SERVICE MANUAL
ODE-3 FRAME SIZE 3
2016

IGBT pin outs

4.0kW, 240V, 5.5 -7.5kW, 480V

34NAB12T4V1M11

5.5kW, 220V, 11.0kW, 480V

35NAB12T4V1M11
Page 13 of 23
