Machine Specifications

Total Weight and Size VR3 Arm Curl 12070 Standard Stack
Weight
425 Lbs 58" L x 40" W x 64" H
193 Kg 147 cm L x 102 cm W x 162 cm H
Total Weight and Size VR3 Arm Curl 12070 Heavy Stack
Weight
465 Lbs 58" L x 40" W x 64" H
211 Kg 147 cm L x 102 cm W x 162 cm H
Maximum User Weight
300 lbs/135 kg

Choosing and Preparing a Site

Before assembling the unit, verify the chosen site meets the following criteria:
Area is well lit and well ventilated.
•
Surface is structurally sound and properly leveled.
•
Free area for access to unit and emergency dismount. Minimum clearance is 23.6 inches
•
(0.6 meters).
Adjacent units may share the free area.
•
It is the responsibility of the facility owner/owner of the equipment to ensure that there is appropriate
clearance around each machine to allow for safe use and passage.
Cybex Owner's Manual

Assembly

Machine Dimensions at Rest
Machine Dimensions at Rest
Machine Dimensions in Use
63" L x 42" W x 64" H
160 cm L x 107 cm W x 162 cm H
Machine Dimensions in Use
63" L x 42" W x 64" H
160 cm L x 107 cm W x 162 cm H
Maximum Training Weight
205 lbs/93 kg
