Viking Range RVGC3301 Installation Manual

Built-in gas cooktops

Advertisement

Quick Links

Installation
3 Series
Built-In Gas Cooktops
RVGC3301 RVGC3361

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RVGC3301 and is the answer not in the manual?

Questions and answers

Summary of Contents for Viking Range RVGC3301

  • Page 1 Installation 3 Series Built-In Gas Cooktops RVGC3301 RVGC3361...
  • Page 2: Table Of Contents

    Table of Contents Warnings & Important Safety Instructions __________________________________________3 Dimensions _________________________________________________________________6 Specifications _______________________________________________________________7 Cutout Dimensions ___________________________________________________________8 Cutout Dimensions (Cooktop over Single Electric Oven) _______________________________9 Clearance Dimensions (Proximity to Cabinets) ______________________________________10 Clearance Dimensions (Wood/Composite Overlay) ___________________________________11 Electrical & Gas Requirements __________________________________________________12 General Information __________________________________________________________14 Installation _________________________________________________________________15 Gas &...
  • Page 3: Warnings & Important Safety Instructions

    IMPORTANT – Please Read and Follow Your safety and the safety of others is • Before beginning, please read these very important. instructions completely and carefully. We have provided many important safety • DO NOT remove permanently affixed messages in this manual and on your labels, warnings, or plates from product.
  • Page 4 IMPORTANT – Please Read and Follow DANGER WARNING FIRE/EXPLOSION CHEMICAL HAZARD HAZARD If not installed, operated and maintained in accordance IF THE INFORMATION IN THIS with the manufacturer’s MANUAL IS NOT FOLLOWED instructions, this product could expose EXACTLY, A FIRE OR EXPLOSION MAY you to substances in fuel or from fuel RESULT CAUSING PROPERTY DAMAGE, combustion which can cause death or...
  • Page 5 IMPORTANT – Please Read and Follow WARNING ELECTRICAL GROUNDING INSTRUCTIONS The cooktop must be electrically grounded in accordance with local codes or, in the absence of codes, with the ANSI/NFPA No. 70-latest edition. Installation should be made by a licensed electrician. This appliance is equipped with a three-prong grounding plug for your protection against shock hazard and should be plugged...
  • Page 6: Dimensions

    Dimensions RVGC3301 - 3 / ( 7 8 4 ” ” ( 5 3 RVGC3361 - 3 / ( 9 3 4 ” ” ( 5 3 2-1/2” 4-3/8” (6.4 cm) (11.1 cm) 2-1/2” (6.4 cm) 1-3/4” (4.5 cm) Front view...
  • Page 7: Specifications

    Specifications Gas Cooktops Description RVGC3301 RVGC3361 Overall width 30-3/4” (78.1 cm) 36-3/4” (93.3 cm) Overall height from bottom 4-3/8” (11.1 cm) to top of grate Overall depth from rear 21” (53.3 cm) Cutout width 29-1/4” (74.3 cm) min. to 35-1/4” (89.5 cm) min. to 29-7/8”...
  • Page 8: Cutout Dimensions

    Cutout Dimensions 30” W. Model 36” W. Model 29-1/4” (74.3 cm) min. to 35-1/4” (89.5 cm) min. to 29-7/8” (75.9 cm) max. 35-7/8” (91.1 cm) max. 20” (50.8 cm) min. to 20-1/4” (51.4 cm) max. 2-1/2” (6.4 cm) min. Note: Based on 24” deep cabinet with 3/4” backsplash. If countertop is less than 1-1/2”...
  • Page 9: Cutout Dimensions (Cooktop Over Single Electric Oven)

    Cutout Dimensions (RVGC/CRVGC Cooktop over Single Electric Oven) ” m ( 9 1 i n . - 1 / ( 7 1 8 ” 30” W. Model - 1 / 29-1/4” (74.3 cm) min. to ( 3 6 4 ” .
  • Page 10: Clearance Dimensions (Proximity To Cabinets)

    Clearance Dimensions (Proximity to Cabinets) Proximity to Side Cabinet Installation Minimum Clearances from Adjacent Combustible Construction • The cooktop may be installed directly to existing base cabinets. • Above countertop 36” (91.4 cm) minimum • The cooktop CANNOT be installed directly •...
  • Page 11: Clearance Dimensions (Wood/Composite Overlay)

    Clearance Dimensions (Wood/Composite Overlay) The bottom of a standard hood should be 30” / C o (76.2 cm) min. to 36” (91.4 cm) max. above the o s i e r l countertop. This would typically result in the bottom of the hood being 66” (167.6 cm) to 72”...
  • Page 12: Electrical & Gas Requirements

    Electrical & Gas Requirements Electrical Requirements There is no connection necessary beyond Manual shut-off valve: plugging the unit into a polarized, grounded, • The installer-supplied valve must be 120 volt, 60 Hz, 15 amp circuit. A minimum of installed in the gas service line ahead of 120VAC is required for proper operation of the appliance and regulator in the gas gas ignition systems.
  • Page 13 Electrical & Gas Requirements Rigid Connections: Initial Ignition of Burners • Incoming gas is brought from an intake pipe (not supplied) at the rear of the unit to All cooktops are tested before leaving the the pressure regulator; then to the manifold factory.
  • Page 14: General Information

    General Information Electrical Requirement CAUTION Normal grounded household current, 120 volts, 60 Hz, 15 amps, single phase. BURN HAZARD Electrical installation should comply with national and local codes. The use of cabinets for storage above the appliance may result in a potential burn Air Supply and Ventilation hazard.
  • Page 15: Installation

    Installation Remove the grates and burner caps. Turn the cooktop over and place into countertop opening. Gas & Electrical Connection Note: Refer to “Electrical & Gas Requirements” section for proper installation information.
  • Page 16: Bracket Installation

    Bracket Installation Cooktop Cooktop Countertop Countertop Screw Eye Bolt Bracket Bracket Screw hold down brackets to the burner box using the #10 x Screw the eye bolt into the self-retaining nut and tighten 1/2” sheet metal screws. There are 6 bracket assemblies firmly against bottom of countertop.
  • Page 17: Final Preparation

    Final Preparation • New units are cleaned at the factory • All stainless steel parts should be wiped to remove any visible signs of dirt, oil, regularly with hot, soapy water grease, etc. remaining from the and with a liquid cleanser designed for this manufacturing process.
  • Page 18: Service & Registration

    Only authorized replacement parts may be used in performing service on the appliance. All servicing should be referred to a qualified technician. Contact Viking Range, 1-888-845-4641, for the nearest service parts distributor in your area or write to: VIKING RANGE, LLC...
  • Page 20 Viking Range, LLC 111 Front Street Greenwood, Mississippi 38930 USA (662) 455-1200 For product information, call 1-888-845-4641 or visit our website at vikingrange.com (103122) 057148-000D EN...
