CCE4510 Evaluation Board
1. ABSTACT
The CCE4510 evaluation board is designed to evaluate and demonstrate the CCE4510 IO-Link Master IC with
integrated frame handler.
Contents
1.
ABSTACT ........................................................................................................................................................ 1
2.
INTRODUCTION ............................................................................................................................................. 2
3.
SYSTEM REQUIREMENTS ............................................................................................................................ 2
4.
FEATURE OVERVIEW ................................................................................................................................... 3
5.
GETTING STARTED ....................................................................................................................................... 3
6.
POWER SUPPLY ............................................................................................................................................ 3
7.
SECTIONS OF THE CCE4510 EVALUATION BOARD ................................................................................. 4
IO-Link Section ................................................................................................................................................ 4
MCU Section .................................................................................................................................................... 4
8.
SCHEMATIC AND LAYOUT ........................................................................................................................... 5
Connectors ....................................................................................................................................................... 5
Schematic ........................................................................................................................................................ 6
Layout .............................................................................................................................................................. 8
9.
BILL OF MATERIALS ................................................................................................................................... 11
10. REVISION HISTORY ..................................................................................................................................... 12
11. REFERENCES .............................................................................................................................................. 12
12. STATUS DEFINITIONS ................................................................................................................................. 12
Corporate Headquarters ..................................................................................................................................... 12
Contact information ............................................................................................................................................. 12
Trademarks .......................................................................................................................................................... 12
Feb 28, 2022
User Manual
Page 1
© 2022 Renesas Electronics
Advertisement
Table of Contents
Related Manuals for Renesas CCE4510
Summary of Contents for Renesas CCE4510
-
Page 1: Table Of Contents
User Manual CCE4510 Evaluation Board 1. ABSTACT The CCE4510 evaluation board is designed to evaluate and demonstrate the CCE4510 IO-Link Master IC with integrated frame handler. Contents ABSTACT ................................ 1 INTRODUCTION ............................. 2 SYSTEM REQUIREMENTS ..........................2 FEATURE OVERVIEW ........................... 3 GETTING STARTED ............................ -
Page 2: Introduction
2. INTRODUCTION The board is divided into two sections: ● IO-Link Section The IO-Link section contains two CCE4510 including all necessary periphery to use the two CCE4510 for IO-Link communication. ● MCU Section The MCU section contains a LPC1549 32-bit ARM Cortex-M3 microcontroller from NXP to control the CCE4510 Master ICs. -
Page 3: Feature Overview
4. Start programming with your preferred SDK 6. POWER SUPPLY The CCE4510 Evaluation Board needs a 24 V power supply connected to JP2 pins 23 / 24. An on-board 3.3 V LDO (placed on the MCU section) supplies the microcontroller as well as the CCE4510 ICs. -
Page 4: Sections Of The Cce4510 Evaluation Board
Each IO-Link channel (L+, CQ, L-) can be accessed via a terminal block (X2, X3, X4, X5). For maximum accessibility to the CCE4510 IO-Link Master ICs, all relevant pins of the CCE4510 ICs are connected to pin-headers JP3 and JP4. -
Page 5: Schematic And Layout
CCE4510 Evaluation Board User Manual 8. SCHEMATIC AND LAYOUT Connectors Figure 3 shows all connectors of the CCE4510 Evaluation Board. It is possible to access all pins of the MCU and the CCE4510 master ICs through these connectors. Figure 3: Connectors Feb 28, 2022... -
Page 6: Schematic
CCE4510 Evaluation Board User Manual Schematic Figure 4: Schematic 1 Feb 28, 2022 Page 6... - Page 7 CCE4510 Evaluation Board User Manual Figure 5: Schematic 2 Feb 28, 2022 Page 7...
-
Page 8: Layout
CCE4510 Evaluation Board User Manual Layout Figure 6: Layout TOP Figure 7: Layout MID1 (Supply) Feb 28, 2022 Page 8... - Page 9 CCE4510 Evaluation Board User Manual Figure 8: Layout MID2 (GND) Figure 9: Layout BOTTOM Feb 28, 2022 Page 9...
- Page 10 CCE4510 Evaluation Board User Manual Figure 10: Layout Assembly Feb 28, 2022 Page 10...
-
Page 11: Bill Of Materials
CCE4510 Evaluation Board User Manual 9. BILL OF MATERIALS Part Value / Description Manufacturer Manufacturer Part Number C1,C2,C20,C21 18 pF 50V C0G 5 % 0603 C3,C4,C9,C10 10 nF 50V X7R 10 % 0603 C5,C6,C11,C12, C15,C17,C18,C19, 100 nF 50V X7R 10 % 0603... -
Page 12: Revision History
Trademarks Renesas and the Renesas logo are trademarks of Renesas Electronics Corporation. All trademarks and registered trademarks are the property of their respective owners. Feb 28, 2022... -
Page 13: Contact Information
Renesas' products are provided only subject to Renesas' Terms and Conditions of Sale or other applicable terms agreed to in writing. No use of any Renesas resources expands or otherwise alters any applicable warranties or warranty disclaimers for these products.
