- Page 1 Reach In Bottle Coolers Models BB-CN-0005, 0014, 0017, 0026 Items 42945, 31859, 31860, 42946 Instruction Manual Revised - 02/24/2017 Toll Free: 1-800-465-0234 Fax: 905-607-0234 Email: service@omcan.com www.omcan.com...
- Page 2 Table of Contents Model BB-CN-0005 / Model BB-CN-0014 Model BB-CN-0017 / Model BB-CN-0026 Section Page General Information --------------------------------------------------------------------------- 3 - 4 Safety and Warranty --------------------------------------------------------------------------- 4 - 5 Technical Specifications -------------------------------------------------------------------------- 6 Installation / Operation ------------------------------------------------------------------------ 6 - 8 Maintenance...
-
Page 3: General Information
If the package has suffered rough handling, bumps or damage (visible or concealed), please note it on the bill of lading before accepting the delivery and contact Omcan within 24 hours, so we may initiate a claim with the carrier. A detailed report on the extent of the damage caused to the machine must be filled out within three days, from the delivery date shown in the shipping documents. - Page 4 Si el paquete ha sufrido un manejo de poco cuidado, golpes o daños (visible o oculto) por favor anote en la factura antes de aceptar la entrega y contacte Omcan dentro de las 24 horas, de modo que podamos iniciar una reclamación con la compañia.
- Page 5 Do not set the desired temperature out of the recommended temperature range: (Ref: 32°F - 50°F). 1 YEAR PARTS AND LABOUR WARRANTY Within the warranty period, contact Omcan Inc. at 1-800-465-0234 to schedule an Omcan authorized service technician to repair the equipment locally.
-
Page 6: Technical Specifications
Technical Specifications Model BB-CN-0005 BB-CN-0014 BB-CN-0017 BB-CN-0026 Power 0.18 HP / 0.14 kW 0.5 HP / 0.38 kW 0.64 HP / 0.48 kW 0.93 HP / 0.7 kW Net Volume 141 L / 5 cu.ft. 382 L / 13.5 cu. ft. - Page 7 Installation / Operation CABINET LOCATION GUIDELINES • Install the unit on strong and leveled surfaces. - Unit may make unpleasant noises if surface is uneven. - Unit may malfunction if surface is uneven. • Install the unit in an indoor, well-ventilated area. - Unit performs more efficiently in a well-ventilated area.
-
Page 8: Maintenance
Installation / Operation CAUTION Setting the temperature control to the coldest setting may cause the Evaporator coil to freeze and ice up. This will eventually result in a warmer Cabinet temperature. Temperature range from 7 (coldest) to 1 (warmest). Do not load Product above the top crossbar. Doing so will harm the Refrigeration. -
Page 9: Maintenance
Maintenance surface. • Wash door gaskets on a regular basis, preferably weekly. Simply remove door gasket from the frame of the door, soak in warm water and soap for thirty (30) minutes, dry with soft cloth, and replace. • Check door gaskets for proper seal after they are replaced. •... -
Page 10: Troubleshooting
For service call 1-800-465-0234. REFERENCE Item Number Model Number Description Manufacturer Model Number Cooler Back Bar 5 cu ft Reach In 42945 BB-CN-0005 JBC-25 115V/60/1 ETL cETLus INTERTEK Cooler Back Bar 13.5 cu ft Reach In 31859 BB-CN-0014 JBC-50 115V/60/1 ETL cETLus INTERTEK Cooler Back Bar 17.2 cu ft Reach In... -
Page 11: Parts Breakdown
Parts Breakdown Model BB-CN-0005 42945... - Page 12 Parts Breakdown Model BB-CN-0005 42945 Item No. Description Position Item No. Description Position Item No. Description Position 37743 Compressor Mounting Plate for JBC25 37764 Terminal Cover of Stopping Bar for JBC25 72000 Evaporator for JBC25 71986 Key for JBC25 71993...
- Page 13 Parts Breakdown Model BB-CN-0014 31859...
- Page 14 Parts Breakdown Model BB-CN-0014 31859 Item No. Description Position Item No. Description Position Item No. Description Position 37743 Compressor Mounting Plate 37762 Door Lock 37781 Controller Mounting Plate 37745 Bottom Cover of Machine Room 37763 Plate of Lock 37782 Evaporator 37746 Front Shutter 37764...
- Page 15 Parts Breakdown Model BB-CN-0017 31860...
- Page 16 Parts Breakdown Model BB-CN-0017 31860 Item No. Description Position Item No. Description Position Item No. Description Position 37744 Compressor Mounting Plate 37762 Door Lock 37781 Controller Mounting Plate 37745 Bottom Cover of Machine Room 37763 Plate of Lock 37783 Evaporator 37746 Front Shutter 37764...
- Page 17 Parts Breakdown Model BB-CN-0026 42946...
-
Page 18: Parts Breakdown
Parts Breakdown Model BB-CN-0026 42946 Item No. Description Position Item No. Description Position Item No. Description Position 37743 Compressor Mounting Plate for JBC95 37764 Terminal Cover of Stopping Bar for JBC95 72010 Evaporator for JBC95 Bottom Cover of Machine Room for 37745 72005 Stopping Bar for JBC95... - Page 19 Electrical Schematics Model BB-CN-0005 42945...
- Page 20 Electrical Schematics Model BB-CN-0014 31859...
- Page 21 Electrical Schematics Model BB-CN-0017 31860...
- Page 22 Electrical Schematics Model BB-CN-0026 42946...
-
Page 23: Warranty Registration
Warranty Registration Thank you for purchasing an Omcan product. To register your warranty for this product, complete the information below, tear off the card at the perforation and then send to the address specified below. You can also register online by visiting: Merci d’avoir acheté... - Page 24 Since 1951 Omcan has grown to become a leading distributor of equipment and supplies to the North American food service industry. Our success over these many years can be attributed to our commitment to strengthen and develop new and existing relationships with our valued customers and manufacturers.
