Handset Operation Instruction

1. Product Outline

LED Display

2. Product Specification

Button introduction: There are 6 buttons that "▲" , "▼", "
(1) "▲" : Adjust the desk upwards
(2) "▼" : Adjust the desk downwards
(3) " ": User height memory setting position 1
(4) " ": User height memory setting position 2
(5) " 3 ": User height memory setting position 3
(6) " 4 ": User height memory setting position 4
3. Operating Instructions
Quick Charge:
●
Safe: Built-in over-temperature protection, over-current protection, short-circuit protection,
etc., output interface current-limiting protection can ensure that the product works within the
normal current range;
Compatible: The product is compatible with mainstream smart phones and laptops on
the market, and can quickly charge the device.
Output Parameters:
●
1. Single USB Type-C port output: MAX 45W, 5V⎓3A, 9V⎓3A, 12V⎓3A, 15V⎓3A,
20V⎓2.25A;
2. Single USB Type-A port output: MAX 27W, 5V⎓2A, 9V⎓2A, 12V⎓1.5A, 15V⎓1.8A,
20V⎓0.9A, compatible with Xiaomi CHARGE TURBO, Huawei FCP/SCP, Samsung AFC
protocol;
3. When both Type-C and Type-A are connected to the device, the output voltage drops to
5V to power the device, and the MAX is 22.5W.
4. Note: When the standing desk is lifting, the charging function will be turned off, and when
the standing desk stops lifting, the charging function will return to normal.
", " ", "3", "4"
Lifting Function:
●
The height of the desk can be adjusted up or down by pressing the "▲" or "▼" button, and
the current height will show on the display.
Height Memory Function:
●
1. When the desk is in a static state, press and hold the button "
display shows " ", which means the save is successful. Then adjust the desk to any
height. Click the button " " and the desk will adjust to the height you saved.
2. Buttons " ", "3", and "4" all have the same height memory function as button "
the above steps to save the height to the corresponding position. Then click the button and
the desk will adjust to the height you saved.
Anti-Collision Sensor Level Adjustment:
●
1. Simultaneously press and hold the "▲" and "▼" buttons for 5 seconds to switch the
sensitivity. One operation can switch to one level, divided into 4 levels—A-3, A-2, A-1, A-0.
2. The display shows " " means the anti-collision function is turned off; the display
shows " " means low sensitivity; the display shows "
the display shows " " means high sensitivity.
3.When the desk rises or falls, it will rebound immediately when encountering obstacles to
prevent damage.
Height Limit Value Setting:
●
a. Press and hold the " " + "4" button for 3 seconds to set the maximum height, and the
LED display will show "top";
b. Press and hold the " " + "4" button for 3 seconds to set the minimum height, and the
LED display will show "bot";
c. Press and hold the "▼" + "4" button for 3 seconds to clear the height limit value setting,
and the LED display will show "clr".
d. Enter the reset mode manually will not clear the recorded altitudes.
Reset Function:
●
1. When the LED display shows "
the "▼" button until the desk reaches the lowest position and bounces up, the display
shows the current height, release the "▼" button and then the reset completes.
2. When the desk is in a static state, press and hold "3" and "4" buttons for 3 seconds
simultaneously and the desk starts reset process. Repeat the STEP 1 and then the reset is
completed. After that, the height you saved will be cleaned.
Code Processing:
●
1. If the words "E01" or "E02" appear, please let the desk rest for more than 18 minutes
before it can be used normally.
2. If other codes appear and there is no response after pressing the "▼" button, please
make sure that the cable is not damaged and the connection is normal, and power off for
more than 10 seconds, then turn on the power again, "
hold the "▼" button to reset (follow Reset Function).
3. If the above operations are performed, the table still does not operate normally, please
contact customer service.
Waste disposal
This marking indicates that this product should not be disposed with other household
wastes. To prevent possible harm to the environment or human health from
uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse
of material resources. To return your used device, please use the return and collection
systems or contact the retailer where the product was purchased. They can take this
product for environmental safe recycling.
" for three seconds, the
" means medium sensitivity;
" ,the desk starts the reset process. Keep pressing
" is displayed, then press and
", repeat
