atd models ATD008 Instruction Manual page 4

11a. Detach component L (x2) and glue them
together, back to back.
12. Detach component O and fold it along the
crease lines, forming the chimney stack.
13b. Apply a bead of glue to the chimney feet
and the position them within the collar,
ensuring the bottom of the feet are flush with
the bottom of the collar.
11b. Detach component J and K and glue them
within the building along with component
L, as per the illustration below.
Each truss should sit within a notch cut out
i
on the corresponding wallst.
13a. Detach component N and fold it along the
crease lines. Then apply glue to the tab and
bond, forming a collar.
14. Position the chimney stack just inside the
chimney base. Next carefully interlock the tabs
on the base with the chimney stack.
tab
stack
push tab
in here to
interlock
