M116K
x86 Rugged Tablet
Intel® Core™ i5-7300U 2.60 GHz
Windows® 10 IoT Enterprise
User Guide
Version 1.0
Document Part No. 91521110105H
Please read these instructions carefully before using this product, and save this manual for future use.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M116K and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Winmate M116K

Summary of Contents for Winmate M116K

  • Page 1 M116K x86 Rugged Tablet Intel® Core™ i5-7300U 2.60 GHz Windows® 10 IoT Enterprise User Guide Version 1.0 Document Part No. 91521110105H Please read these instructions carefully before using this product, and save this manual for future use.

  • Page 2: Table Of Contents

    11.6" Rugged Tablet M116K User Guide Contents CONTENTS CHAPTER 1: READ ME FIRST 1.1 A ..............................3 DVISORY ONVENTIONS 1.2 S ................................ 4 AFETY NFORMATION 1.3 H ............................6 ANDLING AND AINTENANCE 1.4 D C) ..........................7 ECLARATION OF ONFORMITY CHAPTER 2: GETTING STARTED 2.1 I...
  • Page 3 Contents 6.1 B ..............................55 ASIC ROUBLESHOOTING APPENDIX A: P ............................ 57 PPENDIX RODUCT PECIFICATIONS...

  • Page 4: Chapter 1: Read Me First

    11.6" Rugged Tablet M116K User Guide Chapter 1: Read Me First 1.1 Advisory Conventions Four types of advisories are used throughout the user manual to provide helpful information or to alert you to the potential for hardware damage or personal injury. These are Notes, Important, Cautions, and Warnings.

  • Page 5: Safety Information

    Chapter 1: Read Me First 1.2 Safety Information Precaution on Battery Pack Do Not Expose the Battery Pack to Excessive Précaution avec le bloc-pile Heat, or Extreme Heat (Near Fire, in Direct Sunlight for example) Generation of heat, ignition or rupture may result Do Not Disassemble, Modify, or Insert Sharp [FR] Ne pas exposer le bloc-pile à...
  • Page 6 11.6" Rugged Tablet M116K User Guide General Product Safety  This product should not be used near water Sécurité générale des such as bathtubs, sinks, swimming pools, wet basement, etc. produits [FR] Ce produit ne dois pas être utilisé près de l'eau comme les baignoires, les éviers, les...

  • Page 7: Handling And Maintenance

    Chapter 1: Read Me First 1.3 Handling and Maintenance Gently wipe the display with a soft, lint-free cloth. Do not use alcohol or detergent on the product. General Guideline [FR] Essuyer délicatement l'écran avec un Guide Général chiffon doux non pelucheux. Ne pas utiliser d'alcool ou un détergent sur le produit.

  • Page 8: Declaration Of Conformity (Doc)

    11.6" Rugged Tablet M116K User Guide 1.4 Declaration of Conformity (DoC) FCC Statement This device complies with part 15 FCC rules. Operation is subject to the following two conditions: This device may not cause harmful interference.  This device must accept any interference received including interference that ...

  • Page 9: Chapter 2: Getting Started

    The large 11.6-inch sunlight readable full HD display allows for a premium viewing experience no matter where work takes place. The M116K allows for powerful performance with the 7th generation Intel Core i5 processor for all day use with a hot-swappable battery design. Multiple wireless connectivity options and data capture modules allows users to complete their tasks reliably;...

  • Page 10: Unpacking

    11.6" Rugged Tablet M116K User Guide 2.2 Unpacking Check and identify the supplied accessories:   Tablet Computer Standard Battery BM101 Part No. 98K000A000D6   Power Adapter Power Cord and Plugs Part No. 922D065W19V1   Capacitive Stylus Quick Start Guide & Driver CD Part No.

