Infrared Sauna Series Models
IS 200, IS 300, IS 400, IS 600
Read all instructions carefully before installation. Please
leave all instructions and warranty with the owner.
WARNING
Prolonged exposure to elevated temperatures is capable of inducing
hyperthermia. Hyperthermia occurs when the internal temperature of
the body reaches several degrees above the normal body temperature
of 98.6°F. The symptoms of hyperthermia include an increase in the
normal temperature of the body, dizziness, lethargy, drowsiness, and
fainting. The effects of the hyperthermia include failure to perceive
heat, failure to recognize the need to exit the room, unawareness of
impending hazard, fetal damage in pregnant women, physical inability
to exit the room and unconsciousness.
WARNING
The use of alcohol, drugs, or medication is capable of greatly
increasing the risk of fatal hyperthermia.
SECTION 1: GENERAL INFORMATION
The system is ETL approved for permanent installations and electrical
connections. All wiring must be performed in accordance with national
and local codes. See Diagram 2 for wire and room size requirements.
These heaters are wall mounted.
4215-109 G
WARNING
Do not take a sauna if using
alcohol, drugs or
medications.
Pregnant women or persons
with poor health should
consult their physician
before using any sauna.
Caution fire hazard: Do not
use the sauna room for
drying clothes, bathing
suits, etc. Do not hang
towels above heater. If any
darkening of the wall
around the heater is noticed
discontinue sauna use
immediately.
Inspect sauna regularly for
required maintenance to
heater, control and
benches. Replace wood
surfaces which show any
signs of deterioration.
The heater gets hot during
operation and should not be
touched or burns may
result.
Minors should be
adequately supervised
whenever near a hot or
warming sauna.
10/30/09
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Helo IS 200
Summary of Contents for Helo IS 200
-
Page 1: Section 1: General Information
Do not hang towels above heater. If any darkening of the wall Infrared Sauna Series Models around the heater is noticed IS 200, IS 300, IS 400, IS 600 discontinue sauna use immediately. Inspect sauna regularly for required maintenance to heater, control and Read all instructions carefully before installation. - Page 2 Page 2 DIAGRAM 1 MINIMUM DISTANCE TO COMBUSTIBLE MATERIAL *Sauna Heater Optional Equipment Sauna Heater Recheck your distances from the heater to combustible materials to be sure you have the proper minimum distances. OBSERVING MINIMUM DISTANCES IS REQUIRED TO REDUCE FIRE HAZARD DIAGRAM 2 * Denotes an optional traditional sauna heater may be added to the system.
- Page 3 Typical IS Installation with a tradiontal sauna heater Refer to Diagram 1 for minimum spacing requirements. 4215-109 G 10/30/09...
- Page 4 Page 4 WARNING SECTION 2: ELECTRICAL INSTALLATION SUMMARY AND TIPS ELECTRICAL: ROUGH IN: Step 1: Is a traditional sauna heater being installed in room? If yes, the traditional heater location must be chosen first. If the room is over 78" and the heater is hung on the wall and the IR assembly can be Fire sprinkler systems used installed above the tradional sauna heater.
- Page 5 Page 5 SECTION 2: ELECTRICAL INSTALLATION SUMMARY AND TIPS CONT. Step 4: Traditional Sauna Heater Wiring traditional sauna heater (optional). Refer to Diagram 2 for the traditional sauna heater for wire size or a 72" wire is provided with the sauna heater.
-
Page 6: Section 4: Temperature Sensor
Page 6 SECTION 3: ELECTRICAL INSTALLATION SUMMARY Electrical installation must be made by a licensed electrician in accordance with the National Electrical Code and local regulations. Remove the screws from the CB PK box to access the electrical connections. Secure CB PK box to the wall in the sauna room according to Diagram 1. - Page 7 Page 7 WIRING DIAGRAM: CONTROL AND HEATER MODELS 4215-109 G 10/30/09...
- Page 8 Page 8 WIRING DIAGRAM: CONTROL AND HEATER MODELS 4215-109 G 10/30/09...
- Page 9 Page 9 SECTION 6: SAUNALOGIC IS CONTROL INSTALLATION & OPERATION OPERATING INSTRUCTIONS FOR IR EMITTERS . Press the red POWER button once. The Infrared heaters will turn on and begin heating the room to current set points. At the end of the selected time (60 minutes maximum), the control will turn itself off and the control display will turn off.
-
Page 10: Section 8: How To Take A Sauna
Page 10 SECTION 7: HIGH LIMIT CONTROL (RESET BUTTON) The sauna systems have a built-in high limit control, which automatically turns off the heater if the temperature inside in the sauna room rises to an abnormally high level. The control will display "HL" if the system overheats. To restart the heater, let the room cool, then push the "On/Off"... -
Page 11: Section 12: Ventilation
Page 11 SECTION 10: WARNING PLACARDS WARNING The "CAUTION" and Two metal placards are included in the Installation Instruction "WARNING" placards Envelope packaged with every Sauna Heater. The CAUTION placard must be mounted in must be attached to the interior wall of the sauna room directly above accordance with Section 10. -
Page 12: Section 14: Troubleshooting
Page 12 SECTION 14: TROUBLESHOOTING If control displays "SN" it means no sensor is connected. Refer to Section 4 for sensor installation information. If control displays "HL" it means the high limit is open and the heater is too warm. Refer to Section 7 for high limit information.
