Finnish Sauna P rf ction
Note: Room must be installed on flat, level surface.
2 Person Infrared Sauna Cottage
2 person infrared sauna
e e
T820H
User manual
Page 1
2021-01-21
2
2
3
4
8
13
16
17
18
19
19
19
20
210121
Rev. 2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the T820H and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Helo T820H

  • Page 1: Table Of Contents

    2021-01-21 2 person infrared sauna T820H Finnish Sauna P rf ction User manual Note: Room must be installed on flat, level surface. Precautions Before Use Preassembly Information Electrical Requirements Sauna Assembly Electrical Connection-Under Bench Electrical Connection-Inside Ceiling How to Use Sauna Tips &...
  • Page 2: Precautions Before Use

    Precautions before Use: Warning (Room Configuration & Use): • Proper Electrical Grounding is Required • Electrical Receptacles not Allowed in the Room • Do not Apply Water to any Heating Element • Do not Add a Locking or Latching System to the Door •...
  • Page 3: Electrical Requirements

    Electrical Requirements: The IR Sauna Room is designed for a 230 Volt AC / 10 Amp Circuit Breaker! A 230 Volt AC (dedicated) circuit is recommended to avoid unnecessary tripping of the breaker. Record your model number and serial number in the event you should need to contact your dealer or technical support.
  • Page 4: Sauna Assembly

    Sauna Assembly Instructions _________________________________________________________________________ Floor Panel (Box #1): • Locate the Floor Panel on a level surface 8-15 cm (3-6 inches) from wall and no more than 150 cm (5 ft) from 230 Volt AC / 10 amp dedicated receptacle. •...
  • Page 5 Back Wall (Box #3): Note: after opening the box 3 -- store Front Wall panel until that step of the assembly process. sure to control the door from opening when moving the Front Wall Panel to prevent breakage. • Place Back Wall panel into the back slot of the Floor Panel. •...
  • Page 6 Right Wall (Box #2): • Place Right Wall section into the right slot of the Floor Panel • Attach Back Wall to the Right Wall by lifting up the Right wall sliding into the corner interlock brackets. Left Wall (Box #2): •...
  • Page 7 Bench Skirt (Box #1): • Insert the Bench Skirt in between the Right Wall and the Left Wall panels tracks. • Slide Bench Skirt all the way to the floor. Do not pinch any wires under the skirt. • Latch the buckles securing the floor to the Bench Skirt. Do not latch the buckles for the left and right wall panel at this time.
  • Page 8: Electrical Connection-Under Bench

    Electrical Connections (under bench - right side): • Connect wire #4 from distribution plate to #4 from Back Wall harness. • Connect wire #5 from the distribution plate to #5 from the Back Wall harness. • Connect wire R1 from the distribution plate to R1 from the Right Wall junction box. •...
  • Page 9 Electrical Connections (under bench - left side): • Connect wire L1 from the distribution plate to L1 from the Left Wall panel. • Connect wire B1 from the distribution plate to B1 from the Back Wall panel. • View of the finished connections. •...
  • Page 10 • Use the buckles to latch the skirt to the left and right side walls. • Bench top can now be fit into place. Bench must tuck under the back heater guard and then push all the way to the back wall. •...
  • Page 11 Front Wall (Box #2): • Place the Front Wall panel into the Floor panel slot. • Lock Front Wall panel into place by slightly lifting it higher than the Right & Left Wall panels and pushing inward as lowering the Front Wall panel. Note: Secure the door from falling open and breaking while setting the Front Wall panel.
  • Page 12 Ceiling (Box #1): • The ceiling can now be set in place. • Once the Ceiling panel is lined up directly above the Wall panels; insert the wires harnesses from the wall panels into the holes in the Ceiling panel. Note: Position the cam locks on the top of the Left &...
  • Page 13: Electrical Connection-Inside Ceiling

