使用者不能任意拆除或替換內部配備 *報驗義務人之姓名或名稱：美超微電腦股份有限公司 *報驗義務人之地址：新北市中和區建一路 150 號 3 樓...
