Auto‑Image setup — Automatically optimizes the image by analyzing and adjusting
•
to the video input signal. This can save time and effort in setting up a newly connected
source, particularly in presentation environments where different guest presenter laptops
with various output resolutions will be connected.
• Auto Input Memory — When activated, the unit automatically stores size, position,
and picture settings based on the incoming signal. When the same signal is detected
again, these image settings are automatically recalled from memory.
• Input presets — Memory presets are available to store and recall image settings.
Layout presets — Memory presets are available to store and recall user settings. This
•
provides a quick method to set up content Preview in anticipation of transitioning it to
the Program output.
• Output mute — Allows independent muting for Preview and Program output signals.
• Output freeze — Provides independent freeze control of the Program and Preview
output signals. Frozen content can be switched to the Program output using any
transition effect.
• User‑selectable HDCP authorization — Allows each HDMI input to appear HDCP
compliant or non-HDCP compliant to the connected source, which is beneficial if the
source automatically encrypts all content when connected to an HDCP-compliant
device. Protected material is not passed in non-HDCP mode.
• HDCP Visual Confirmation provides a green signal when encrypted content
is sent to a non‑compliant display — A green window with an alert message is
displayed when HDCP-encrypted content is transmitted to a non-HDCP compliant
display, providing immediate visual confirmation that protected content cannot be
viewed on the display.
Key Minder continuously verifies HDCP compliance for quick, reliable
•
switching — Key Minder authenticates and maintains continuous HDCP encryption
between input and output devices to ensure quick and reliable switching in professional
AV environments, while enabling simultaneous distribution of a single source signal to
one or more displays.
SpeedSwitch Technology delivers virtually instantaneous switching speeds for
•
HDCP‑encrypted content.
• EDID Minder automatically manages EDID communication between connected
devices — EDID Minder ensures that all sources power up properly and reliably output
content for display.
EDID capture mode — EDID information can be captured and stored from connected
•
Program and Preview display devices.
• Comprehensive picture controls for Preview and Program output buses — Fine
tune displayed content with picture controls for brightness, contrast, sizing, positioning,
and zoom.
Internal video test patterns and pink noise generator for calibration and setup
•
— The ISS offers several video test patterns and audio pink noise to facilitate proper
system setup and calibration of display devices.
Audio management — Embedded two-channel digital audio can be extracted from
•
any input and sent to the Preview and Program analog audio outputs. Multi-channel
audio formats can be passed to the Preview and Program HDMI outputs.
Easy setup and commissioning with Extron PCS ‑ Product Configuration
•
Software — Convenient configuration and preset design from a single easy-to-use
software application.
