INSTALLATION AND OPERATING INSTRUCTIONS
Infrared Sauna Series Models
IS 201, IS 301, IS 401, and IS 601 with
"SaunaLogic IS" Control Panel and CB PK-5
Box
(here after referenced as SaunaLogic IS and CB PK Box)
Read all instructions carefully before installation. Please
leave all instructions and warranty with the owner.
WARNING
Prolonged exposure to elevated temperatures is capable of inducing
hyperthermia. Hyperthermia occurs when the internal temperature of
the body reaches several degrees above the normal body temperature of
98.6°F. The symptoms of hyperthermia include an increase in the
normal temperature of the body, dizziness, lethargy, drowsiness, and
fainting. The effects of the hyperthermia include failure to perceive
heat, failure to recognize the need to exit the room, unawareness of
impending hazard, fetal damage in pregnant women, physical inability
to exit the room and unconsciousness.
WARNING
The use of alcohol, drugs, or medication is capable of greatly
increasing the risk of fatal hyperthermia.

SECTION 1: GENERAL INFORMATION

The system is ETL approved for permanent installations and electrical
connections. All wiring must be performed in accordance with national
and local codes. See Diagram 2 for wire and room size requirements.
These heaters are wall mounted.
710-0143 Custom IS Installation Manual with Low EMR
07/18/16
WARNING
Do not take a sauna if using
alcohol, drugs or
medications.
Pregnant women or persons
with poor health should
consult their physician
before using any sauna.
Caution fire hazard: Do not
use the sauna room for
drying clothes, bathing suits,
etc. Do not hang towels
above heater. If any
darkening of the wall
around the heater is noticed
discontinue sauna use
immediately.
Inspect sauna regularly for
required maintenance to
heater, control and benches.
Replace wood surfaces
which show any signs of
deterioration.
The heater gets hot during
operation and should not be
touched or burns may result.
Minors should be adequately
supervised whenever near a
hot or warming sauna.
Page 1
Rev 02

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IS 201 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Helo IS 201 Series

  • Page 1: Section 1: General Information

    INSTALLATION AND OPERATING INSTRUCTIONS Page 1 WARNING Do not take a sauna if using alcohol, drugs or medications. Pregnant women or persons with poor health should consult their physician before using any sauna. Caution fire hazard: Do not use the sauna room for drying clothes, bathing suits, etc.
  • Page 2 INSTALLATION AND OPERATING INSTRUCTIONS Page 2 DIAGRAM 1 MINIMUM DISTANCE TO COMBUSTIBLE MATERIAL Temperature Sensor *Sauna Heater Optional Equipment Emitters Sauna Heater CB PK 2" 2" 10" 18" 18" Recheck your distances from the heater to combustible materials to be sure you have the proper minimum distances.
  • Page 3 INSTALLATION AND OPERATING INSTRUCTIONS Page 3 DIAGRAM 3 Typical IS Installation with a traditional sauna heater Refer to Diagram 1 for minimum spacing requirements. 2" Locate top of sensor 2" from ceiling and directly above the traditional sauna heater if installed. (If infrared only, install the sensor above IR heater panel).
  • Page 4 INSTALLATION AND OPERATING INSTRUCTIONS Page 4 DIAGRAM 6 Recessed Mounted IR Heating Assembly Information 16" 28 1/4" 27" 14 3/4" IR-160-240-R IR-325-240-R 40" 39 3/8" ROUGH OPENING IR-110-240-R Surface Mounted IR Heating Assembly Information 26 5/8" 14 3/8" IR-160-240-S IR-325-240-S 38 3/8"...
  • Page 5 INSTALLATION AND OPERATING INSTRUCTIONS Page 5 DIAGRAM 7 WIRING DIAGRAM: CONTROL AND HEATER MODELS Junior 3.0 (1517-30-02) SaunaLogic IS and CB PK Box Junior Heater 1517-30-02 IR Emitters IR Emitters (Optional Equipment) Back Element Front Element T1T2 SaunaLogic IS Control Panel To next IR Emitter T1 T2 GND GND...
  • Page 6 INSTALLATION AND OPERATING INSTRUCTIONS Page 6 DIAGRAM 7 CONT. WIRING DIAGRAM: CONTROL AND HEATER MODELS Viki 4.5, 6.0 & 8.0 (1720-45-02,1720-60-02,1720-80-02) SaunaLogic IS and CB PK Box Viki Heater 1720-45-02 1720-60-02 IR Emitters IR Emitters (Optional 1720-80-02 Equipment) Back Element Middle Element Front Element...
  • Page 7: Section 2: Installation Summary And Tips

