King/Ashley Pellet Stove
SAVE THESE INSTRUCTIONS
THIS MANUAL WILL HELP YOU TO OBTAIN EFFICIENT, DEPENDABLE
SERVICE FROM THE HEATER, AND ENABLE YOU TO ORDER REPAIR PARTS
CORRECTLY. KEEP IN A SAFE PLACE FOR FUTURE REFERENCE.
• Please read this entire manual before installation and use of this
appliance. Failure to follow these instructions could result in property
damage, bodily injury, or even death.
• Contact your local building or fire officials about obtaining permits,
restrictions and installation inspection requirements in your area.
• If your heater is not properly installed, a house fire may result. For
everyone's safety, follow all Installation and Operating Directions.
Never use makeshift compromises during the installation of this
appliance. Contact your local building or fire officials about
Ce produit peut vous exposer à des agents chimiques, y compris au monoxyde de
restrictions and installation inspection requirements in your area.
carbone, lesquels sont reconnus dans l'État de la Californie comme causant le cancer et
des malformations congénitales ou autres dommages au fœtus. Pour obtenir plus de
renseignements, veuillez consulter le site www.P65warnings.ca.gov
CALIFORNIA PROPOSITION 65 WARNING:
This product can expose you to chemicals including carbon monoxide, which
is known to the State of California to cause cancer, birth defects and/or other
reproductive harm. For more information, go to www.P65warnings.ca.gov
United States Stove Company
227 Industrial Park Rd.,
South Pittsburg, TN 37380
PH: (800) 750-2723
www.usstove.com
5500XL
5500
5500XL
Models 5500/5500M
5500M
Certified to ASTM E1509-12 (2017), and Certified
to ULC S627, 2000, and(UM) 84-HUD
This unit is not intended to be used as a
primary source of heat.
U.S. Environmental Protection Agency
Certified to comply with 2020 particulate
emissions standards.
ALL
PICTURES
SHOWN
ILLUSTRATIVE PURPOSES ONLY. ACTUAL
PRODUCT MAY VARY DUE TO PRODUCT
ENHANCEMENT.
This manual is subject to change without
notice.
ARE
FOR
R
Report #: F20-570
851641T-0504j
55
Advertisement
Table of Contents
Related Manuals for United States Stove King
Summary of Contents for United States Stove King
- Page 1 King/Ashley Pellet Stove 5500XL 5500XL Models 5500/5500M 5500M 5500 Certified to ASTM E1509-12 (2017), and Certified SAVE THESE INSTRUCTIONS to ULC S627, 2000, and(UM) 84-HUD THIS MANUAL WILL HELP YOU TO OBTAIN EFFICIENT, DEPENDABLE This unit is not intended to be used as a SERVICE FROM THE HEATER, AND ENABLE YOU TO ORDER REPAIR PARTS primary source of heat.
-
Page 2: Safety Precautions
Safety Precautions • IMPORTANT: Read this entire manual before installing • DO NOT CONNECT TO OR USE IN CONJUNCTION WITH and operating this product. Failure to do so may result ANY AIR DISTRIBUTION DUCTWORK UNLESS SPECIFICALLY in property damage, bodily injury, or even death. APPROVED FOR SUCH INSTALLATION. -
Page 3: Specifications
Your pellet stove has been safety tested and listed to ASTM E1509-12 (201&), ULC-S627-00 and (UM) 84-HUD. This manual describes the installation and operation of the King/Ashley model 5500, 5500M pellet stove. This heater meets the 2020 U.S. Environmental Protection Agency’s crib wood emission limits for wood-heaters sold after May 15, 2020. -
Page 4: Installation Options
Installation This heater is designed to burn only PFI Premium grade pellets. This appliance can also burn pellets rated as standard after May 16, 2015 DO NOT BURN: 1. Garbage; 10. Salt water driftwood or other previously salt water 2. Lawn clippings or yard waste; saturated materials;... - Page 5 CLEARANCES Your pellet stove has been tested and listed for installation in residential, mobile home, and alcove applications in accordance with the clearances given in FIGURES 3-5 and TABLE 1. Clearances may only be reduced by means approved by the regulatory authority. NOTE: Distance “C”...
