Operating instructions
CombiCooler V2000
Refrigerator/freezer

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CombiCooler V2000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for V-ZUG CombiCooler V2000

Summary of Contents for V-ZUG CombiCooler V2000

  • Page 1 Operating instructions CombiCooler V2000 Refrigerator/freezer...
  • Page 2 The model number corresponds to the first alphanumerics on the identification plate. These operating instructions apply to: Model designation Type Size system CombiCooler V2000 CCO2T-51100 SMS 55 / Euro 60 Variations depending on the model are noted in the text. © V-ZUG Ltd, CH-6302 Zug, 2020...

  • Page 3: Table Of Contents

    Basic procedure .......... 10 Switching the appliance on ....... 10 Setting the temperature ........ 10 Switching the appliance off........ 11 Using the appliance functions  11 Brief description of the appliance functions... 16 V-ZUG-Home  18 Conditions ............. 18 Initial set-up............ 18 Glass shelves and door trays  19 Tips and tricks  19...

  • Page 4: Safety Precautions

    Safety precautions Symbols used Denotes important safety precau- ▪ This appliance can be used tions. Failure to observe said precautions by children aged 8 and above can result in injury or in damage to and by persons with reduced the appliance or fittings! physical, sensory or mental Information and precautions that capabilities, or lack of experi-...

  • Page 5: Appliance-Specific Safety Precautions

    1 Safety precautions ▪ Refer to the identification plate for in- turer or its Customer Services formation on the required mains or a similarly qualified person voltage, current type and fuse protec- in order to avoid hazard. tion. ▪ All plastering, plasterboarding, wall pa- Appliance-specific safety pering or painting work is to be carried precautions...
  • Page 6 1 Safety precautions ▪ WARNING: Do not locate multiple port- the appliance and fittings, as well as af- able socket-outlets or portable power fect the functioning of the appliance. If supplies at the rear of the appliance. the appliance is not working properly or ▪...
  • Page 7 1 Safety precautions ▪ Avoid prolonged skin contact with frozen food. Never consume frozen food or ice cubes that are straight out of the freezer compartment or too cold. Risk of burns from freezing! ▪ Do not remove the evaporation tray on the compressor.

  • Page 8: Using For The First Time

    Using for the first time Before operating the newly installed appliance for the first time, the following steps should be taken: ▸ Remove packaging and transport materials as well as any protective film from the in- terior. ▸ Clean the interior and accessories with lukewarm water or a mild soapy solution (wa- ter and washing-up liquid) and dry thoroughly.

  • Page 9: Operating And Display Elements

    BACK: Cancel/discard entry ON/OFF (hold depressed for 3 seconds) Display elements: Operating mode User setting SilentPlus Display brightness PartyCooling Switch off button tone Holiday function V-ZUG-Home Sabbath mode Temperature unit Value and status display Refrigerating/Freezing zone Freezing zone active Fast cooling/freezing active...

  • Page 10: Operating The Appliance

    4 Operating the appliance Operating the appliance Basic procedure ▪ Use the navigation arrows (up/left) and (down/right) to select a settable value and to navigate through the operating steps. ▪ The selected set values are displayed for 5 seconds when the door is opened, and then the actual temperature values are displayed.

  • Page 11: Switching The Appliance Off

    5 Using the appliance functions ▸ Confirm with the button to accept the entry. – The temperature setting has been entered successfully. – The temperature will be reached after a few hours, depending on the setting. The effective temperature may at times be different from the selected set value if the door is open for an extended period of time or if warm foods have been placed inside.
  • Page 12 5 Using the appliance functions Function Description Fast cooling/ Preparing the refrigerating zones ideally for loading food and food freezing items after a shopping trip. Activating ▸ Touch the button. ▸ Select the refrigerator or freezer compartment using ▸ Confirm with the button.
  • Page 13 5 Using the appliance functions Function Description SilentPlus Noise-reduced operation Activating ▸ Touch the button. ▸ appears flashing. ▸ Confirm with the button. ▸ Adjust the temperature selected for the freezer compartment using the buttons if ne- cessary. ▸ Confirm with the button.
  • Page 14 5 Using the appliance functions Function Description Holiday function Reduced cooling capacity for the refrigerator compartment (14 °C). The freezer compartment remains at the set temperature value. Activating ▸ Touch the button. ▸ Select the button until appears flashing. ▸ Confirm with the button.
  • Page 15 5 Using the appliance functions Function Description V-ZUG-Home Interaction with the appliance via the app (see page 18). Activating ▸ Touch the button. ▸ Select the button until appears flashing. ▸ Confirm with the button and select «On» in the display using ▸...