  • Page 11: Description Of Parts

    Chapter 2: Getting Started 2.3 Description of Parts Dimensions: 300.67 x 201.97 x 22.5 mm Front: Left: Right: Item Description Item Description Use to attach a wrist strap or 11.6-inch display with String Hole other accessories. 11.6” PCAP LED backlight, acts as Touchscreen one of the inputs for the HDMI output to external...
  • Page 12 11.6" Rugged Tablet M116K User Guide Rear: Top: Bottom: Item Description Item Description Fan Intake Intake for waterproof fan. Barcode Scanner for Optional For optional add-on UHF reading of 1D/2D Expansion Slot Barcode RFID Reader or Smart barcode. (Optional) Card Reader.

  • Page 13: Indicators

    Chapter 2: Getting Started 2.4 Indicators Icon Indicator Description Power Indicator Blue– Tablet is ON No light– Tablet is OFF Battery Status Orange–AC adapter is plugged in and charging Green–AC adapter is plugged in and battery is full charged Solid Red - Low battery (<10%) Blinking Red –...

  • Page 14: Installing A Micro Sd Card

    11.6" Rugged Tablet M116K User Guide 2. Insert the battery with the connector-pins side first, and then lower the battery into the battery compartment. Make sure the battery is completely lowered into the compartment. Once fully inserted, the Battery Release Slider automatically locks. Battery will be flat against the housing once fully inserted.

  • Page 15: Installing 4G Lte Module

    Chapter 2: Getting Started 2.6.3 Installing 4G LTE Module Notice that 4G LTE feature is optional and may not be supported by your device. Check your order specifications for more details. The Tablet Computer supports 4G LTE data connection and fits a Micro-SIM card. Before installing fits a Micro-SIM card please install the 4G LTE module.

  • Page 16: Installing Sim Card (For 4G/Lte Equipped Devices)

    11.6" Rugged Tablet M116K User Guide 2.6.4 Installing SIM card (For 4G/LTE Equipped Devices) Notice that 4G LTE feature is optional and may not be supported by your device. Check your order specifications for more details. Caution Disconnect any cords connected to the tablet computer before installation or removing battery procedure.

  • Page 17: Charging Your Tablet

    Chapter 2: Getting Started 2.6.5 Charging Your Tablet The Tablet operates either on external AC power or internal battery power. It is recommended to use AC power when you start up the Tablet for the first time. Caution Use only the AC adapter included with your Tablet Computer. Using other AC adapters may damage the Tablet Computer and the Battery.

  • Page 18: Using Lan Port (Rj45)

    11.6" Rugged Tablet M116K User Guide 2.6.6 Using LAN Port (RJ45) Notice that the LAN Port (RJ45) is optional and may not be supported by your device. Check your order specifications for more details. 1. Connect the tablet PC to external devices using LAN cable.

  • Page 19: Chapter 3: Setting Up Windows For The First Time

    This chapter details how to setup the Windows that may be installed on the tablet for the first time. 3.1 Introduction The M116K Tablet Computer operates on Windows 10 IoT Enterprise operating system. Caution Make sure the battery is full charged before starting the Tablet Computer for the first time with internal battery power.
  • Page 20 11.6" Rugged Tablet M116K User Guide 3. On the Here's the legal stuff screen, read through the disclosures, then tap Accept. 4. Windows will then try to connect to network. Tap Skip this step to continue without a wireless connection as you can then set up the network later.
  • Page 21 Chapter 3: Setting Up Windows for the First Time 6. To create a local account, type your User name, password, and Password hint in the fields provided, and then tap Next. 7. The initial setup screens are complete, and the desktop is displayed. 8.

  • Page 22: Chapter 4: Operating The Device

    RFID, WWAN, WLAN, GPS features. Note: Please download the SDK from Winmate Download Center. >> M116K >> Development Kit or check the Driver CD which is shipped with the tablet. Please notice that HF RFID reader, Barcode reader are optional module, please make sure user have ordered the module before using the SDK.

