Pins
13 RXD_MUX
11 TXD_MUX

2.3.23 UART3 Interface (J10)

Pins
33 CTS
35 RTS
36 RXD_MUX
38 TXD_MUX

2.3.24 UART4 Interface (J11)

Pins
28 RXD_MUX
30 TXD_MUX

2.3.25 UART5 Interface (J11)

Pins
32 RXD_MUX
34 TXD_MUX
2.3.26 USDHC1 (Ultra Secured Digital Host Controller) Interface
(J10)
Pins
39 CD
3 CLK
Copyright © 2014 Embest Technology
Definitions
Receive data
Transmit data
Table 2-23 UART3 Interface
Definitions
Clear To Send
Request To Send
Receive data
Transmit data
Table 2-24 UART4 Interface
Definitions
Receive data
Transmit data
Table 2-25 UART5 Interface
Definitions
Receive data
Transmit data
Table 2-26 USDHC1 Interface
Definitions
Card detect
Card clock
Descriptions
Descriptions
Descriptions
Descriptions
Descriptions
