User Guide
FortiFone FON- x8 0 / x8 0 B Series 3 .0 .19

Advertisement

Table of Contents
loading

Related Manuals for Fortinet FortiFone FON 80 Series

Summary of Contents for Fortinet FortiFone FON 80 Series

  • Page 1 User Guide FortiFone FON- x8 0 / x8 0 B Series 3 .0 .19...
  • Page 2 FORTINET DOCUMENT LIBRARY https://docs.fortinet.com FORTINET VIDEO GUIDE https://video.fortinet.com FORTINET BLOG https://blog.fortinet.com CUSTOMER SERVICE & SUPPORT https://support.fortinet.com FORTINET TRAINING & CERTIFICATION PROGRAM https://www.fortinet.com/training-certification FORTINET TRAINING INSTITUTE https://training.fortinet.com FORTIGUARD CENTER https://www.fortiguard.com END USER LICENSE AGREEMENT https://www.fortinet.com/doc/legal/EULA.pdf FEEDBACK Email: techdoc@fortinet.com August 16, 2023 FortiFone FON-x80/x80B Series 3.0.19 User Guide...

  • Page 3: Table Of Contents

    How to enter values with the dial pad and soft keys Configuration overview Status General Network Phone Account Accessory Provisioning History Contact Business and Directory Personal Setting Preference Accessory Programmable key Network Provisioning Feature Tool Cloud Text message Visual voicemail FortiFone FON-x80/x80B Series 3.0.19 User Guide Fortinet Inc.
  • Page 4 Performing a ping test Collecting traceroute information Setting log levels and downloading logs Appendix A: Supported Bluetooth headsets and dongles Bluetooth headsets (mono) Bluetooth dongles Appendix B: Supported EHS headsets Appendix C: Supported USB headsets FortiFone FON-x80/x80B Series 3.0.19 User Guide Fortinet Inc.

  • Page 5: Change Log

    Change log Date Change description 2023-08-14 Initial release of the FortiFone FON-x80/x80B Series 3.0.19 User Guide 2023-08-16 Updated Accessory on page FortiFone FON-x80/x80B Series 3.0.19 User Guide Fortinet Inc.

  • Page 6: Introduction

    For a complete list of FON-x80 phone features, see the FortiFone IP Telephones and Softclient Data Sheet. Phone buttons Button Function Navigation keys — used to navigate items in various menus. Hold — places and retrieves calls on hold. FortiFone FON-x80/x80B Series 3.0.19 User Guide Fortinet Inc.
  • Page 7 To configure programmable keys, go to Setting > Programmable key (see Programmable key on page 24). For more details about LED colors and patterns, see Programmable keys on page FortiFone FON-x80/x80B Series 3.0.19 User Guide Fortinet Inc.

  • Page 8: Programmable Keys

    Extension is idle. Slow flashing green Extension is ringing. Solid red Extension is in use. Solid yellow Do Not Disturb is enabled on extension. Slow flashing yellow Extension has a call on hold. FortiFone FON-x80/x80B Series 3.0.19 User Guide Fortinet Inc.

  • Page 9: Line Appearance And Shared Line Appearance

    Title bar The title bar displays status information, such as the extension display name and notifications for the phone status. The following table details the status icons that may be seen: FortiFone FON-x80/x80B Series 3.0.19 User Guide Fortinet Inc.

  • Page 10: Scroll List Of Programmable Keys

    . If the LED of the lower-right key flashes, then there is an incoming call (line, line appearance, or extension appearance) on one of the non-displayed programmable key pages. Notifications The main screen can show the following notification icons: FortiFone FON-x80/x80B Series 3.0.19 User Guide Fortinet Inc.

  • Page 11: Soft Keys

    (Phone System > Profile > Phone) and applying this profile to your phone (Phone System > Device > Phone). This feature requires a FortiVoice phone system running version 6.0.11, 6.4.5, or later. FortiFone FON-x80/x80B Series 3.0.19 User Guide Fortinet Inc.

