2.3.17 IPU1 (Image Processing Unit 1) Interface (J11)

Pins
4 CSI0_DAT12
6 CSI0_DAT13
8 CSI0_DAT14
10 CSI0_DAT15
12 CSI0_DAT16
14 CSI0_DAT17
16 CSI0_DAT18
18 CSI0_DAT19
21 CSI0_DATA_EN
17 CSI0_HSYNC
19 CSI0_PIXCLK
23 CSI0_VSYNC

2.3.18 KPP Keyboard Interface (J11)

Pins
30 COL[0]
34 COL[1]
35 COL[2]
28 ROW[0]
32 ROW[1]
37 ROW[2]
2.3.19 PWM (Pulse Width Modulation) Interface (J10 & J11)
Pins
26(J11) PWM1
13(J10) PWM4
Copyright © 2014 Embest Technology
Table 2-17 IPU1 Interface
Definitions
Digital image data bit 12
Digital image data bit 13
Digital image data bit 14
Digital image data bit 15
Digital image data bit 16
Digital image data bit 17
Digital image data bit 18
Digital image data bit 19
Digital image data write enable
Horizontal synchronization
Pixel clock
Vertical synchronization
Table 2-18 KPP Interface
Definitions
Keypad matrix column 0 output
Keypad matrix column 1 output
Keypad matrix column 2 output
Keypad matrix row 0 input
Keypad matrix row 1 input
Keypad matrix row 1 input
Table 2-19 PWM Interface
Definitions
Pulse Width Modulation
Pulse Width Modulation
Descriptions
Descriptions
Descriptions
