Note: Room must be installed on flat, level surface.
710-0130 IG-880-SH / S880-H 3-4 Person IR Sauna
Ver. 2
3-4 Person Infrared Sauna
Touch Pad and Bluetooth
IG-880-SH/S880
User Manual
This Product is covered by:
US Patents No. 8,692,168
Canadian Patents No. 2,729,500
2,794,059 & 2,813,340
and other Patents Pending.
S-Series
Page 1
2
2
3
4
7
12
15
15
16
17
18
19
20
01/18/16
Rev. 3
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Helo IG-880-SH
Summary of Contents for Helo IG-880-SH
-
Page 1: Table Of Contents
Sauna Assembly Electrical Connection-Under Bench Electrical Connection-Inside Ceiling Control Panel Instructions Lighting Operation Audio System How to Use Sauna Tips & Troubleshooting Wiring Diagram Warranty 710-0130 IG-880-SH / S880-H 3-4 Person IR Sauna Page 1 01/18/16 Ver. 2 Rev. 3... -
Page 2: Precautions Before Use
Note: Front wall glass assembly is heavy and fragile. Box #1: Floor, Ceiling, Bench Skirt, Bench, Manual & Deluxe Door Handle Set Box #2: Back & Front Walls Box #3: Back & Side Walls 710-0130 IG-880-SH / S880-H 3-4 Person IR Sauna Page 2 01/18/16 Ver. 2... -
Page 3: Electrical Requirements
Record your model number and serial number from box in the event you should need to contact your dealer or technical support. Serial Number ______________________________ Model Number ______________________________ Dealer Name________________________________ 710-0130 IG-880-SH / S880-H 3-4 Person IR Sauna Page 3 01/18/16 Ver. 2 Rev. 3... -
Page 4: Sauna Assembly
Note: place the power cord on the ground to the side of the floor; be sure that all wires and connectors on the sauna floor are clear of the slots. Note – Do NOT Plug the Sauna Room 120 VAC Power Cord into the Outlet Yet! 710-0130 IG-880-SH / S880-H 3-4 Person IR Sauna Page 4 01/18/16 Ver. - Page 5 Place Left Back Wall section into the left slot of the Floor Panel Attach Left Back Wall to the Right Back Wall by lifting up the Left wall sliding into the corner interlocking brackets. 710-0130 IG-880-SH / S880-H 3-4 Person IR Sauna Page 5 01/18/16 Ver.
- Page 6 Slide Bench Skirt all the way to the floor. Do not pinch any wires under the skirt. Insert the right Bench Skirt in between the left Bench Skirt and the Right Front Wall. 710-0130 IG-880-SH / S880-H 3-4 Person IR Sauna Page 6 01/18/16 Ver.
-
Page 7: Electrical Connection-Under Bench
The Bench Top should fit down flush from front to back. It may be necessary to use the openings in the skirt to apply pressure forward or rearward on the skirt to allow the bench to drop into place. 710-0130 IG-880-SH / S880-H 3-4 Person IR Sauna Page 7 01/18/16 Ver. - Page 8 Connect wire S3 from the distribution plate to S3 from the Bench Skirt. Connect wire S1 from the distribution plate to S1 from the Bench Top. Connect wire #6 from the distribution plate to #6 on Bench Top. 710-0130 IG-880-SH / S880-H 3-4 Person IR Sauna Page 8 01/18/16 Ver.
- Page 9 The Bench Top should fit down flush from front to back. It may be necessary to use the openings in the skirt to apply pressure forward or rearward on the skirt to allow the bench to drop into place. 710-0130 IG-880-SH / S880-H 3-4 Person IR Sauna Page 9 01/18/16 Ver.
- Page 10 These will be used to set the ceiling on. The ceiling can now be set in place on top of the Styrofoam blocks. 710-0130 IG-880-SH / S880-H 3-4 Person IR Sauna Page 10 01/18/16 Ver.
- Page 11 Glass panels must recess into the slot in the Ceiling panel. Make sure the ceiling fits tight and is flat and level. Turn the wood ceiling cam locks to lock the ceiling into place. 710-0130 IG-880-SH / S880-H 3-4 Person IR Sauna Page 11 01/18/16 Ver.
-
Page 12: Electrical Connection-Inside Ceiling
Connect Left Wall wire F to Ceiling wire F. Connect Left Wall wire E to Ceiling wire E. Connect the Right wall wire #7 to Ceiling wire #7. 710-0130 IG-880-SH / S880-H 3-4 Person IR Sauna Page 12 01/18/16 Ver. 2 Rev. 3... - Page 13 Note: It is important that the sauna be plugged into a dedicated outlet of the correct rating. Plugging your sauna into a shared circuit through can cause poor performance, circuit breaker tripping, or overheating of the circuit. 710-0130 IG-880-SH / S880-H 3-4 Person IR Sauna Page 13 01/18/16 Ver.
- Page 14 Phillips screw driver. Step 5. Attach exterior portion of door handle on to bolt section and tighten all four set screws with Allen wrench. 710-0130 IG-880-SH / S880-H 3-4 Person IR Sauna Page 14 01/18/16 Ver. 2...
-
Page 15: Control Panel Instructions
7th press – BLUE-RED-GREEN 8th press – Activates full rotation of all 7 color therapy in sequence noted above 9th press – Turns Color Therapy Functions OFF 710-0130 IG-880-SH / S880-H 3-4 Person IR Sauna Page 15 01/18/16 Ver. 2... -
Page 16: Audio System
95⁰F and above. The recommended operating temperature is 32⁰F to 95⁰F to fall into the warranty. Check with any other device manufactures for operation temperatures before using the device in the Sauna/IR Room. 710-0130 IG-880-SH / S880-H 3-4 Person IR Sauna Page 16 01/18/16 Ver. -
Page 17: How To Use Sauna
Open the door and clean the Sauna walls, bench and floor areas with a soft clean damp cloth. Enjoy a final shower or bath to cool down. Relax, in the special “after sauna glow” and you may choose to enjoy a healthy snack and cool drink. 710-0130 IG-880-SH / S880-H 3-4 Person IR Sauna Page 17 01/18/16 Ver. -
Page 18: Tips & Troubleshooting
------------------------------------------------------------------------------------------- For additional assistance or service questions? Please do not hesitate contacting Saunatec/TyloHelo Mon – Fri. 8AM – 5PM CST 1-888-780-4427 techsupport@tyloheloinc.com 710-0130 IG-880-SH / S880-H 3-4 Person IR Sauna Page 18 01/18/16 Ver. 2 Rev. 3... -
Page 19: Wiring Diagram
710-0130 IG-880-SH / S880-H 3-4 Person IR Sauna Page 19 01/18/16 Ver. 2 Rev. 3... -
Page 20: Warranty
710-0130 IG-880-SH / S880-H 3-4 Person IR Sauna Page 20 01/18/16 Ver. 2 Rev. 3...
