Back Bar Bottle Coolers
Models BD-CN-0007-HC, BB-CN-0012-DH, BD-CN-0019-HC,
BB-CN-0016-DH, BD-CN-0023-HC, BB-CN-0020-DH, BD-CN-0032-HC
Items 50066, 50063, 50067, 50064, 50068, 50065, 50069
Instruction Manual
Revised - 03/12/2021
Toll Free: 1-800-465-0234
Fax: 905-607-0234
Email: service@omcan.com
www.omcan.com