  • Page 16: Brief Description Of The Appliance Functions

    5 Using the appliance functions Function Description Temperature unit Switching between the unit of temperature. °C / °F ▸ Touch the button. ▸ Select the button until appears flashing. ▸ Confirm with the button. Demo mode* This setting enables specialist retailers to put the appliance into the showroom mode for demonstration purposes.
  • Page 17 5 Using the appliance functions Fast cooling/freezing The fast cooling/freezing functions allow larger quantities of food, e.g. after a shopping trip or freezing pre-cooked meals, to be cooled more quickly. The temperature of the re- frigerating zone is lowered to the coldest value for 24 hours and similarly the temperat- ure of the freezing zone is lowered to the coldest value for 54 hours.

  • Page 18: V-Zug-Home

    – A bluetooth pairing request appears in the V-ZUG App. – A 6-digit PIN appears in the display of the appliance. ▸ Enter the 6-digit PIN in the V-ZUG App and confirm the bluetooth pairing request. – All available wireless networks appear in the V-ZUG App.

  • Page 19: Glass Shelves And Door Trays

    7 Glass shelves and door trays Further information can be found in the V-ZUG-Home operating instructions or on home.vzug.com. Glass shelves and door trays The height of the glass shelves in the refrigerator compartment and the door trays on the inside of the refrigerator compartment door can be adjusted.

  • Page 20: Storing Food And Food Items

    8 Tips and tricks Storing food and food items The example arrangement shows the zones and areas in the appliance that are generally suitable for certain food and food items. 1 Cheese, butter, jam, tortes, desserts, milk and milk products, pre-prepared or cooked meals, ready-made products, sausages, meat, poultry,...

  • Page 21: Notes On Saving Energy

    ▪ Store food that releases moisture in closed containers or covered in the refrigerator compartment. Moisture reduces the cooling capacity. ▪ For ideal air circulation: Do not store food and food items too close to each other. ▪ Turn the SilentPlus and V-ZUG-Home functions off when not in use. Care and maintenance Cleaning For the hygienic storage of food, the interior should always be kept clean.

  • Page 22: Defrosting

    10 Noises and warnings Defrosting The fully automatic NoFrost system keeps the freezer compartment frost-free. The refri- gerator compartment also defrosts several times a day. This means that manual defrost- ing is unnecessary. Keep the collection channel and the drain pipe clean so that the water can flow un- impeded.

  • Page 23: Warnings

    10 Noises and warnings Keyword Cause Remarks Buzzing Compressor/fan Normal operating noise made by the cooling unit. Gurgling, bubbling, Cooling circuit Normal operating noise as refrigerant flows hissing through the cooling circuit. Hissing Cooling circuit Normal operating noise as refrigerant is injected into the evaporator.

  • Page 24: Trouble-Shooting

    11 Trouble-shooting Trouble-shooting This section lists faults that can be solved simply by following the instructions given. If the fault cannot be remedied, please contact Customer Services. Before contacting Cus- tomer Services: ▸ please note down the serial number (SN), which is shown on the identification plate, as well as ▸...
  • Page 25 11 Trouble-shooting Malfunction Possible cause Solution/Measures Illumination is flash- ▪ Appliance door is left open ▸ Close the appliance door. ing and an acoustic for longer than 5 minutes. – If the alarm is still being emit- signal is emitted. ▪...
  • Page 26 11 Trouble-shooting Malfunction Possible cause Solution/Measures Error message F_ _ ▪ Various situations can lead ▸ Contact Customer Services. to an F message. Malfunction Possible cause Solution/Measures The temperature and ▪ The refrigerator compart- ▸ Touch any button. refrigerating zone(s) ment temperature is 10 °C –...

  • Page 27: Disposal

    12 Technical data Technical data Product data ▸ See the identification plate, energy label and www.vzug.com. External dimensions ▸ See installation instructions Electrical connection ▸ See identification plate Energy consumption The declared energy consumption was determined with a kitchen cabinet depth of 560 mm.

  • Page 28: Index

    Index Appliance disposal .......... 27 Model designation ..........2 Appliance functions ......... 11 Model number ............. 2 Appliance installation ......... 5 Noise-reduced operation........ 13 Button tone on/off..........15 Noises ..............22 Notes ..............30 Care and maintenance ........21 Cleaning............. 21 ON/OFF ............
  • Page 29 14 Index Using for the first time........5, 8 Validity..............2 V-ZUG App ............18 V-ZUG-Home..........15, 18 Warnings............23 WLAN connection ..........18...
  • Page 30 Notes...

  • Page 31: Service & Support

    Your repair order Call the free service number 0800 850 850 to contact your nearest V-ZUG service centre. You can arrange an on-site visit by us by phone if you wish. General queries, accessories and service agreement V-ZUG will be happy to help you with any general administrative or technical queries, to accept your orders for accessories and spare parts and to inform you about our pro- gressive service agreements.
  • Page 32 Temperature unit Value and status display Refrigerating/Freezing zone Freezing zone active Fast cooling/freezing active 1087034-R02 V-ZUG Ltd, Industriestrasse 66, CH-6302 Zug Tel. +41 58 767 67 67, Fax +41 58 767 61 61 info@vzug.com, www.vzug.com Service Centre: Tel. 0800 850 850...
