- Page 1 M116P/ PT x86 Rugged Tablet Intel® Pentium® N4200, 1.1 GHz (turbo to 2.5 GHz) Windows® 10 IoT Enterprise Quick Start Guide Version 1.0 Document Part No. 91521110105E Please read these instructions carefully before using this product, and save this manual for future use.
-
Page 2: Table Of Contents
11.6" Rugged Tablet M116P/ PT Series Quick Start Guide Contents READ ME FIRST DVISORY ONVENTIONS AFETY NFORMATION ANDLING AND AINTENANCE INTRODUCTION VERVIEW NPACKING ESCRIPTION OF ARTS NDICATORS OTKEY FOR PECIFIC UNCTIONS GETTING STARTED NSTALLING ATTERY SD C NSTALLING A ICRO 4G LTE M NSTALLING ODULE... -
Page 3: Read Me First
Read Me First Read Me First Advisory Conventions Four types of advisories are used throughout the user manual to provide helpful information or to alert you to the potential for hardware damage or personal injury. Note: A note is used to emphasize helpful information Important: An important note indicates information that is important for you to know. -
Page 4: Safety Information
11.6" Rugged Tablet M116P/ PT Series Quick Start Guide Safety Information Precaution on Battery When the Battery Pack Has Deteriorated, Replace It with a New Battery. Continued use Pack of a damaged battery pack may result in heat Précaution avec le bloc- generation, ignition or battery rupture. - Page 5 Read Me First General Product Safety This product should not be used near water Sécurité générale des such as bathtubs, sinks, swimming pools, wet basement, etc. produits [FR] Ce produit ne dois pas être utilisé près de l'eau comme les baignoires, les éviers, les ...
-
Page 6: Handling And Maintenance
11.6" Rugged Tablet M116P/ PT Series Quick Start Guide Handling and Maintenance Gently wipe the display with a soft, lint-free cloth. Do not use alcohol or detergent on the product. General Guideline [FR] Essuyer délicatement l'écran avec un Guide Général chiffon doux non pelucheux. -
Page 7: Introduction
Introduction Overview Congratulations on purchasing Winmate® 11.6-inch x86 Rugged Tablet M116P/ PT Series. The M116P/ PT Series platform is a next-generation Windows rugged tablet series designed to boost efficiency in a mobile, versatile form factor. The large 11.6-inch sunlight readable full HD display allows for a premium viewing experience no matter where work takes place. -
Page 8: Description Of Parts
11.6" Rugged Tablet M116P/ PT Series Quick Start Guide Description of Parts Dimensions: 300.67 x 201.97 x 22.5 mm Front: Left: Right: Item Description Item Description Use to attach a wrist strap 11.6-inch display with String Hole 11.6” PCAP LED backlight, acts as or other accessories. - Page 9 Introduction Bottom: Item Description Item Description Optional Barcode Scanner for Smart Card Smart Card Reader, Barcode reading of 1D/2D Reader complies with barcode. (Optional) IS07816-1.2.3T=1 and Physical Press power button to T=Ø protocol Buttons: Power, turn on the tablet. Long Expansion Slot For optional add-on UHF F1, F2, F3...
-
Page 10: Indicators
11.6" Rugged Tablet M116P/ PT Series Quick Start Guide Indicators Icon Indicator Description Power Indicator Blue– Tablet is ON No light– Tablet is OFF Orange–AC adapter is plugged in and charging Battery Status Green–AC adapter is plugged in and battery is full charged Solid Red - Low battery (<10%) Blinking Red –... -
Page 11: Installing A Micro Sd Card
Getting Started 2. Insert the battery with the connector-pins side first, and then lower the battery into the battery compartment. Make sure the battery is completely lowered into the compartment. Once fully inserted, the Battery Release Slider automatically locks. Battery will be flat against the housing once fully inserted. -
Page 12: Installing 4G Lte Module
11.6" Rugged Tablet M116P/ PT Series Quick Start Guide Installing 4G LTE Module Notice that 4G LTE feature is optional and may not be supported by your device. Check your order specifications for more details. The Tablet Computer supports 4G LTE data connection and fits a Micro-SIM card. Before installing fits a Micro-SIM card please install the 4G LTE module. -
Page 13: Installing Sim Card (For 4G/Lte Equipped Devices)
Getting Started Installing SIM card (For 4G/LTE Equipped Devices) Notice that 4G LTE feature is optional and may not be supported by your device. Check your order specifications for more details. Caution Disconnect any cords connected to the tablet computer before installation or removing battery procedure. -
Page 14: Charging Your Tablet
11.6" Rugged Tablet M116P/ PT Series Quick Start Guide Charging Your Tablet The Tablet operates either on external AC power or internal battery power. It is recommended to use AC power when you start up the Tablet for the first time. Caution Use only the AC adapter included with your Tablet Computer. -
Page 15: Using Lan Port (Rj45)
Getting Started 2. If the Backup battery level is “Low”, please charge the tablet with AC Power until the Backup battery level is “Medium” or “High”, and do not remove the main battery. 3. If the Backup battery level is at “Medium” or “High”, you can remove the main battery. 4. -
Page 16: Using Hottab Utility
11.6" Rugged Tablet M116P/ PT Series Quick Start Guide Using Hottab Utility Hottab provides quick access to the tablet’s functions and features, such as setting up shortcuts, using camera, powering on/off built-in devices, programming function key, and changing power management. As Windows starts up, Hottab starts and runs in the background. -
Page 17: Changing Touch Mode
Getting Started 3. Touch the on-screen shutter button to take a photo or video record button to record a video. Changing Touch Mode The tablet computer supports three built-in operating modes for different usage scenarios: To change touch mode: Mode Description In Hand/Rain mode the touchscreen rejects false inputs from liquid drops. -
Page 18: Reading Hf Rfid Tags
11.6" Rugged Tablet M116P/ PT Series Quick Start Guide To set up a barcode scanner: 1. Tear off protective film from the barcode. 2. Launch the Hottab Utility 3. Choose Device ON/OFF and click on Barcode 4. Tap barcode power ON. 5. -
Page 19: Attachment
Attachment Attachment Docking Connector Pin Definition M116P/ PT Series Rugged Tablet supports one 19-pin docking connector at the bottom side. The pin definition is listed as the following table. Pin No. Signal Name Pin No. Signal Name RF_GND DOCK_DET# GPS ANT RF_GND Power RF_GND... - Page 20 Winmate Inc. 9F, No.111-6, Shing-De Rd., San-Chung District, New Taipei City 24158, Taiwan, R.O.C www.winmate.com Copyright © 2018 Winmate Inc. All rights reserved.
