StarTech.com RKPNLHS6U Instruction Manual

Instruction manual
6U Hinged Solid Server Rack Blanking Panel
RKPNLHS6U
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
Packaging contents
• 1 x 6U hinged solid blanking panel
• 4 x 5/8" #10-32 UNF screws
• 4 x #10-32 UNF cage nuts
• 1 x instruction manual
Product diagram
Latch
For the latest information, technical specifications, and support for
this product, please visit www.startech.com/RKPNLHS6U.
Installation
1. Select the 6U space in your rack where you want to mount the
2. Insert the provided #10-32 UNF cage nuts into the mounting
3. Secure the blanking panel in place by aligning the blanking panel
4. To open the panel, slide the latch towards the hinge and pull the
Mounting points
Hinge
*actual product may vary from photos
blanking panel and decide which side of the rack that you want
the hinge to be on.
holes on either the left or the right post of your rack.
with the cage nuts installed in the previous step, and insert the
provided 5/8" #10-32 UNF screws into the cage nuts.
panel towards yourself.
Manual Revision: 06/30/2015