    • Lower the Ceiling panel. Be sure not to pinch any wires under the Ceiling panel. • Turn the wood ceiling cam locks to lock the ceiling into place. Electrical Connections (inside the Ceiling panel-back right corner): • Open all hatch doors on the ceiling to locate the necessary electrical plugs. •...
  • Page 14 Electrical Connections (inside Ceiling-Left front corner): • Near the Touch Screen harness in Ceiling connect Left Wall wire #3 to Ceiling wire #3. • Connect Left Wall wire #7 to the Ceiling wire #7. • Connect Left Wall wire F to Ceiling wire F. •...
  • Page 15 Door handles: Inside Outside 2 Person Infrared Sauna Cottage Page 15 210121 Rev. 2...
  • Page 16: How To Use Sauna

    How to Use Infrared Sauna: Avoid eating large meals and excessive alcohol intake before using Sauna. Never smoke or drink alcohol or exercise inside of Sauna. If you are taking any medications or under the care of a Physician, consult with them prior to Sauna usage. Refer to Sauna Usage Warning signs located inside of Sauna Room Prior to Sauna session, if possible before using Sauna, take a warm shower without drying.
  • Page 17: Tips & Troubleshooting

    Maintenance / General Cleaning Tips: DO NOT USE: Alcohol or any strong Cleaning Chemicals Note: Some chemicals can damage clear finish and wood surfaces. • Interior: Perspiration and dirt may absorb into the wood, so periodic cleaning is needed, scrubbing benches, back supports, floor boards and walls with a stiff brush and mild detergent is normally sufficient.
  • Page 18: Wiring Diagram

    2 Person Infrared Sauna Cottage Page 18 210121 Rev. 2...
  • Page 19: Control Panel Instructions

    IR2 Control Operation Operating Instructions Default settings for temperature are preset to 65°C, the time is set to 60 minutes. These settings are adjustable as described below. Any changes are remembered by the room for your next bath. Should the room power be lost then restored, the settings will return to their default values.
  • Page 20: How To Pair Ir2 Control To Saunalogic App

    SaunaLogic App Quick Start Guide: How to Pair IR2 Control to SaunaLogic App The SaunaLogic App allows you to turn your sauna on/off, set temperature, turn on Bluetooth, adjust lighting, and more from the convenience of your smart phone or tablet. The following are the steps to pair your IR2 Control to the SaunaLogic App.
  • Page 21 3) Login with Your Account: After completing the account registration requirements, you will be able to login with the credentials you provided during that process. NOTICE: BEFORE MOVING TO THE NEXT STEP (Add Device) YOU WILL NEED TO MAKE SURE THAT THE PHONE OR TABLET THAT YOU ARE GOING TO USE TO PAIR THE IR2 CONTROL TO THE SAUNALOGIC APP IS CONNECTED TO A WIFI NETWORK THAT IS CONFIGURED FOR 2.4GHz AND PROVIDES A STRONG SIGNAL WHERE THE IR2 CONTROL IS LOCATED.
  • Page 22 7) Connect to your desired Wi-Fi Network, enter your Password and then tap on the Confirm Button. 8) Connect your mobile phone to the IR2 Control’s hotspot that is identified in the SaunaLogic App. 9) Once you have selected and connected to the IR2 Control’s hotspot, tap on “SaunaLogic” located at the top left of the screen to go back to the SaunaLogic App and continue with the pairing process.
  • Page 23 10) If you get a message that reads “Network is unavailable, 11) If you get a message that reads “Device not responding please check the network” it means that the connection has Check demerit points and retry” it means that the connection failed.
  • Page 24 13) You should now be able to control your IR2 Control with the SaunaLogic App. Tap the button on the control screen within the SaunaLogic App to turn your sauna on and gain access to the control functions. NOTE: THE SAUNA MAY ALSO BE TURNED ON / OFF FROM THE HOME SCREEN BY TAPPING THE BUTTON, NEXT TO THE IR2 CONTROL ICON (SEE BELOW).
  • Page 25 NOTICE: IT IS ONLY ONE PHONE THAT CAN AND NEEDS TO BE PAIRED. ALL OTHER USERS NEED TO BE A PART OF THE SAME “FAMILY”. THE PHONE THAT IS PAIRED IS THE ADMINISTRATOR AND GIVES ACCESS TO THE “FAMILY” CREATED TO ALL OTHER USERS BY ADMITTING THEIR ACCOUNTS (ALL USERS NEED TO CREATE AN ACCOUNT, SEE STEP 2) Troubleshooting: Not able to find the hotspot SMARTxxx (step 8):...