  • Page 23: Shortcuts

    Chapter 4: Operating the Device Icon Description Allows users to configure short cut to quickly access programs with a few tabs. Shortcuts Allows users take a picture or record a video. User can also adjust setting related to camera in this menu option. Camera Enables/disables tablet computer’s hardware functions.

  • Page 24: Using Camera

    11.6" Rugged Tablet M116K User Guide 4.3 Using Camera This Hottab menu option allows users take a picture or record a video. Before use, make sure the camera is powered on under Devices ON/OFF menu with the following scenarios. To open camera interface: 1.

  • Page 25: Built-In Devices On/Off

    Chapter 4: Operating the Device 4.4 Built-in Devices On/Off This section describes how to get a quick access to set-up built-in devices, including turning on/off RF modules, setting up barcode reader, and RFID reader. Hottab Utility 4.4.1 Using the Wireless LAN (Wi-Fi) To use the wireless LAN (Wi-Fi) feature to connect to the network, perform the following procedure: 1.

  • Page 26: Using The Gps

    5. Now the GPS feature is ready to be used with an application utilizing the GPS. 4.4.4 Turn on/off the GPS External Antenna The vehicle dock of M116K Tablet PC supports external GPS antenna through standard SMA connector. To work with external GPS antenna, please make sure the tablet PC is well installed to vehicle dock, and the vehicle dock has connected with external GPS antenna.

  • Page 27: Using The Bluetooth

    Chapter 4: Operating the Device 4.4.5 Using the Bluetooth To enable the Bluetooth: 1. Launch the Hottab Utility 2. Tap on the Device ON/OFF button. 3. Check the status color of the Bluetooth icon: Item Status Color Description Orange Bluetooth is enabled. White Bluetooth is disabled.

  • Page 28: Using The Barcode Reader

    4.4.7 Using the Barcode Reader The 2D/1D Barcode Reader is optional for M116K Tablet PC and is not re-workable by the end user. To use this feature, please make sure the tablet PC is built-in barcode reader before use, or contact our sales contact window for more details.
  • Page 29 Chapter 4: Operating the Device 4.4.7.1 Device Configuring and Setting 1.Click on Windows and search for EZConfig-Scanning from the Start menu. 2.Click on EZConfig-Scanning v4_IE and allow the blocked content if browser is blocking the content. 3.Click on “Connected Device” icon and wait for system to discover the device (Honeywell N660X).
  • Page 30 11.6" Rugged Tablet M116K User Guide 4.Once Honeywell N660X is discovered please click “Configure Device” button as shown. 4.4.7.2 Scanning Mode Settings 1. Click Device Settings under the Input/Output settings section. 2. Select the desire scanning mode from the drop-down menu shown as below.
  • Page 31 Chapter 4: Operating the Device 3. After selecting a desire scanning mode, click on the “Save to Device” on the side bar. Scanning Mode Description Manual Trigger When in manual trigger mode, the scanner scans until a bar code is read, or until the trigger is released.
  • Page 32 11.6" Rugged Tablet M116K User Guide 4.4.7.3 Setting the 1D/2D Barcode Scanner Symbologies The barcode scanner is shipped with default settings shown below. If the default setting suits the usage requirement, setting symbologies is not necessary. Symbologies Default Settings: Symbologies...
  • Page 33 Chapter 4: Operating the Device Important: 1. The reset to default button will change all setting to default. 2. N660X could disconnect with system after clicking the reset to default button. If the Disconnection happened please scan barcodes below in the following steps. Step1.
  • Page 34 11.6" Rugged Tablet M116K User Guide 4.4.7.4 Adding a Prefix or Suffix 1. To add a Prefix or Suffix please click on “Data Formatting icon”. 2.Click on Editor button under the Prefix or Suffix section and create Prefix/Suffix value by typing in the block or select desire characters in the Control chars, Printable chars, and Extended ASCII.
  • Page 35 Chapter 4: Operating the Device 3. When you finish creating Prefix/Suffix, please click on “Save to Device” on the side bar. 4. For checking the functionality of Prefix/Suffix, please chick on “Scan Data Window” icon on the top. Then scan a barcode to verify if the Prefix/Suffix appear correctly.

