Gorenje SVK61TS User Manual

Gorenje SVK61TS User Manual

Built-in ceramic-glass cooktop

Advertisement

Built-in ceramic-glass cooktop
Dear customer !
The built-in ceramic-glass cooktop is intended for
household use only.
Materials used for packaging are nature friendly
and may be recycled, deposited or destroyed
without any threats to the environment.
In order to recognize these features, all packing
materials are marked with relevant symbols.
Once your appliance has become obsolete and
you do not intend to use it any longer, take
adequate care not to litter the environment.
Deposit your old appliance with the authorized
depot dealing with used household appliances.
Built-in ceramic-glass cooktop EN .............. 40
Important warnings ...................................... 41
Connection to the power supply .................. 41
Basic adjustment of sensors to the ambience
Installation diagram
Mounting the built-in cooktop ..................... 42
Caution !
Dimensions of the built-in hob opening
Installation procedure
Ceramic-glass cooktop .................................. 43
Cookware ....................................................... 44
Energy saving tips
Glass ceramic hob control elements ............ 45
Control panel
Control elements
Automatic cooking mode
Blocking the hob operation
Timer function
40

Instructions for use

Installation instructions

Rating plate

Fire hazard protection
Cooker controls.............................................. 52
Control elements............................................ 53
Cleaning and maintenance of ceramic-glass
hob .................................................................. 56
Technical information................................... 57
Instructions for use, mounting and connection
GB IE MT
Instructions for use have been prepared for the
user, and describe the particulars and handling of
the appliance. These instructions apply to
different models from the same family of
appliances, therefore you may find information
and descriptions that may not apply to your
particular appliance.
The appliance should be connected to the power
supply in accordance with the instructions from
the chapter "Electrical connections" and in line
with the standing regulations and standards.
The connections should be carried out by a
qualified personnel only.
The rating plate with basic information is located
underneath the appliance.
Appliances are allowed to be mounted on one
side next to a high kitchen cabinet, the height of
which may exceed that of the appliance. On the
opposite side however, only a kitchen cabinet of
equal height as the appliance is allowed.
Limited time of operation
Safety functions and error display
Control panel
Switching the hob on
Selecting the particular hotplate
Switching the hotplate on
Automatic cooking mode
Blocking the hob operation
Remaining heat indicators
Switching the entire hob off
Limited operation time
Power interruption
Safety warnings and error indication

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SVK61TS and is the answer not in the manual?

Questions and answers

Summary of Contents for Gorenje SVK61TS

  • Page 1: Instructions For Use

    Built-in ceramic-glass cooktop GB IE MT Dear customer ! Instructions for use The built-in ceramic-glass cooktop is intended for Instructions for use have been prepared for the household use only. user, and describe the particulars and handling of the appliance. These instructions apply to Materials used for packaging are nature friendly different models from the same family of and may be recycled, deposited or destroyed...
  • Page 2: Important Warnings

    Important warnings • The appliance may be built-in and connected to • In case of any malfunctions, disconnect the the power supply only by a qualified technician. appliance from the power supply and call • Particular areas of the cooktop surface service department.
  • Page 3: Mounting The Built-In Cooktop

    Basic adjustment of sensors to the ATTENTION ! Before attempting any repairs on the appliance, ambience disconnect the power supply. In accordance with the mains voltage the appliance should be connected in Upon each connection to the power supply the line with the attached diagram.
  • Page 4: Dimensions Of The Built-In Hob Opening

    • The smallest distance between the edge of the Installation procedure appliance and the adjacent high kitchen cabinet is 40 mm. • The use of hard wood decorative borders around the worktop behind the appliance is allowed, in case the minimum distance remains as indicated on the installation illustrations.
  • Page 5: Energy Saving Tips

    Cookware Use only high quality cookware with flat and firm Energy saving tips bottom. • Position the pot at the center of the hotplate • The inside bottom of the cookware should be during cooking. slightly concave for optimum heat transfer. •...
  • Page 6: Glass Ceramic Hob Control Elements

