SERVICE MANUAL
2016

Power board (supply rails)

240V - 480V
= 5V ISO (Control board)
= 26V ISO (Control board)
= 15V ISO
= 5V (Power board)
= 15V (Power board)
ODE-3 FRAME SIZE 3
Page 15 of 23
