- Page 1 Dip Chin ® Owner’s Manual Strength Systems Part Number 12231-999-4 G www.cybexintl.com...
- Page 2 ® DISCLAIMER: Cybex International, Inc., makes no representations or warranties regarding the contents of this manual. We reserve the right to revise this document at any time or to make changes to the product described within it without notice or obligation to notify any person of such revisions or changes.
- Page 3 • equipment must be anchored to a solid, level surface, utilizing all anchoring holes provided. Fasteners must have a minimum of 500 lbs. tensile capacity. Cybex • recommends .3/8” grade 2 bolts or better. A minimum pull force of 220 lbs/100 kgs is required for each anchor position.
- Page 4 Use only Cybex components to maintain and repair the equipment. Display the Facility Safety Sign so it is visible and prominent.
- Page 5 Cybex Owner’s Manual DO NOT lean or pull on machine • DO NOT use machine for support during stretching. • DO NOT attach resistance straps, ropes or other means to equipment, except those provided by • the manufacturer for intended use on the equipment.
- Page 6 Cybex Owner’s Manual Warnings and Cautions Warning decals indicate a potentially hazardous situation that could result in death or serious injury if the precautions are not observed. Caution decals indicate a potentially hazardous situation that could result in minor or moderate injury if the precautions are not observed.
- Page 7 Cybex Owner’s Manual Label Placement 12230-352-X DE000001-X DE000005-X DE000004-X...
- Page 8 Cybex Owner’s Manual Assembly Machine Specifications Total Weight and Size VR3 Dip/Chin Assist 12231 Standard Stack Weight Machine Dimensions at Rest Machine Dimensions in Use 720 Lbs 62” L x 55” W x 98” H Same 327 Kg 157 cm L x 139 cm W x 248 cm H...
- Page 9 Cybex Owner’s Manual The dimensions stated in the assembly instructions of this manual include the maximum foot print (in use) dimensions. Area is not in the vicinity of high humidity, such as in the vicinity of a steam room, sauna, indoor •...
- Page 10 Cybex Owner’s Manual Move to desired location Then Two people will be required for this procedure If machine can be 1. Move to desired location. moved without adding or removing 2. Remove the four shipping cones using a 3/4” socket or wrench.
- Page 11 1. Remove the four shipping cones using a 3/4” socket or wrench. 2. Attach foot pads to each foot of frame. WARNING: Anchoring equipment: Cybex is not responsible for the actual anchoring of equipment. Consult with a • professional contractor.
- Page 12 Cybex Owner’s Manual Install support leg 1. Align holes of support leg with holes on frame. Push BHSCS (supplied in kit) through holes of support leg and frame. Lower Bracket BHSCS .375-16 x 2.50 (4) Support Leg Locknut (4) 2. Place lower bracket on BHSCS from step.
- Page 13 Cybex Owner’s Manual 3. Slide belt through slot in belt clamp. 4. Verify belt and insert are installed properly. Do not install the insert backwards. Correct belt routing Wrong belt routing Insert Insert Belt Belt Stem Stem 5. Pull belt through clamp until input arm measures 31” from floor. Measure from floor to lower edge of caution decal (located on foot bar).
- Page 14 Cybex Owner’s Manual Install weight plate decals 1. Peel off back side of decal making sure that the decals remain attached to the front sticker. Front Back 2. Insert a guide pin through each hole of the template. A guide pin can be anything that fits through the weight stack hole, such as a weight stack selector pin.
- Page 15 Cybex Owner’s Manual Exercise Intended Use The intended commercial use of this machine is to aid exercise and improve general physical fitness. Instructions Read and understand all instructions and warnings prior to using this machine in the Safety section of the Owner’s Manual.
- Page 16 Do Not inhale or swallow any cleaning product. Protect surrounding area/clothing from exposure. Use in well ventilated area. Follow all product manufacturer’s warnings. Cybex and its vendors cannot be held responsible for damage or injuries resulting from the use or misuse of...
- Page 17 Cybex Owner’s Manual Clean Upholstery Then Prepare a solution of 10% household liquid soap and warm water. Apply with a soft damp cloth. If necessary, apply a solution of liquid Light Soiling cleanser with a soft bristle brush. Dampen a clean soft cloth in water and wipe residue away.
- Page 18 Cybex Owner’s Manual Guidelines for cleaning front panel: Use clean soft cloths or sponges for application of cleaners and again for washing and rinsing. Follow up each application with warm water rinse. DO NOT use abrasives or high alkaline cleaners.
- Page 19 Cybex Owner’s Manual WARNING: Equipment hazard. To avoid serious injury or death replace worn or damaged components immediately and keep the equipment out of use until repair is completed. Inspect cables and belts Inspect all cables and belts for wear or damage and proper tension. When inspecting cables and belts, run fingers on the cable or belt, paying particular attention to bends in cables and attachment points.
- Page 20 Cybex Owner’s Manual Belts Condition of Belt 3D View 3D or Side View Peeling of the belt’s skin. Wave in belt Replace belt if any Examine edge of belt (both sides). section is over 1/32” Replace belt if any section is (.03) narrower than the...
- Page 21 Cybex Owner’s Manual CAUTION: Worn handles Do not use handles if less then 1/8” of material remains on edge. • Replace all worn handles immediately. • Inspect bars and handles for wear, paying particular attention to tab area connection points.
- Page 22 Cybex Owner’s Manual Cable Adjustment Tools Required 9/16” Wrench (2) Four types of cable tension adjustment are used on Cybex Strength Systems: Cable Description Diagram Adjustment This type of adjustment uses a jam nut and a tension adjustment nut at...
- Page 23 Cybex Owner’s Manual Belt Adjustment Tools Required 7/32” Wrench • Torque wrench (lbs-in) • Belt Adjustment Action Using a 7/32” Allen wrench loose set screws. Pull belt tight. Secure belt in place with set screws. Torque set screws to 300-350 lb-in.
- Page 24 To speak with a customer service representative, call 888-462-9239 (for customers living within the USA) or 508-533-4300 (for customers outside the USA). The following information located on the serial number decal will assist our Cybex representatives in serving you. Unit Serial Number, Product Name and Model Number •...
- Page 25 Provide the model and serial number of your Cybex equipment. At Cybex’s discretion, the technician may request that you return the problem part(s) to Cybex for evaluation and repair or replacement. The technician will assign you a RMA number and will send you an ARS label.
- Page 28 10 Trotter Drive Medway, MA 02053 508-533-4300 FAX 508-533-5183 • • www.cybexintl.com...