    Glass ceramic hob control elements Control panel Extended hotplate ring ON/OFF sensor Second hotplate LED signal lamp (hotplate 4) Second and third hotplate LED signal lamp (hotplate 2), certain models Heating power setting indicator (0...9), remaining heat display "H" and automated cooking signal "•"...
  • Page 7 Control elements Once the glass ceramic hob is connected to the mains (including the power failure), the appliance carries out the harmonization with the conditions of the exterior in order to provide most efficient sensor function and render the best control environment.
  • Page 8 Setting of cooking level As long as the indicators are lit the heating power (1...) may be selected and altered accordingly by pressing the (-) or (+) sensor. By the (+) sensor the power is gradually increased to the maximum level (9), while with the (-) sensor it is reduced back to 0 (hotplate is switched off).
  • Page 9 Switching the extended hotplate rings on (hotplates 2 and 4) Switch the relevant hotplate ( 2 or 4) and consequently switch the extended hotplate ring by pressing the relevant sensor (see the control element board illustration). The LED signal lamp above the indicator displays the extended ring is on.
  • Page 10 Switching the hotplate off Particular hotplate is switched off either by pressing the sensor (-) to bring the heating power to "0", or by simultaneously pressing both the (+) and (-) sensor. Hotplate is switched off automatically after the set timer period elapses. Display indicates "0"...
  • Page 11: Timer Function

    Timer function Once the hob is on you have two timer operation alternatives: 1. time countdown without the switch off function 2. setting the timer controlled period of operation for a particular hotplate Timer is activated by pressing the timer sensor, the display indicates "00".
  • Page 12: Limited Time Of Operation

    Limited time of operation Power setting Maximum operation time in hrs This function is incorporated for safer operation of your hob. Each hotplate is equipped with the time limit switch. The period of operation is calculated in accordance with the last selected power setting of a particular hotplate.
  • Page 13: Cooker Controls

    Cooker controls Control panel Hotplate cooking power indicator (0…9), remaining heat warning ''H'', and automatic cooking mode indicator ''A'' Hotplates 1 - 4 Hotplate selection sensor (+) Hotplate ON and power increase sensor (-) Hotplate ON and power reduction sensor Blocked operation indicator Main switch ON/OFF sensor Blocked operation ON/OFF sensor...
  • Page 14: Control Elements

    Control elements Once the glass ceramic hob is connected to the you may select the desired cooking power in 10 mains (including the power failure), the appliance seconds following the switch on or selection of a will perform the process of initial synchronization particular hotplate.
  • Page 15 Switching the hotplate on Power setting Maximum power time (in sec.) Once the hotplate is selected and its indicator flashes ''0'', you have 10 seconds to select the desired power setting by pressing either sensor (+) or (-). Indicator will flash the selected setting, and after 10 second lapse this setting becomes default.
  • Page 16 Switching the hotplate off Switching the entire hob off Particular hotplate is switched off either by The hob is switched off by pressing the main pressing the sensor (-) to bring the heating power ON/OFF sensor. All indicators go off, except for to "0", or by simultaneously pressing both the (+) those hotplates which are still hot and display the and (-) sensor.
  • Page 17: Cleaning And Maintenance Of Ceramic-Glass Hob

    If the sensors are covered with an object, or the Safety warnings and error indication surface is covered with spilt liquid, the hob is switched off. If both the (+) and (-) sensor are preset together the hotplate is switched off. Error may occur also during the period of initial synchronization or during the operation.
  • Page 18: Technical Information

    Sugar and sugar containing food may permanently damage the ceramic-glass hob surface (Fig.5), so the remains of sugar and sugar containing food must be scraped off from Technical information Type SVK61TS SVK62TS SVK63TS SVK66TS SVK67TS 2N AC 400 V Electrical connection...

This manual is also suitable for:

Svk62tsSvk63tsSvk67tsSvk66ts
