- Page 1 DETAILED INSTRUCTIONS FOR USE OF AN INDUCTION FREE STANDING COOKER gorenje MEKI510I MEKIS510W EIT5351SG www.gorenje.com...
- Page 2 Instructions for use are also available at our website: http://www.gorenje.com GORENJE gospodinjski aparati, d.o.o. Partizanska cesta 12 SI-3320 Velenje, SLOVENIA info@gorenje.com Important information Tip, note...
-
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS CAREFULLY READ THE INSTRUCTIONS AND SAVE THEM FOR FUTURE REFERENCE. This appliance may only be used by children aged 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if supervision or instructions are provided to them concerning use of the appliance in a safe way and if they understand the hazards involved. - Page 4 CAUTION: possibility of tilting. WARNING: In order to prevent tipping of the appliance, stabilising means must be installed. Refer to the instructions for installation. WARNING: Before replacing the light bulb, make sure the appliance has been disconnected from the mains power, in order to prevent the hazard of an electric shock.
- Page 5 WARNING: Use only hob guards designed by the manufacturer of the cooking appliance or indicated by the manufacturer of the appliance in the instructions for use as suitable or hob guards incorporated in the appliance. The use of inappropriate guards can cause accidents.
-
Page 6: Before Connecting The Appliance
Oven door become very hot during operation. A third glass is installed for extra protection, reducing the temperature of the outside surface (only with some models). Oven door hinges may be damaged when under excessive load. Do not place heavy pans on open oven door and do not lean against open oven door when cleaning the oven cavity. -
Page 7: Control Unit
APPLIANCE DRAWER Do not store combustible, explosive, volatile or temperature-sensitive items (such as paper, dish cloths, plastic bags, cleaners or detergents and spray cans) in the oven's storage drawer, as they can ignite during over operation and cause a fire. OVEN EQUIPMENT AND ACCESSORIES With telescopic extendible guides, first pull out the... - Page 8 − In induction cooking zones, heating is made INDUCTION COOKING SURFACE possible by the induction coil installed under the (depending on the model) glass ceramic surface. The coil induces a magnetic field which generates eddy currents in the bottom of a ferromagnetic pan (i.e. a pan that a magnet will adhere to), which in turn heats the pan.
-
Page 9: Energy Saving Tips
overheating of empty, dried-out pots or pans (with by the cooking zone. When the cooking zone is nothing in them), the warranty is void. activated, the sign "u" will appear on the cooking power display. If a pan is placed on the induction cooking zone within the next ten minutes, the hob will recognize it and switch on with the selected cooking power. -
Page 10: Switching On The Cooking Zones
OPERATING THE COOKING HOB SWITCHING ON THE COOKING ZONES CONTROL UNIT (depending on the model) After the hob is switched on (in the next 10 seconds), switch on the desired cooking zone (E). Use the keys (C) and (D) to select the desired setting for the activated cooking zone. - Page 11 CHILD LOCK signal will be emitted, and with a decimal point will Child lock may be activated on the hob to prevent the appear on the cooking zone display unit (G). appliance from being switched on easily and quickly Remaining time will appear on the opposite cooking and to prevent any changes during operation.
- Page 12 the cooking zone, which can be used to keep the food SETTING THE MAXIMUM TOTAL warm or for defrosting. When the sign "H" disappears, APPLIANCE POWER the cooking zone may still be hot. Be careful as there is danger of burns! MAXIMUM COOKING TIME For safety, the cooking time for each cooking zone is restricted to a maximum duration.
- Page 13 Activating the bridged cooking zone NOISE AND SOUNDS DURING INDUCTION Switch on the cooking hob by pressing the on/off COOKING sensor (A). Noises and Cause Simultaneously touch the two sensors and hold sounds them for 3 seconds (E). The sign will appear on Induction- Induction technology is based on...
