EMG LJV-HZ-EP5 Installation Instructions

INSTALLATION INFORMATION
EMG MODEL: JV-HZ/JV-HZ 52 SETS
SPECIFICATIONS
Pickup Types: Passive
Logo Color
Magnet Type
Inductance (Henries)
DC Resistance (kOhm)
Resonant Frequency (KHz) (1)
Resonant Frequency (KHz) (2)
Impedance at Resonance (kOhm) (1)
(1) Loaded with 250K Volume and Tone
and 20' (6M) 560pf cable
(2) Loaded with 1 MegOhm / 47pf
Installation notes:
As you can see from the diagrams above, the J-HZ Set consists of a Short (SJ-HZ) Style Pickup and the longer Bridge Pickup (LJ-HZ).
The SJ-HZ pickup is for the Neck position while the LJ-HZ pickup is for the bridge position.
These J-HZ Models use a split-coil design with a coil for each pair EA/DG strings for noise reduction and are for 4 string instruments only.
Alnico 2 magnets have more iron in their makeup therefore yield a higher inductance and have slightly lower magnetism.
As you can see the cable capacitance has a heavy influence on the resonant frequency of both Alnico 2 and 5 versions.
Alnico 2 models can be described as "vintage" (pre-1960's) while the Alnico 5 models reflect more current passive designs.
It is common to ground (earth) the strings of an instrument that uses passive pickups. This means there will be a wire
coming from the bridge into the control cavity that will be hooked to one of the pots. Included with the system is a single black wire
with a connector on it and an IDC connector that will attach to the existing ground wire and will provide the ground (earth) connection.
Included with THE SET:
2 VOLUME CONTROLS (250K)
1 TONE CONTROL (250K)
.235 (6)
.390
.310
(8)
(10)
Warranty
All EMG Pickups and accessories are warranted for a period of two years. This warranty does not cover failure due to improper installation, abuse or damage. If
upon examination the pickup is determined to be defective, a replacement will be made. Warranty replacement products are covered by this same warranty. This
warranty covers only those pickups and accessories sold by authorized EMG Dealers. This warranty is not transferable.
© 2019 Copyright EMG INC. All Rights Reserved.
SHORT J HOUSING
.920 (23.4)
MODEL:
-
SJV HZ-EP5
Gold
Alnico 5
2.38
6.89
3.5
4.0
52.31
ADJUSTMENT SCREWS (8)
BRIDGE GROUND
MONO OUTPUT
CONNECTOR
JACK
EXPOSED POLE (EP) MODELS ARE SHOWN
HIDDEN POLE MODELS ARE AVAILABLE
(SJ)
3.590
(91.18)
.730 (18.54)
1.500
R .093
(38.1)
(2.36) TYP
#4 WOOD SCREW
R .250
FOR MOUNTING
(6.35) TYP
- -
LJV HZ-EP5 SJV HZ-EP2
Gold Gold
Alnico 5 Alnico 2
2.80 3.0
7.60 6.83
3.5 3.0
4.0 3.4
61.54 56.52
J PICKUP CABLE 12" (25cm)
J PICKUP CABLE 10" (25cm)
2 CONNECT CABLES 5.5" (14cm)
OUTPUT CABLE 6" (15cm)
BRIDGE GROUND WIRE 6" (15cm)
LONG J HOUSING
(LJ)
3.700
(93.98)
1.560
(39.6)
.900 (22.8)
-
LJV HZ-EP2
Gold
Alnico 2
3.48
7.60
3.0
3.4
65.56