  • Page 36: Using The Hf Rfid Reader

    4.4.8 Using the HF RFID Reader The HF RFID Reader is optional for M116K Tablet PC and is not re-workable by the end user. To use this feature, please make sure the tablet PC is built-in HF RFID reader before use, or contact our sales contact window for more details.
  • Page 37 Chapter 4: Operating the Device 4.4.8.1 RFID Trigger Setting Auto Scan The default setting for RFID trigger is Auto Scan. Under this setting, the RFID Reader will always be ready to scan tags. When the RFID tag is detected from RFID antenna, the data will be read automatically.
  • Page 38 11.6" Rugged Tablet M116K User Guide 4.4.8.2 Settings Sound The Sound check box defines whether a beep sound will come with the data scanning. Output to This setting defines the output type of the scanned data. Two options are available: Keyboard Wedge Under this setting, the data scanned is sent like keyboard data.
  • Page 39 Chapter 4: Operating the Device Item Description Prefix User can type in this field to define the characters BEFORE the data scanned. Suffix User can type in this field to define the characters AFTER the data scanned. The check box user can defines to append an “Enter” which is Append Enter followed by the characters.

  • Page 40: Turn On/Off The Light Sensor

    11.6" Rugged Tablet M116K User Guide Note: User can download the SDK from Winmate Download center website >> M116K >> Development Kit or check the Driver CD which is shipped with the tablet. 4.4.8.3 RFID Output Setting Select The default setting for built-in HF RFID Reader is to Read UID. For some RFID applications, user might need to read or write further block data;...

  • Page 41: Changing Touchscreen Modes

    Chapter 4: Operating the Device 4.4.10 Changing Touchscreen Modes The tablet computer supports three built-in operating modes for different usage scenarios: Mode Description In Hand/Rain mode the touchscreen rejects false inputs from liquid drops. When the liquid is removed, the touchscreen accepts touch inputs from bare fingertips. Supports input by: ...
  • Page 42 11.6" Rugged Tablet M116K User Guide 4.4.10.1 Switch via Built-in HotTab Utility To switch touchscreen mode via the HotTab: Launch the Hottab Utility Choose “Device ON/OFF” and then click on “Touch Set” icon  Under the “Touch Mode”, select the desired touch modes by tapping on the radio button.
  • Page 43 Chapter 4: Operating the Device...

  • Page 44: Chapter 5: Frequently Used Settings

    Chapter 5: Frequently Used Settings 5.1 Screen Resolution Scaling and Setting The M116K rugged tablet’s 1920 x 1080 Full HD high resolution display is perfect for viewing image, video, or other applications; however, Windows user interface (icons, buttons, and other user interface elements) may be too small to read and operate at the default Windows settings.

  • Page 45: Changing Screen Resolution

    Chapter 5: Frequently Used Settings 5.1.2 Changing Screen Resolution Alternatively, instead of changing the display scaling setting, user may choose to change the overall resolution setting to make screen elements bigger. 1. Tap and hold anywhere on the desktop for 3 seconds and release to bring up the context menu, and select “Display settings”...

  • Page 46: Replacing Battery

    11.6" Rugged Tablet M116K User Guide 2. The native resolution of M116K is 1920 x 1080. Click on the dropdown option next to “Resolution” and select the resolution by tapping on the scale: 3. Hit “Apply”. A prompt “Display Settings” prompt will show up to ask the user if the applied resolution is usable.

  • Page 47: Using Recovery Wizard To Restore Computer

    5.3 Using Recovery Wizard to Restore Computer M116K Tablet Computer has a dedicate recovery partition stored on the hard drive of the tablet to enable quick one-key recovery process. This partition occupies about 11 GB of the storage space, and comes built-in to each M116K Tablet Computer.
  • Page 48 11.6" Rugged Tablet M116K User Guide 4. A warning message about data loss will show up. Make sure data is backed up before recovery, and click on “Yes” to continue. 5. Wait till the recovery process to complete. During the recovery process, a command prompt will...