  • Page 12: Personalizing Your Phone

    To enter characters with the dial pad, use the digit with the desired character. Press the same digit repeatedly until the desired character appears on the color screen. After entering a character, pause to allow the cursor to move to next character position. FortiFone FON-x80/x80B Series 3.0.19 User Guide Fortinet Inc.
  • Page 13 To enter a space, press # on the dial pad while the mode soft key is set to Prior to saving an entry, you may discard changes by pressing the Back soft key to move to the previous menu. FortiFone FON-x80/x80B Series 3.0.19 User Guide Fortinet Inc.

  • Page 14: Configuration Overview

    2. You can access the following functions: Icon Function Status on page 15 History on page 17 Contact on page 18 Setting on page 20 Feature on page 29 Tool on page 30 FortiFone FON-x80/x80B Series 3.0.19 User Guide Fortinet Inc.

  • Page 15: Status

    Storage Usage: Percentage of storage used. To see the total, used, and free storage (in KB) on the phone, press the Detail soft key. Network FON-x80/x80B series IP phone models support IPv4, not IPv6. Status > Network displays network information of the phone: FortiFone FON-x80/x80B Series 3.0.19 User Guide Fortinet Inc.

  • Page 16: Phone

    Disabled: Shows when Bluetooth is disabled. Enabled: Shows when Bluetooth is enabled but a Bluetooth headset is not connected. When Bluetooth is enabled and a headset is connected, the phone displays the headset model. FortiFone FON-x80/x80B Series 3.0.19 User Guide Fortinet Inc.

  • Page 17: Provisioning

    Last Configuration Time If Type is Cloud manual, the list shows the following settings: Cloud ID Extension No. Last Configuration Time History History displays call information for the following types of calls: FortiFone FON-x80/x80B Series 3.0.19 User Guide Fortinet Inc.

  • Page 18: Contact

    Contact > Business lists business entries that the administrator configures on the FortiVoice phone system. Contact > Directory lists your company directory including names and extensions entries stored on the FortiVoice phone system. To search for a business or directory contact FortiFone FON-x80/x80B Series 3.0.19 User Guide Fortinet Inc.

  • Page 19: Personal

    7. Enter the voicemail PIN for your extension. 8. Press the OK soft key. To edit a personal contact 1. Go to Contact > Personal. 2. Select the contact that you want to edit. FortiFone FON-x80/x80B Series 3.0.19 User Guide Fortinet Inc.

  • Page 20: Setting

    In Setting, you can configure various settings that control how the phone operates. Setting includes the following sections: Preference on page 21 Accessory on page 23 Programmable key on page 24 Network on page 26 Provisioning on page 29 FortiFone FON-x80/x80B Series 3.0.19 User Guide Fortinet Inc.

  • Page 21: Preference

    Date (DDMMYY) Manually enter the date in DDMMYY format. Time zone Manually select the time zone. Display Setting > Preference > Display allows you to control the appearance of items on the screen: FortiFone FON-x80/x80B Series 3.0.19 User Guide Fortinet Inc.
  • Page 22 You can adjust the microphone volume of the accessories. For example, if the caller is complaining about being unable to hear you, you can increase the microphone gain for that accessory. Handset Handsfree Headset USB Headset Bluetooth Headset FortiFone FON-x80/x80B Series 3.0.19 User Guide Fortinet Inc.

  • Page 23: Accessory

    EHS Headset Enables EHS (electronic hook switch), for use with compatible headsets. USB Headset Enables headset support through the USB port. Bluetooth Headset Enables and scans for Bluetooth headsets. FortiFone FON-x80/x80B Series 3.0.19 User Guide Fortinet Inc.

  • Page 24: Programmable Key

    DTMF: When you are on a call and you press the DTMF key, the system dials the configured DTMF digits. Shared Line Appearance: Allows you to perform the following actions for a FortiFone FON-x80/x80B Series 3.0.19 User Guide Fortinet Inc.
  • Page 25 Line appearance - Allows you to monitor the status of a line (available, busy, or on hold). If the light is flashing, you can press the programmable key to retrieve the call. FortiFone FON-x80/x80B Series 3.0.19 User Guide Fortinet Inc.

