- Page 1 CLPKT90 (8907) Flat arm 90° pocket door mount (closer on wall) Installation instructions 08280151 – 09-2019 | EN |...
- Page 2 8907 AF PKT 90° Installation Instructions Table of Contents Table of contents 1 Technical specifications Overview Pocket depth chart Tools recommended Handing the door Instructions - 90° pocket door mount Installing surface closer Secure arm to closer Securing arm shoe to door...
-
Page 3: Technical Specifications
Metal: 7/32” drill bit; 1/4-20 3/16” flat head screwdriver Wood: 3/8” and 5/32” bit 5mm hex key 1/2” box wrench 1.4 Handing the door Fig.1 Interior side of door Left hand door (LH) Right hand door (RH) Hinge Hinge 08280151 09-2019 CLPKT90 POCKET CLOSERS... - Page 4 Main arm Arm shoe 2.3.1 Attach arm shoe to door. 2.3.2 Adjust connecting arm rod length Screw according to pocket depth chart. 2.3.3 Tighten screw. Connecting arm “A” Center of pivot point Center of pivot point 08280151 09-2019 CLPKT90 POCKET CLOSERS...
-
Page 5: Install Covers
Increase latch speed: Turn valve counter-clockwise Install covers Fig.6 Snap valve adjustment wrench inside 4.1.1 Place tab in cover slot, opposite main cover. arm. 4.1.2 Place cover over closer and fasten securely with screws provided. CLPKT90 POCKET CLOSERS 08280151 09-2019... - Page 6 DORMA USA, Inc. T: 800-523-8483...
