Troubleshooting
If the unit is not functional - check that the main power supply is ʻonʼ and check fuses.
If the unit is functional but lamps do not light - the lamps may require replacing.
If after trying the above, you still have a problem contact CHAUVET.
Caution
Do not obstruct the air vents.
Do not touch unit or lamps while hot.
No user serviceable parts inside. Please refer to CHAUVET for service.
Power Connections
The unit is supplied with a power plug appropriate to its voltage and destination. Should any other connec-
tions be required, they must be carried out with the following configuration.
Earth = Green/Yellow cable
Neutral = Blue cable
Live = Brown cable
In the USA & Europe, it is required that all plugs are 3-pin type i.e. with Earth/Ground connection.
In the UK, it is required that all mains plugs are fitted with 5A fuses.
Technical Specifications
Power:
120V~60Hz AC
Fuse:
20mm Glass 4A Fast Blow
Lamps:
2 x 12V 100W
Part No EFP 12V 100W
Dimensions:
635 x 152 x 229mm
25 x 6 x 9in
Weight:
6.4kg / 14lbs
User Information (Please complete for your records)
Date Purchased:
/
/
Dealer Stamp:
230V~50Hz AC
20mm Glass 2A Fast Blow
2 x 12V 100w
Part No EFP 12V 100W
Serial No: ________________
Model: CH-425 Slasher
Slasher
CH-425
User Guide
Please read these instructions carefully before use
World-wide Headquarters:
3000 North 29th Ct.
Hollywood, Florida, USA 33020
Tel: +1-954-929-1115 Fax: +1-954-929-5560
www.ChauvetLighting.com