  • Page 26: Network

    Your choices are: DHCP (default) Static When you set the IP Mode to Static, configure the following settings: IP Address Configure IP address. Subnet Mask Configure subnet mask. Default Gateway Configure default gateway. FortiFone FON-x80/x80B Series 3.0.19 User Guide Fortinet Inc.
  • Page 27 If enabled, configure the following settings:  VLAN ID - Configure the VLAN ID with a value from 1 to 4094. VLAN Priority - Configure the VLAN Priority with a value from 0 to 7. FortiFone FON-x80/x80B Series 3.0.19 User Guide Fortinet Inc.
  • Page 28 AF32: 28 AF33: 30 AF41: 34 AF42: 36 AF43: 38 CS5: 40 CS4: 42 EF: 46 CS6: 48 CS7: 56 Default: 46 For details about Configuration Guidelines for DiffServ Service Classes, see RFC4594. FortiFone FON-x80/x80B Series 3.0.19 User Guide Fortinet Inc.

  • Page 29: Provisioning

    If you disable this option, users can use the pound key (#) as a phone number prefix such as #19002. Do Not Disturb Enables or disables Do Not Disturb. Call Waiting Enables or disables Call Waiting. FortiFone FON-x80/x80B Series 3.0.19 User Guide Fortinet Inc.

  • Page 30: Tool

    23646. The FortiVoice administrator can change this password on the phone system in Phone System > Profile > Phone. Tool contains configuration file related settings: Item Description Reboot Reboots the phone. Maintenance FortiFone FON-x80/x80B Series 3.0.19 User Guide Fortinet Inc.

  • Page 31: Cloud

    Update Firmware Requests the upgrade of the FortiFone firmware. Before requesting the upgrade, make sure that the FortiVoice administrator has uploaded the FortiFone firmware file from the Fortinet Support website to the FortiVoice phone system. Reload Used to restart certain processes:...

  • Page 32: Text Message

    PIN. The Visual Voicemail section displays voice messages in their respective folders, as stored on the FortiVoice unit. Available folders are All, Urgent, New, and Old. FortiFone FON-x80/x80B Series 3.0.19 User Guide Fortinet Inc.
  • Page 33 1. In App, select Visual Voicemail. 2. If prompted, enter your voicemail PIN, and press the OK soft key. 3. Select the voicemail message to delete. 4. Press the Delete soft key. FortiFone FON-x80/x80B Series 3.0.19 User Guide Fortinet Inc.

  • Page 34: Using Your Phone

    To quickly disable the ring tone, press the Ignore soft key. This will also allow for the call to still be answered. Placing a call You can place a call by using one of the following methods: FortiFone FON-x80/x80B Series 3.0.19 User Guide Fortinet Inc.

  • Page 35: Dialing An Extension Number

    To end a call, you can do one of the following: Press the End soft key. If you are using the handset, place it in the cradle. If you are on speakerphone, press If you are using a headset, press FortiFone FON-x80/x80B Series 3.0.19 User Guide Fortinet Inc.

  • Page 36: Call Features

    Mute turns the phone’s microphone on or off: Press to disable the microphone. The mute button will turn red. Press again to enable the microphone. The mute button will no longer be red. FortiFone FON-x80/x80B Series 3.0.19 User Guide Fortinet Inc.

  • Page 37: Attended Transfer

    To answer an incoming call while on a call, press the Answer soft key. The initial call will be placed on hold. For details about how to toggle between calls, see the Hold on page 36 section. FortiFone FON-x80/x80B Series 3.0.19 User Guide Fortinet Inc.

  • Page 38: Dnd

    - Voicemail Key):  A call is placed to your voicemail box. Follow the prompts. Alternatively, in the Visual voicemail menu, use the navigation keys to select the voicemail and press the Play soft key. FortiFone FON-x80/x80B Series 3.0.19 User Guide Fortinet Inc.
  • Page 39 2. When you hear the Auto Attendant greeting, press *98. (This is the default code.) 3. When prompted, enter your extension and then press #. 4. When prompted, enter your voicemail PIN and then press #. 5. Follow the prompts to listen to your messages. FortiFone FON-x80/x80B Series 3.0.19 User Guide Fortinet Inc.

  • Page 40: Troubleshooting

    4. Verify the MAC address and phone model of the phone entry: a. On the FortiVoice system or FortiVoice Cloud, go to Phone System > Device > Phone. b. In the table, locate the phone entry. FortiFone FON-x80/x80B Series 3.0.19 User Guide Fortinet Inc.

