Gpmi (General Purpose Memory Interface) (J10); Spdif (Sony/Philips Digital Interface) (J10); Uart1 Interface (J11) - Embest MarS Board User Manual

Embest Technology

2.3.20 GPMI (General Purpose Memory Interface) (J10)

Pins
6 ALE
4 CE0N
3 CLE
14 D0
16 D1
18 D2
20 D3
22 D4
24 D5
26 D6
28 D7
34 DQS
32 RDN
12 READY0
10 WP
30 WRN

2.3.21 SPDIF (Sony/Philips Digital Interface) (J10)

Pins
25 IN1
23 OUT1
29 PLOCK
27 SPDIF_EXTCLK
31 SRCLK

2.3.22 UART1 Interface (J11)

Pins
7 CTS
9 RTS
Copyright © 2014 Embest Technology
Table 2-20 GPMI Interface
Definitions
Address Latch Enable
CHIP ENABLE
Command Latch Enable
Data 0
Data 1
Data 2
Data 3
Data 4
Data 5
Data 6
Data 7
Data Strobe Control
Read Enable
Ready Busy
Write Protect
Write Enable
Table 2-21 SPDIF Interface
Definitions
I2S data Input
I2S data output
System master clock
I2S frame clock
I2S bit clock
Table 2-22 UART1 Interface
Definitions
Clear To Send
Request To Send
Descriptions
Descriptions
Descriptions
MarS Board User Manual
16
