CCE4503 Evaluation Board
1. ABSTRACT
The CCE4503 evaluation board is designed to evaluate and demonstrate the CCE4503 IO-Link Device IC.
Contents
1.
ABSTRACT ..................................................................................................................................................... 1
2.
INTRODUCTION ............................................................................................................................................. 2
3.
SYSTEM REQUIREMENTS ............................................................................................................................ 2
4.
FEATURE OVERVIEW ................................................................................................................................... 3
5.
GETTING STARTED ....................................................................................................................................... 3
6.
POWER SUPPLY ............................................................................................................................................ 3
7.
SECTIONS OF THE CCE4503 EVALUATION BOARD ................................................................................. 4
IO-Link Section ................................................................................................................................................ 4
Sensor Section................................................................................................................................................. 4
Temperature Sensor .............................................................................................................................. 4
Color Sensor .......................................................................................................................................... 5
Proximity Sensor / Inductive Switch ...................................................................................................... 5
MCU Section .................................................................................................................................................... 5
8.
SCHEMATIC AND LAYOUT ........................................................................................................................... 6
Connectors ....................................................................................................................................................... 6
Schematic ........................................................................................................................................................ 7
Layout .............................................................................................................................................................. 9
9.
BILL OF MATERIALS ................................................................................................................................... 12
10. REVISION HISTORY ..................................................................................................................................... 13
11. REFERENCES .............................................................................................................................................. 13
12. STATUS DEFINITIONS ................................................................................................................................. 14
Corporate Headquarters ..................................................................................................................................... 14
Contact information ............................................................................................................................................. 14
Trademarks .......................................................................................................................................................... 14
Feb 28, 2022
User Manual
Page 1
© 2022 Renesas Electronics
Advertisement
Table of Contents
Related Manuals for Renesas CCE4503
Summary of Contents for Renesas CCE4503
-
Page 1: Table Of Contents
User Manual CCE4503 Evaluation Board 1. ABSTRACT The CCE4503 evaluation board is designed to evaluate and demonstrate the CCE4503 IO-Link Device IC. Contents ABSTRACT ..............................1 INTRODUCTION ............................. 2 SYSTEM REQUIREMENTS ..........................2 FEATURE OVERVIEW ........................... 3 GETTING STARTED ............................3 POWER SUPPLY ............................ -
Page 2: Introduction
The board is divided into three sections: ● IO-Link Section The IO-Link section contains all necessary circuitry to use one CCE4503 (with an adjustable current limit and slew rate) for IO-Link communication as well as several connectors. ● Sensor Section The sensor section contains three different sensors to provide a variety of signals and measurement capabilities (temperature sensor, color sensor and proximity switch). -
Page 3: Feature Overview
At port VDD, a regulated voltage of 3.3 V is generated by a LDO regulator. This regulator supplies the digital I/O pads of the CCE4503, the MCU and the sensors. VDD can supply additional external components, but the overall external load at VDD must not exceed 20 mA. The current consumption of the MCU, the sensors and external components must be below this limit. -
Page 4: Sections Of The Cce4503 Evaluation Board
IO-Link Section The IO-Link section contains the reference design for using the CCE4503. The current limit and the slew rate can be adjusted either by using the potentiometer R8, a fixed resistor R14 (not placed) or by connecting ILIM to GND or VDD. -
Page 5: Color Sensor
CCE4503 Evaluation Board User Manual Color Sensor Features of the color sensor: ■ BH1745NUC-E2 (ROHM) ■ C interface ■ 16 bit serial output RGBC For successful measurements, activate LED3 (white LED) to illuminate the object to be measured. In order to get a better result, keep the object close to the sensor and reduce incident ambient light. -
Page 6: Schematic And Layout
8. SCHEMATIC AND LAYOUT Connectors Figure 3 shows all connectors of the CCE4503 Evaluation Board. Via the connectors it is possible to access all necessary pins of the MCU and the CCE4503 device IC. Figure 3: Connectors Feb 28, 2022... -
Page 7: Schematic
CCE4503 Evaluation Board User Manual Schematic Figure 4: Schematic 1 Feb 28, 2022 Page 7... - Page 8 CCE4503 Evaluation Board User Manual Figure 5: Schematic 2 Feb 28, 2022 Page 8...
-
Page 9: Layout
CCE4503 Evaluation Board User Manual Layout Figure 6: Layout TOP Figure 7: Layout MID 1 Feb 28, 2022 Page 9... - Page 10 CCE4503 Evaluation Board User Manual Figure 8: Layout MID 2 Figure 9: Layout BOTTOM Feb 28, 2022 Page 10...
- Page 11 CCE4503 Evaluation Board User Manual Figure 10: Layout Assembly Feb 28, 2022 Page 11...
-
Page 12: Bill Of Materials
CCE4503 Evaluation Board User Manual 9. BILL OF MATERIALS Manufacturer Part Part Value / Description Manufacturer Number C1,C3,C6,C7,C8,C1 100 nF, 50 V, X7R, 10 %, 0603 1,C12 C2,C4 18 pF, 50 V, C0G, 5 %, 0603 1 nF, 50 V, C0G, 5 %, 0603 1 µF, 50 V, X7R, 10 %, 0805... -
Page 13: Revision History
CCE4503 Evaluation Board User Manual 10. REVISION HISTORY Revision Date Description 13-Mar-2020 Initial version. 28-Jan-2022 Rebrand 11. REFERENCES CCE4503, Datasheet, Dialog Semiconductor. LPC1347FBD48,151, Datasheet, NXP. IO-Link Interface and System Specification V1.1.2, IO-Link Community. Feb 28, 2022 Page 13... -
Page 14: Status Definitions
Trademarks Renesas and the Renesas logo are trademarks of Renesas Electronics Corporation. All trademarks and registered trademarks are the property of their respective owners. Feb 28, 2022... - Page 15 Renesas' products are provided only subject to Renesas' Terms and Conditions of Sale or other applicable terms agreed to in writing. No use of any Renesas resources expands or otherwise alters any applicable warranties or warranty disclaimers for these products.
