- Page 1 ASSEMBLY INSTRUCTIONS Thank you for purchasing our product. SERIES MODELS Echo TSF44 TS43 TS90 ProGamer2 TS92 TS51 TS52 Luxx TS85 TS83 GameMasters TS84 GamerXL TSXXL2 REV.ZK-1021-4...
-
Page 2: Main Parts List
TS43, TS51, TS52, TS83, TS84, TS85, TS90, TS92, TSF44, TSXXL2 MAIN PARTS LIST Backrest Hydraulic Seat 5-Leg star Mechanism base gas lift Nylon: TS43, TS85, TS90, TS92 & TSF44 Metal: TS51, TS52, TS83, TS84 & TSXXL2 Left cover for Casters Left Right Covers for... - Page 3 TS43, TS51, TS52, TS83, TS84, TS85, TS90, TS92, TSF44, TSXXL2 BEFORE YOU START THE ASSEMBLY, PLEASE READ THE FOLLOWING TIPS AND WARNINGS. ❶ ❻ Do a quick inventory to Make sure you make sure the package understand which hardware contains all the parts and will be used on each step.
-
Page 4: Assembly Steps
TS43, TS51, TS52, TS83, TS84, TS85, TS90, TS92, TSF44, TSXXL2 ASSEMBLY STEPS STEP 1 Insert the casters F into the legs of the base C using pressure, then place the gas lift E in the middle of the base and cover it with H. STEP 2 Flip over the seat B with its front towards your LEFT, and place the... - Page 5 TS43, TS51, TS52, TS83, TS84, TS85, TS90, TS92, TSF44, TSXXL2 STEP 4 STEP 5 Put the seat over the Assemble the backrest base parts making sure A to the brackets on the Hardware the tip of the gas lift E seat B with screws M, enters into the hole of O-rings O and washers...
-
Page 6: Care And Maintenance
TS43, TS51, TS52, TS83, TS84, TS85, TS90, TS92, TSF44, TSXXL2 CHAIR’S FUNCTIONS • Chairs’ height: Pull UP the lever under the seat. The chair goes down while sitting on it, or up if you lift your body. • Seat tilting: Pull the same lever OUT horizontally to unlock this function, and IN to lock again. NOTE: Unlike regular office chairs, the racing/gaming chairs have their base components off- center, and the tilting won’t be much and might actually feel hard to tilt. - Page 7 Gaming Desk: 5-YEAR WARRANTY Gaming Chair Metal Frame: LIFETIME WARRANTY RTA Products, LLC has warranted the Techni Sport products to the original purchaser who acquired a new product from RTA Products or its authorized re-sellers of the product against defects in material or workmanship.
- Page 8 TS43, TS51, TS52, TS83, TS84, TS85, TS90, TS92, TSF44, TSXXL2 SUPPORT OPTIONS: • Assembly questions • Damage issues • Replacement parts _________________________________________________________________ TECHNISPORTUSA.COM GO TO: CLICK ON SUPPORT TAB _________________________________________________________________ Scan QR Code to order replacement parts _________________________________________________________________ CONTACT US BY EMAIL: SUPPORT@TECHNISPORTUSA.COM...
