- Page 1 USER MANUAL – EN IN 22961 Handles for Verticon inSPORTline Pro 1000...
- Page 2 Step 1 Use a 6 mm Allen key to remove the M8x20L bolt. Step 2 Attach the handles with the supplied M8x25L bolts, do not tighten yet.
- Page 3 Step 3 Place the device on the ground. Step 4 Remove the leveling feet. Use an 8 mm Allen key to remove the 4x M10 bolts from the base.
- Page 4 Step 5 Assemble all 3 parts of the handles and then attach to the sides of the machine. Step 6 Attach the handles to the bottom with M10x20L bolts, spring washers and flat washers. Attach the leveling feet. Do not tighten yet.
- Page 5 Step 7 Use a 6 mm Allen key and M8x20L bolts and washers to connect the handles. Do not tighten yet. Step 8 Tighten the M10x20L bolts with an 8 mm Allen key and leveling foot.
- Page 6 Step 9 Position the device and tighten the M8x25L screw with a 6 mm Allen key. Step 10 Tighten all M10 bolts with an 8 mm Allen key. Note: if you need to adjust the height of the leveling feet, adjust the M10 nuts with a wrench.
- Page 7 ENVIRONMENT PROTECTION After the product lifespan expired or if the possible repairing is uneconomic, dispose it according to the local laws and environmentally friendly in the nearest scrapyard. By proper disposal you will protect the environment and natural sources. Moreover, you can help protect human health.