    INSTALLATION AND OPERATING INSTRUCTIONS Page 7 WARNING SECTION 2: INSTALLATION SUMMARY AND TIPS Refer to Diagram 1 for minimum clearance of ELECTRICAL: ROUGH IN: Step 1: Is a traditional sauna heater being installed in room? ceiling above heater. If yes, the traditional heater location must be chosen first. If the room is over 78"...
  • Page 8: Section 3: Temperature Sensor

    INSTALLATION AND OPERATING INSTRUCTIONS Page 8 SECTION 3: TEMPERATURE SENSOR Locate top of sensor 2" from ceiling and directly above the IR-325-240 IR panel AND traditional sauna heater if installed. (traditional sauna heater is optional equipment.) Feed the 17 ft "low voltage" sensor wire from the sensor location to the CB PK box location. Sensor wire must be routed completely separate (as per low voltage electrical wiring codes) from any wiring carrying over 50 volts.
  • Page 9 INSTALLATION AND OPERATING INSTRUCTIONS Page 9 SECTION 4: ROOM AND ELECTRICAL INSTALLATION CONT. ROOM ROUGH IN FOR RECESS MOUNT IR EMITTERS: Build the frame the room with standard building materials and framing design. Install single gang outlets below the IR Emitters. Rough in all lighting wires, IR emitters wires, Sensor wire, Control wires before insulating the room and applying foil vapor barrier.
  • Page 10: Section 5: Electrical Controls Installation

    INSTALLATION AND OPERATING INSTRUCTIONS Page 10 SECTION 5: ELECTRICAL CONTROLS INSTALLATION Electrical installation must be made by a licensed electrician in accordance with the National Electrical Code and local regulations. Remove the screws from the CB PK box to access the electrical connections. Secure CB PK box to the wall in the sauna room according to Diagram 1.
  • Page 11: Section 6: Saunalogic Is Control Operation

    INSTALLATION AND OPERATING INSTRUCTIONS Page 11 SECTION 6: SAUNALOGIC IS CONTROL OPERATION OPERATING INSTRUCTIONS FOR IR EMITTERS . Press the red POWER button once. The Infrared heaters will turn on and begin heating the room to current set points. At the end of the selected time (60 minutes maximum), the control will turn itself off and the control display will turn off.
  • Page 12: Section 7: High Limit Control (Reset Button)

    INSTALLATION AND OPERATING INSTRUCTIONS Page 12 SECTION 7: HIGH LIMIT CONTROL (RESET BUTTON) The sauna systems have a built-in high limit control, which automatically turns off the heater if the temperature inside in the sauna room rises to an abnormally high level. The control will display "HL"...
  • Page 13: Section 10: Warning Placards

    INSTALLATION AND OPERATING INSTRUCTIONS Page 13 SECTION 10: WARNING PLACARDS WARNING The "CAUTION" and Two metal placards are included in the Installation Instruction Envelope "WARNING" placards must packaged with every Sauna Heater. The CAUTION placard must be be mounted in accordance attached to the interior wall of the sauna room directly above the heater where it is visible to the bather.
  • Page 14: Section 14: Troubleshooting

    INSTALLATION AND OPERATING INSTRUCTIONS Page 14 DIAGRAM 8 DIAGRAM 9 TYPICAL PRE-CUT WALL CONSTRUCTION VENTILATION 1/2" wallboard 2x4" framing berglass insulation foil vapor barrier T&G soft wood Locate vent under the top bench 1/2" wallboard SECTION 14: TROUBLESHOOTING If control displays "SN" it means no sensor is connected. Refer to Section 4 for sensor installation information.