-
Page 6: Venting Requirements
VENTING REQUIREMENTS • Install vent at clearances specified by the vent manufacturer. • Do not connect the pellet vent to a vent serving any other appliance or stove. • Do not install a flue damper in the exhaust venting system of this unit. The following installation guidelines must be followed to ensure conformity with both the safety listing of this stove and to local building codes. -
Page 7: Vent Termination Clearances
VENT TERMINATION CLEARANCES A. Minimum 4-foot (1.22m) clearance below or beside any door or window that opens. B. Minimum 1-foot (0.3m) clearance above any door or window that opens. C. Minimum 3-foot (0.91m) clearance from any adjacent building. D. Minimum 7-foot (2.13m) clearance from any grade when adjacent to public walkways. -
Page 8: Special Mobile Home Requirements
OUTSIDE AIR SUPPLY (OPTIONAL, UNLESS INSTALLING IN A MOBILE HOME) Depending on your location and home construction, outside air may be necessary for optimal performance. Metal pipe (solid or flexible) must be used for the outside air installation. PVC pipe is NOT approved and should NEVER be used. -
Page 9: Understanding Your Stove
As pellets enter the burn pot and ignite, outside air is drawn across the fuel and heated during the combustion process which is then pulled through the heat exchanger by the exhaust motor or draft fan. As the stove heats up, room air is circulated around the heat exchanger by means of a room air blower, distributing warm air into the room. -
Page 10: Control Panel Overview
Control Panel Overview Turning the heater ON/OFF, as well as adjustments for the fuel feed rate and room fan speed are performed by pressing the appropriate button(s) on the control panel which is located on the lower left-hand side of your heater. -
Page 11: Thermostat Hook-Up
Thermostat Hook-Up The Jumper Must Be Removed First 1. Put female terminals on the lead wires to your low voltage thermostat. 2. Plug one thermostat lead onto each of the terminal posts on the circuit board. IMPORTANT NOTE: The purpose of the T’Stat is make stove cycle... -
Page 12: Operation
Operation UNIT PREPARATION After carefully unpacking and reading the instructions for installing your stove, you will need to perform the following steps: • Attach the included spring handle to the door handle by screwing it on in a respective location. •... -
Page 13: Shutdown Procedure
• Attempts to achieve heat output rates that exceed heater design specifications can result in permanent damage to the heater. 1. Verify that the hopper is clean and free of foreign matter. 2. Verify that all of the required exhaust/inlet connections have been made in accordance with this manual and that the stove is plugged into an outlet (an outlet surge protector is highly recommended). -
Page 14: Maintenance
the heater will operate on the highest setting, we recommend to operate your heater on this setting for only a short period of time. (1 hour etc.) Your pellet stove also includes an auto-start igniter as a standard feature. The use of other fire starter materials (wood chips, starter gel, etc.) is not necessary. -
Page 15: Blower Motors
DOOR AND GLASS GASKETS Inspect the main door and glass window gaskets periodically. The main door may need to be removed to have frayed, broken, or compacted gaskets replaced by your authorized dealer. The glass gasket has a gap at the bottom for the airwash. -
Page 16: Troubleshooting
Trouble Shooting • Disconnect the power cord before performing any maintenance! NOTE: Turning the ON/OFF Switch to ”OFF” does not disconnect all power to the electrical components of the stove. • Never try to repair or replace any part of the stove unless instructions for doing so are given in this manual. All other work should be done by a trained technician. -
Page 17: Display Indicators
Error Codes and Display Indicators Error Error Description Possible Causes Code Inadequate ventilation. Room fan failure. Err1 The high limit temperature sensor has tripped. Exhaust Blockage. Electrical Open in wiring. Hopper Empty. Auger output failure or jam. Err2 Stove ran out of fuel during normal operation. Flame of fuel quality caused fire to burn too slowly or go out. -
Page 18: Parts Diagram/List
Parts Diagram/List Model 5500 Item Part No. Title Qty. 891167 Spring Handle 25517 Handle, Door 25490 Door Weldment 88082 3/4” Rope Gasket 4.2 ft 88087 Glass Gasket 3 ft 891186 Glass Retainer, Bottom 891188 Glass Retainer, Top 891166 Ceramic Glass Model 5500M Item Part No. -
Page 19: Parts Diagram
Parts Diagram... - Page 20 Parts List Item Part # Title 80473 Exhaust Blower 86624 Burnpot Assembly 88118 Igniter Flange Gasket 86625 Burnpot Housing Assy. 891169 Heater Hose 1.5” 86628 Exhaust Duct Weldment 891141 Auger 86633 Igniter Tube Weldment 80488 Drive Motor 80619 Igniter Cartridge 83529 Hairpin 25506...
-
Page 21: Wiring Diagram
Wiring Diagram... - Page 22 Notes...
- Page 23 Notes...
- Page 24 Notes...
-
Page 25: Service Record
Service Record It is recommended that your heating system is serviced regularly and that the appropriate Service Interval Record is completed. SERVICE PROVIDER Before completing the appropriate Service Record below, please ensure you have carried out the service as described in the manufacturer’s instructions. Always use the manufacturer's specified spare part when replacement is necessary. - Page 26 2. THE PART DESCRIPTION / LA DESCRIPTION DE LA PIÈCE ___________________________________________________ 3. THE MODEL NUMBER / LE NUMÉRO DE MODÈLE __________________________________________________________ 4. THE SERIAL NUMBER / LE NUMÉRO DE SÉRIE ______________________________________________________________ United States Stove Company 227 Industrial Park Road P.O. Box 151...
- Page 28 BLANC NOIR BLANC ROUGE BLEU ORANGE...