  • Page 49: Docking Connector Pin Definition

    6. After recovery is completed, please press any key to continue, and the tablet computer will shut down automatically. 5.4 Docking Connector Pin Definition M116K tablet computer supports one 19-pin docking connector at the bottom side. The pin definition is listed as the following table. Pin No.
  • Page 50 11.6" Rugged Tablet M116K User Guide Go to "Device Manager", right click on the COM number need to be changed, and tap on "Properties" to open the setting page. Tap on "Port Setting" tab and click on "Advanced" button. Tap on the dropdown list and choose the correct COM Port Number (refer to the COM Port...

  • Page 51: Gigalan Port Definition

    5.6 GigaLAN Port Definition Notice that GigaLAN port is an optional feature of the M116K Rugged Tablet and may not be present in your device. Please check your order specifications for more details. Pin №...
  • Page 52 11.6" Rugged Tablet M116K User Guide 3. Once the Bluetooth & other devices Menu appears, click “More Bluetooth options” under Related settings section as shown below. 4. go to “Options” tab, and make sure that in the Discovery section, the computer is set to “Allow Bluetooth devices to find this computer”, as shown below:...
  • Page 53 Chapter 5: Frequently Used Settings 6. You are in “Add COM Port” window. Choose “Incoming (device initiates the connection)”, and click “OK”. 7. The computer will automatically assign COM Port to the Bluetooth connection. In the screenshot below, COM4 is allocated. Click OK to continue.

  • Page 54: Set Up The Barcode Scanner For Bluetooth Pairing

    11.6" Rugged Tablet M116K User Guide 8. Next, the user has to configure the application that is used to accept the scanned data from the wireless Bluetooth Barcode Scanner. The application has to be configured to accept the same COM Port that has been assigned for the Bluetooth Serial Port Profile in the previous step.
  • Page 55 Chapter 5: Frequently Used Settings 5. In Add a Bluetooth Device window, click Next to connect the Barcode Scanner to the Computer. In order to ensure that Bluetooth Device is successfully pared to the Computer, follow the steps below: 1. Locate the Bluetooth icon in the Notification Area. Select Show Bluetooth Devices. You can access this menu in the Control Panel: Control Panel ...

  • Page 56: Chapter 6: Troubleshooting

    11.6" Rugged Tablet M116K User Guide Chapter 6: Troubleshooting 6.1 Basic Troubleshooting Problem Solution  The removable battery is not Make sure the AC adapter is properly connected, and charging. that the removable battery is properly inserted.  Nothing appears on the screen.
  • Page 57 Chapter 6: Troubleshooting Problem Solution  No sound is produced. Adjust volume of the tablet computer by pressing on the volume rocker.  If using an external audio device, make sure that the cable is properly connected.  I cannot project the tablet computer Make sure the VGA driver is installed.
  • Page 58 11.6" Rugged Tablet M116K User Guide Appendix Appendix A: Product Specifications M116K Model Name Size 11.6-inch display with LED Backlight Resolution 1920 x 1080 Full HD Panel Brightness 850 nits with direct optical bonding for sunlight readability Contrast Ratio 1000:1...
  • Page 59 Appendix Model Name M116K Built-in dual digital mic with noise cancellation Microphone Audio Speaker 2 x 1 watt front-facing speakers Web Camera 2MP front camera Cameras Rear Camera 8MP rear camera with autofocus and LED light Optional 1D/2D Barcode Reader...
  • Page 60 Winmate Inc. 9F, No.111-6, Shing-De Rd., San-Chung District, New Taipei City 24158, Taiwan, R.O.C www.winmate.com Copyright © 2018 Winmate Inc. All rights reserved.
