- Page 1 Reach In Bottle Coolers Models BB-CN-0005-HC, 0014-HC, 0017-HC, 0026-HC Items 50038, 50039, 50040, 50041 Instruction Manual Revised - 09/28/2017 Toll Free: 1-800-465-0234 Fax: 905-607-0234 Email: service@omcan.com www.omcan.com...
-
Page 2: Table Of Contents
Table of Contents Model BB-CN-0005-HC / Model BB-CN-0014-HC Model BB-CN-0017-HC / Model BB-CN-0026-HC Section Page General Information --------------------------------------------------------------------------- 3 - 4 Safety and Warranty --------------------------------------------------------------------------- 4 - 5 Technical Specifications -------------------------------------------------------------------------- 6 Installation / Operation ------------------------------------------------------------------------ 6 - 8 Maintenance... -
Page 3: General Information
If the package has suffered rough handling, bumps or damage (visible or concealed), please note it on the bill of lading before accepting the delivery and contact Omcan within 24 hours, so we may initiate a claim with the carrier. A detailed report on the extent of the damage caused to the machine must be filled out within three days, from the delivery date shown in the shipping documents. -
Page 4: Safety And Warranty
Si el paquete ha sufrido un manejo de poco cuidado, golpes o daños (visible o oculto) por favor anote en la factura antes de aceptar la entrega y contacte Omcan dentro de las 24 horas, de modo que podamos iniciar una reclamación con la compañia. - Page 5 Do not set the desired temperature out of the recommended temperature range: (Ref: 32°F - 50°F). 1 YEAR PARTS AND LABOUR WARRANTY Within the warranty period, contact Omcan Inc. at 1-800-465-0234 to schedule an Omcan authorized service technician to repair the equipment locally.
-
Page 6: Technical Specifications
Technical Specifications Model BB-CN-0005-HC BB-CN-0014-HC BB-CN-0017-HC BB-CN-0026-HC Horsepower 1/4+ Net Volume 141 L / 5 cu. ft. 382 L / 13.5 cu. ft. 488 L / 17.23 cu. ft. 730 L / 25.8 cu. ft. Temperature 0.5 - 3.3°C / 33 - 38°F... -
Page 7: Installation / Operation
Installation / Operation - Unit may malfunction if surface is uneven. • Install the unit in an indoor, well-ventilated area. - Unit performs more efficiently in a well-ventilated area. - For best performance, please maintain clearance of 6” on the back of the unit. - Outdoor use may cause decreased efficiency and damage to the unit. -
Page 8: Maintenance
Installation / Operation CAUTION Setting the temperature control to the coldest setting may cause the Evaporator coil to freeze and ice up. This will eventually result in a warmer Cabinet temperature. Temperature range from 7 (coldest) to 1 (warmest). Do not load Product above the top crossbar. Doing so will harm the Refrigeration. -
Page 9: Troubleshooting
Maintenance surface. • Wash door gaskets on a regular basis, preferably weekly. Simply remove door gasket from the frame of the door, soak in warm water and soap for thirty (30) minutes, dry with soft cloth, and replace. • Check door gaskets for proper seal after they are replaced. •... - Page 10 Cooler Back Bar 5 cu ft Reach In 50038 BB-CN-0005-HC JBC-25-HC 115V/60/1 ETL cETLus INTERTEK Cooler Back Bar 13.5 cu ft Reach In 50039 BB-CN-0014-HC JBC-50-HC 115V/60/1 ETL cETLus INTERTEK Cooler Back Bar 17.2 cu ft Reach In 50040 BB-CN-0017-HC JBC-65-HC 115V/60/1 ETL cETLus INTERTEK Cooler Back Bar 25.8 cu ft Reach In...
-
Page 11: Parts Breakdown
Parts Breakdown Model BB-CN-0005-HC 50038... - Page 12 Parts Breakdown Model BB-CN-0005-HC 50038 Item No. Description Position Item No. Description Position Item No. Description Position Compressor Mounting Plate for JBC- Terminal Cover of Stopping Bar for 37743 37764 72000 Evaporator for JBC-25-HC 25-HC JBC-25-HC 71986 Key for JBC-25-HC 71993 Stopping Bar for JBC-25-HC 37785...
- Page 13 Parts Breakdown Model BB-CN-0014-HC 50039...
- Page 14 Parts Breakdown Model BB-CN-0014-HC 50039 Item No. Description Position Item No. Description Position Item No. Description Position Compressor Mounting Plate for JBC- 37743 37762 Door Lock for JBC-50-HC 37781 Controller Mounting Plate for JBC-50-HC 50-HC Bottom Cover of Machine Room for...
- Page 15 Parts Breakdown Model BB-CN-0017-HC 50040...
- Page 16 Parts Breakdown Model BB-CN-0017-HC 50040 Item No. Description Position Item No. Description Position Item No. Description Position Compressor Mounting Plate for JBC- 37744 37762 Door Lock for JBC-65-HC 37781 Controller Mounting Plate for JBC-65-HC 65-HC Bottom Cover of Machine Room for 37745 37763 Plate of Lock for JBC-65-HC...
- Page 17 Parts Breakdown Model BB-CN-0026-HC 50041...
- Page 18 Parts Breakdown Model BB-CN-0026-HC 50041 Item No. Description Position Item No. Description Position Item No. Description Position Compressor Mounting Plate for JBC- Terminal Cover of Stopping Bar for 37743 37764 72010 Evaporator for JBC-95-HC 95-HC JBC-95-HC Bottom Cover of Machine Room for 37745 72005 Stopping Bar for JBC-95-HC...
-
Page 19: Electrical Schematics
Electrical Schematics Model BB-CN-0005-HC 50038... - Page 20 Electrical Schematics Model BB-CN-0014-HC 50039...
- Page 21 Electrical Schematics Model BB-CN-0017-HC 50040...
- Page 22 Electrical Schematics Model BB-CN-0026-HC 50041...
-
Page 23: Warranty Registration
Warranty Registration Thank you for purchasing an Omcan product. To register your warranty for this product, complete the information below, tear off the card at the perforation and then send to the address specified below. You can also register online by visiting: Merci d’avoir acheté... - Page 24 Since 1951 Omcan has grown to become a leading distributor of equipment and supplies to the North American food service industry. Our success over these many years can be attributed to our commitment to strengthen and develop new and existing relationships with our valued customers and manufacturers.
