  • Page 1 Instructions for use, mounting and connection Ceramic-glass Built-in Cooktop...

  • Page 2: Table Of Contents

    Ceramic-glass Built-in Cooktop Dear customer, Ceramic-glass built-in cooktop is made for domestic use only. Our products use environmentally friendly packaging, which can be either recycled or disposed of in an environmentally friendly manner. To this end, individual packaging materials are clearly marked. When your appliance fi...

  • Page 3: Important - Read Before Using The Appliance

    Important - Read before using the appliance Safety percautions • This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or metal capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
  • Page 4 • Do not store temperature-sensitive items underneath the appliance, such as cleaners or detergents, spray cans etc. • Using the glass ceramic hob as a storage area may result in scratches or other damage to it. Never heat food in aluminium foil or in plastic containers on the cooking hob. Such foil or containers may melt which can result in a fi...

  • Page 5: Glass Ceramic Cooktop

    Glass Ceramic Cooktop 1. Cooking zone rear left 2. Cooking zone rear right 3. Control knobs 4. Cooking zone front right 5. Cooking zone front left The glass ceramic cooktop has four heating zones. Its surface is fl at and there are no edges where food remains usually collect. •...

  • Page 6: Energy Saving Tips

    Pots and Pans Use only high quality pots with fl at and stable bottom. • Always be careful to put the pot in the middle of the cooking zone. • If you use the pots made of temperature resistant glass or earthenware, always consider the manufacturer’s instructions.

  • Page 7: Setting Of Cooking Zones

    Setting of Cooking Zones The cooking zones are controlled by knobs mountedl on the control panel of the cooker. The heating degrees are marked on the knobs from 1 to 6, whereby position 1 is the lowest and position 6 respectively the highest setting. The heating is switched off in position 0.

  • Page 8: Mounting The Built-In Hob

    Hold the scraper at the correct angle (45° to 60°). Gently press the scraper against the glass and slide it over the signage to remove the dirt. Make sure the plastic handle of the scraper (in some models) does not come into contact with a hot cooking zone.
  • Page 9 Installing the foam Before inserting the appliance into the opening in the kitchen gasket worktop, the supplied foam gasket must be attached to the lower side of the glass ceramic (glass) cooking hob (see fi gure above). Do not install the appliance without the foam gasket! The gasket should be attached to the appliance in the following way: - Remove the protective fi...
  • Page 10 • Worktop should be perfectly levelled. • Respect the instructions shown in Fig. 1 regarding installation. • Protect the cut edges and openings and insert adequate packing. • Insert the appliance into the opening. • Push fi rmly the cooktop plate from above and fi x it with four (4) screws from below.

  • Page 11: Electrical Connections

    Electrical connections • The electric built-in cooker has to be mounted and installed by a qualifi ed technician. The protection of the electrical wiring shall comply with current standards and regulations. • Before connecting the appliance to the power source, make sure that the voltage stated on the rating plate complies with the voltage of your power supply.

  • Page 12: Connecting To Power Supply

    Connecting to Power Supply Power supply may be connected by the qualifi ed technician only. Connecting sockets are available when you open the connecting box cover. WARNING! Before repairing or servicing, disconnect the power supply. According to the mains voltage the appliance should be connected in line with the displayed diagram.

  • Page 13: Type

    Front right Total power (kW) WE RESERVE THE RIGHT TO MAKE ANY CHANGES THAT DO NOT AFFECT THE FUNCTIONALITY OF THE APPLIANCE. Instructions for use of the appliance can also be found on our website at www.gorenje.com / < http://www.gorenje.com />...
  • Page 16 SVK 667S en (04-14)