-
Page 14: Electronic Timer
ELECTRONIC TIMER After turning on the oven using the "oven function switch", the electronic timer automatically (after 3 seconds) offers the option of setting the duration of baking. The display flashes and the ʺpreparation time" symbol is lit up. If duration is not set within 5 seconds, the timer switches into standby and duration of baking is not under time control. -
Page 15: Additional Functions
The volume of the sound signal can be set if no timer ʺTIMER ALARMʺ function function has been activated. The appliance is in standby mode and only the current time is displayed. Press and hold the less ʺ ʺ button for 5 seconds. ʺVollʺ... -
Page 16: Operating The Oven
OVEN System Description Suggested OPERATING THE OVEN temperature The oven can be operated with the knob for "oven °C mode selection" select function Cooking systems "temperature setting" to set the temperature. GRILL Rotate the knob (left and right) to select COOKING Only grill heater, a part of the SYSTEM (see program table). -
Page 17: Rapid Preheating
Guides cooking levels System Description Suggested temperature °C Cooking systems GENTLEBAKE * This feature allows gentle, slow, and even baking that leaves the food soft and juicy. It is suitable for roasting meat, cooking fish, and baking pastry on a single rack. - Page 18 Maximum temperature when using Grill and Large side of the rear oven cavity wall (the opening is grill is 230°C. protected with a rotating cover). Supervise the cooking process at all times. The meat Undo the skewer handle and close the oven door. may burn quickly due to high temperature.
-
Page 19: Maintenance And Cleaning
MAINTENANCE & CLEANING BOTTOM HEATER AND FAN Be sure to unplug the appliance from the This is used for baking leavened but low-rising pastry power supply and wait for the appliance and for preserving fruit and vegetables. Use the to cool down. second guide from the bottom and a rather shallow Children should not clean the appliance or baking tray to allow the hot air to circulate across the... -
Page 20: Removing And Cleaning Wire And Telescopic Extendible Guides
surface may also be damaged by aggressive spray Immediately remove any sugar or sugar-laden food cleaners unsuitable liquid cleaners. from the glass ceramic hob using a scraper, even if the hob is still hot, as sugar may permanently damage the glass ceramic surface. Discolouration of the glass ceramic surface does not affect the operation or stability of the surface. -
Page 21: Removing And Replacing The Oven Door
DOOR LOCK (depending on the model) Open the door lock by gently pushing it to the right with your thumb while simultaneously pulling the door outwards. When the oven door is closed, the door lock automatically returns to the initial position. -
Page 22: Removing And Inserting The Oven Door Glass Pane
Removing and replacing the oven door (depending on the model) 1. Open the oven door (up to end position). 2. Raise up and turn the flaps. 3. Slowly close the oven door, lift it slightly and pull it out from the both hinges of the appliance. Hold the door glass pane by the lower edge;... -
Page 23: Troubleshooting Table
TROUBLESHOOTING TABLE During the warranty period, only a service center authorized by the manufacturer may carry out any repairs. Before making any repairs, make sure the appliance is disconnected from the power mains either by removing the fuse or by disconnecting the power plug from the wall outlet. Unauthorized tampering with and repairs of the kitchen range (cooking hob) can result in electric shock or short circuit;... -
Page 24: Installation And Connection Instructions
INSTALLATION AND CONNECTION INSTRUCTIONS According to the plan attach the holder to the wall with the added screws and anchors. If the attached screws and anchors cannot be used, use APPLIANCE PLACEMENT (mm) others that will ensure a secure installation on the wall. -
Page 25: Connecting To The Power Mains
2. Adjust the wheels (see figure 2) by screwing them it to the mains and to check up on its duty. Installation with two screws at the front of the skirting board. of the range must be confirmed in the certificate of Check the horizontal position of the stove using a warranty. - Page 26 DISPOSAL Packaging is made of environmentally friendly materials that can be recycled, disposed of, or destroyed without any hazard to the environment. To this end, packaging materials labelled appropriately. The symbol on the product or its packaging indicates that the product should not be treated as normal household waste.
-
Page 27: Cooking Test
COOKING TEST Tested in compliance with the EN 60350-1 standard. BAKING Dish Equipment Guide (from System Temperature Cooking time (°C) the bottom) (minutes) Cookies 140-150* 25-40 single level Cookies 140-150* 25-40 single level shallow enamel-coated baking sheet Cookies 2, 3 140-150* 30-45 two levels... - Page 28 GORENJE MEKI510I, MEKIS510W, EIT5351SG 2022 03 20 IFU ES6I TC ILED T3 C GOR EN SAP 822895...
