GAMING CHAIRS
ASSEMBLY INSTRUCTIONS
(General representation of our gaming
chairs. The styles, materials, colors and
features vary with series and models)
Thank you for purchasing our product
REV.ZK-7369-0523
ProGamer2
GameMaster
Cow Print
Gamer XL
SERIES
MODELS
Echo
TSF44
TS42
Lux
TSF45
GG
TS51
TS43
TS90
TS92
TS83
TS85
Pastel
TS86
TSXL3

Advertisement

loading
Need help?

Need help?

Do you have a question about the Echo Series and is the answer not in the manual?

Questions and answers

Related Manuals for Techni Sport Echo Series

Summary of Contents for Techni Sport Echo Series

  • Page 1 GAMING CHAIRS ASSEMBLY INSTRUCTIONS REV.ZK-7369-0523 SERIES MODELS Echo TSF44 TS42 TSF45 TS51 TS43 ProGamer2 TS90 TS92 GameMaster TS83 Cow Print TS85 Pastel TS86 Gamer XL TSXL3 (General representation of our gaming chairs. The styles, materials, colors and features vary with series and models) Thank you for purchasing our product...

  • Page 2: Main Parts List

    TS42, TS43, TS51, TS83, TS85, TS86, TS90, TS92, TSF44, TSF45, TSXL3 For Support, assembly questions Replacement Parts for International Do a quick inventory & Replacement Parts within the Customers & AK-HI-PR orders: of all the parts and 48 Contiguous United States: RTA Products will replace the part free of hardware listed below.
  • Page 3 TS42, TS43, TS51, TS83, TS85, TS86, TS90, TS92, TSF44, TSF45, TSXL3 BEFORE YOU START THE ASSEMBLY, PLEASE READ THE FOLLOWING TIPS AND WARNINGS. • Do not discard this manual or any of the packaging material until the unit is completely assembled. •...

  • Page 4: Assembly Steps

    TS42, TS43, TS51, TS83, TS85, TS86, TS90, TS92, TSF44, TSF45, TSXL3 ASSEMBLY STEPS STEP 1 Flip over the seat B and place the felt gaskets Q over the innermost holes in the Hardware middle and back of the frame. Place the mechanism D over the felt gaskets, making sure its tension knob M8x20 faces towards the FRONT.
  • Page 5 TS42, TS43, TS51, TS83, TS85, TS86, TS90, TS92, TSF44, TSF45, TSXL3 STEP 4 STEP 5 Assemble the backrest A to the metal Hardware brackets on the seat B with screws M, Join the base parts to the seat making O-rings O and washers P, making sure sure the tip of the lift E enters correctly the O-ring go in the middle of the into the hole of the mechanism D.

  • Page 6: Care And Maintenance

    TS42, TS43, TS51, TS83, TS85, TS86, TS90, TS92, TSF44, TSF45, TSXL3 CHAIR'S FUNCTIONS To raise or lower the chair’s height, pull UP the lever that is under the seat on the right side. The chair goes down while sitting on it, or up if you lift your body. The chair also tilts by pulling OUT the same lever to unlock, but please note that unlike regular chairs, gaming chairs have their balance centered farther back, so the chair feels harder to tilt.
  • Page 7 2-YEAR WARRANTY 5-YEAR WARRANTY LIFETIME WARRANTY RTA Products, LLC has warranted the Techni Sport products to the original purchaser who acquired a new product from RTA Products or its authorized re-sellers of the product against defects in material or workmanship.

This manual is also suitable for:

Lux seriesGg seriesProgamer2 seriesGamemaster seriesCow print seriesPastel series ... Show all