  • Page 41: Recommended Web Browser Versions

    Recommended web browser versions Fortinet recommends using the following web browser versions when you collect traffic captures and traceroute information, perform ping tests, set log levels, and download logs. Google Chrome version 114...
  • Page 42 In Capture Type, select one of the following options: Use Protocol: To capture TCP, UDP, or Any traffic. You can also specify a Port. SIP: To capture SIP traffic only. Capture All: To capture all traffic regardless of the protocol. FortiFone FON-x80/x80B Series 3.0.19 User Guide Fortinet Inc.
  • Page 43 13. When the traffic capture is complete, your web browser may give you the option to choose where you want to save the file or automatically save it for you, depending on the settings. 14. You can open the .pcap file in a network protocol analyzer software (such as Wireshark). FortiFone FON-x80/x80B Series 3.0.19 User Guide Fortinet Inc.

  • Page 44: Performing A Ping Test

    9. Under Ping, in IP Address/FQDN, enter the IP address or fully qualified domain name (FQDN) of the destination. 10. To start the ping process, click Start. 11. Please wait. 12. Check the ping results. The following example shows that the phone can successfully ping fortinet.com: FortiFone FON-x80/x80B Series 3.0.19 User Guide Fortinet Inc.

  • Page 45: Collecting Traceroute Information

    5. In Password, enter the administrator password. 6. If you want the portal to remember your login credentials and use them the next time you log in, click Remember 7. Click Log In. 8. Click Tool. FortiFone FON-x80/x80B Series 3.0.19 User Guide Fortinet Inc.
  • Page 46 11. Please wait. 12. Check the output. Here is an output example (without errors): traceroute to fortinet.com (54.186.80.150), 30 hops max, 38 byte packets 1 192.168.10.99 (192.168.10.99) 0.272 ms 0.205 ms 0.199 ms 2 172.17.97.3 (172.17.97.3) 0.312 ms 0.278 ms 0.523 ms 3 * * * 4 96.45.47.4 (96.45.47.4) 0.963 ms 0.787 ms 0.797 ms...

  • Page 47: Setting Log Levels And Downloading Logs

    30 * 108.166.240.19 (108.166.240.19) 12.571 ms * Setting log levels and downloading logs Phone logs can help you and Fortinet Support troubleshoot FON-x80/x80B series IP phones. You can set a log level for each log type and download log files.

  • Page 48: Appendix A: Supported Bluetooth Headsets And Dongles

    Model Company Answer Hangup Ringing Hold waiting call call Redial tone waiting (idle) call) M300- BlueParrott — BT2054 — — BT4010 — — Jabra Evolve — — Talk 45 — — FortiFone FON-x80/x80B Series 3.0.19 User Guide Fortinet Inc.

  • Page 49: Bluetooth Dongles

    USB dongle. The following table includes supported CSR Bluetooth USB dongles for the FON-380 phone. Manufacturer Model ASUS BT500 AZiO BTD-V401 Onvian 8541554597 ORICO BTA-403 REDGO 163804JA84M830 RtTech 4328604329 TP-LINK UB400 Yealink BT40 FortiFone FON-x80/x80B Series 3.0.19 User Guide Fortinet Inc.

  • Page 50: Appendix B: Supported Ehs Headsets

    Savi 7310 — — Legend:  l: FortiFone FON-x80/x80B phones and the headset support this function. —: FortiFone FON-x80/x80B phones do not support this headset function. N/A: The headset does not support this function. FortiFone FON-x80/x80B Series 3.0.19 User Guide Fortinet Inc.

  • Page 51: Appendix C: Supported Usb Headsets

    Blackwire — Plantronics 3220 Legend:  l: FortiFone FON-x80/x80B phones and the headset support this function. —: FortiFone FON-x80/x80B phones do not support this headset function. N/A: The headset does not support this function. FortiFone FON-x80/x80B Series 3.0.19 User Guide Fortinet Inc.
  • Page 52 Fortinet’s General Counsel, with a purchaser that expressly warrants that the identified product will perform according to certain expressly-identified performance metrics and, in such event, only the specific performance metrics expressly identified in such binding written contract shall be binding on Fortinet. For absolute clarity, any such warranty will be limited to performance in the same ideal conditions as in Fortinet’s internal lab tests.
